ELECTROMAGNETIC COMPATIBILITY INFORMATION

Guidance & Declaration — electromagnetic immunity

The model TL90 is intended for use in the electromagnetic environment specified below. The customer or the

user of the model TL90 should assure that It is used in such an environment.

Immunity test IEC 60601

Compliance

Electromagnetic environment –

test level

level

guidance

Electrostatic

±6kVcontact

±6kVcontact

Floors should be wood, concrete or

discharge(ESD)

±8kVair

±8kVair

ceramic tile. If floors are covered with

IEC61000-4-2

synthetic material, the relative humidity

should be at least 30 %.

Electrical fast

±2 kV for power

±2 kV for power

Mains power quality should be that of

transient/burst

supply lines

supply lines

a typical commercial or hospital envi-

IEC61000-4-4

±1 kV for input/output

ronment.

lines

Surge

±1 kV differential mode

±1 kV differential

Mains power quality should be that of

IEC61000-4-5

±2 kV common mode

mode

a typical commercial or hospital envi-

ronment.

Voltage dips,

<5 % U

<5 % U

Mains power quality should be that of a

T

T

short interruptions

(>95 % dip in U

T

)

(>95 % dip in U

typical commercial or hospital environ-

T

)

and voltage vari-

for 0,5 cycle

for 0,5 cycle

ment. If the user of the TL90 requires

ations on power

continued operation during power

supply input lines

40 % U

mains interruptions, it is recommended

T

40 % U

T

IEC61000-4-11

(60%dipinU

T

)

(60%dipinU

)

that the TL90 be powered from an unin-

T

for 5 cycles

for 5 cycles

terruptible power supply or a battery.

70 % U

T

70 % U

T

(30 % dip in U

T

)

(30 % dip in U

T

)

for 25 cycles

for 25 cycles

<5 % U

T

<5 % U

T

(>95 % dip in U

T

)

(>95 % dip in U

T

)

for 5 sec

for 5 sec

Power frequency

3A/m 3A/m Power frequency magnetic fields

(50/60Hz)

should be at levels characteristic of a

magnetic field

typical location in a typical commercial

IEC61000-4-8

or hospital environment.

NOTE U

T

is the a.c. mains voltage prior to application of the test level.

64

Guidance & Declaration — electromagnetic immunity

The TL90 is intended for use in the electromagnetic environment specified below. The customer or

the user of the TL90 should ensure that it is used in such an environment.

Immunity test IEC 60601

Compliance

Electromagnetic environment –

test level

level

guidance

Portable and mobile RF communications

equipment should be used no closer to any

part of the TL90, including cables, than the

recommended separation distance calcu-

lated from the equation applicable to the

frequency of the transmitter.

Recommended separation distance

3V

Radiated RF

3 V/m

3 V/m

1/2

IEC61000-4-3

80MHzto2,5GHz

d=1.2 P

80MHzto800MHz

1/2

d=2.3 P

800MHzto2.5GHz

where P is the maximum output power rating

ofthetransmitterinwatts(W)according

to the transmitter manufacturer and d is

the recommended separation distance in

metres(m).

Field strengths from fixed RF transmitters,

as determined by an electromagnetic site

a

survey,

should be less than the compliance

b

level in each frequency range.

Interference may occur in the vicinity of

equipment marked with the following

symbol:

65

NOTE 1At80MHzand800MHz,thehigherfrequencyrangeapplies.

NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorpti-

on and reflection from structures, objects and people.

a

Fieldstrengthsfromfixedtransmitters,suchasbasestationsforradio(cellular/cordless)telephonesandland

mobileradios,amateurradio,AMandFMradiobroadcastandTVbroadcastcannotbepredictedtheoretically

with accuracy. To assess the electromagnetic environment due to fixed RF transmitters, an electromagne-

tic site survey should be considered. If the measured field strength in the location in which the TL90 is used

exceeds the applicable RF compliance level above, the Medical Daylight should be observed to verify normal

operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting

or relocating the TL90.

b

Overthefrequencyrange150kHzto80MHz,fieldstrengthsshouldbelessthan[V1]V/m.

Recommended separation distances between

portable and mobile RF communications equipment and the TL90

The TL90 is intended for use in an electromagnetic environment in which radiated RF disturbances are con-

trolled. The customer or the user of the Medical Daylight can help prevent electromagnetic interference by

maintainingaminimumdistancebetweenportableandmobileRFcommunicationsequipment(transmitters)

and the TL90 as recommended below, according to the maximum output power of the communications

equipment.

Rated maximum output

Separation distance according to frequency of transmitter m

power of

transmitter W

150 kHz to 80 MHz

80 MHz to 800 MHz

800 MHz to 2,5 GHz

1/2

1/2

1/2

d = 1.2 x P

d = 1.2 x P

d = 2.3 x P

0,01 0.12 0.12 0.23

0,1 0.38 0.38 0.73

1 1.2 1.2 2.3

10 3.8 3.8 7.3

100 12 12 23

For transmitters rated at a maximum output power not listed above, the recommended separation distance d

inmeters(m)canbeestimatedusingtheequationapplicabletothefrequencyofthetransmitter,wherePis

themaximumoutputpowerratingofthetransmitterinwatts(W)accordingtothetransmittermanufacturer.

NOTE 1At80MHzand800MHz,theseparationdistanceforthehigherfrequencyrangeapplies.

NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorpti-

on and reflection from structures, objects and people.
