ENGLISH
Read these instructions for use carefully and keep them for
later use, be sure to make them accessible to other users
and observe the information they contain�
Table of contents
1� Signs and symbols ����������������������������������������������������������� 14
2� Intended use ��������������������������������������������������������������������� 14
3� Notes ��������������������������������������������������������������������������������� 15
4� Unit description ���������������������������������������������������������������� 17
5� Initial use ��������������������������������������������������������������������������� 18
6� Operation �������������������������������������������������������������������������� 19
7� Cleaning ���������������������������������������������������������������������������� 20
8� Replacement parts and additional items ����������������������� 20
9� Disposal ���������������������������������������������������������������������������� 20
10� What if there are problems? �������������������������������������������� 21
11� Technical data ������������������������������������������������������������������� 21
Dear customer,
Thank you for choosing one of our products. Our brand stands for well-engineered,
quality made products; driven by innovation and safety. Our product range en-
compasses a wealth of products for health and well-being in the heat, weight,
blood pressure, body temperature, pulse, gentle therapy, massage, beauty, baby
and air sectors.
With kind regards,
Your Beurer team
12
Included in delivery
Check that the delivery has not been tampered with and make sure that all com-
ponents are present. Before use, ensure that there is no visible damage to the
device or accessories and that all packaging material has been removed. If you
have any doubts, do not use the device and contact your retailer or the specified
Customer Services address.
1 x aroma diuser
1 x mains adapter
1 x cleaning brush
1 x measuring jug
1 x set of instructions for use
WARNING
•
This device may be used by children over the age of
eight and by people with reduced physical, sensory
or mental skills or a lack of experience or knowledge,
provided that they are supervised or have been in-
structed on how to use the device safely, and are
fully aware of the consequent risks of use.
•
Children must not play with the device.
•
Cleaning and user maintenance must not be per-
formed by children unless supervised.
•
Disconnect the device from the mains supply during
filling or cleaning.
•
Do not use any solvent-based cleaning products.
•
If the mains connection cable of this device is dam-
aged, it must be replaced by the manufacturer, its
customer service department or a similarly qualified
person to avoid any risk.
13
1� Signs and symbols
The following symbols appear in these instructions for use and on the device:
WARNING
Warning notice indicating a risk of injury or damage to health.
IMPORTANT
Safety note indicating possible damage to the device/accessory.
Note
Note on important information.
Observe the instructions for use
Disposal in accordance with the Waste Electrical and Electronic
Equipment EC Directive – WEEE
This product satisfies the requirements of the applicable European
and national directives.
Manufacturer
2� Intended use
The aroma diuser is only to be used for improving the ambient scent in a room.
The device is intended for private use.
Use the device for the intended purpose only and in the manner specified in these
instructions for use. Any form of improper use can be dangerous. The manufacturer
is not liable for damage resulting from improper or careless use.
14
3� Notes
Non-observance of the following information may result in personal injury or
material damage.
Safety notes
WARNING
•
Keep packaging material away from children! Choking hazard!
•
If you suer from a severe respiratory or lung disease, consult your doctor before
using the device.
•
If you start to feel unwell while the device is in use, stop using it immediately,
switch the device o and ventilate the room.
Electric shock
WARNING
As with every electrical device, use this device carefully and cautiously, in order
to avoid hazards due to electric shock.
•
Therefore, observe the following instructions for use:
– Only use this device with the voltage specified on the device
– Never use the device if it shows visible signs of damage
– Do not use the device during a thunderstorm
•
In the case of defects or operational faults, switch the device o immediately and
disconnect the device from the mains socket. Do not pull on the mains cable or
on the device to disconnect the mains adapter from the socket. Never hold or
carry the device by the mains cable.
•
Only use the device in dry rooms (e.g. never in the bath, sauna).
•
Never reach for a device that has been submerged in water. Disconnect the
mains adapter immediately.
•
Do not drop the device or subject it to any impacts.
•
Do not clamp or pinch the mains cable.
•
Ensure that the mains cable and mains adapter do not come into contact with
water, steam or other liquids.
15
Repairs
WARNING
Only specialist personnel may perform repairs on electrical devices. Improper
repairs may subject users to considerable danger. For repairs, please contact
Customer Services or an authorised retailer.
Risk of fire
WARNING
There is a risk of fire if the device is used improperly or these instructions for use
are ignored.
Therefore, observe the following instructions for use:
•
Never use underneath a cover, such as a blanket, pillow, etc.
•
Never use near petrol or other highly flammable substances.
Handling
IMPORTANT
•
The device must be switched o and disconnected from the mains every time
after use and before cleaning.
•
Ensure that the mains cable does not pose a trip hazard.
•
Do not insert any objects into openings on the device.
•
Do not place any objects on the device.
•
Do not expose the device to high temperatures.
•
Avoid water damage by handling the device carefully (e.g. water damage from
splashing in the vicinity of wooden floors).
•
If the device should accidentally tip over, water may escape, even if the device
is switched o and unplugged.
•
The immediate vicinity of the device can become damp.
•
Calcareous water can leave white deposits.
•
Do not place the device on the floor, but in a raised position (e.g. on a table or
chest of drawers).
•
Position the device so that the mist outlet is not directed towards objects.
•
Empty any remaining water when the device is not in use.
•
Do not expose the device to high temperatures.
•
The water tank and the cover are made of oil-resistant materials. Keep aroma oils
away from other components of the device as these could become damaged by
certain ingredients within the oils.
16
4� Unit description
3
2
11
4
1
9
10
8
5
6
7
1 Water tank 7 Connection socket
2 Cover 8 Measuring jug
3 Outlet 9 Cleaning brush
4 Wind channel 10 Mains cable
5 ON/OFF button 11 Mains adapter
6 LED light
17
5� Initial use
WARNING
•
Only fill the device when the network adapter is unplugged.
•
Never fill the device when the cover is still on.
•
Only use for water-based aroma oils.
•
Open the cardboard packaging, remove all the packaging film and check the
device for damage.
1. Pull the cover upwards to remove it.
2. Fill the measuring jug with water up
to the “MAX” marking.
3.
Carefully pour the water from the
4.
Add three to five drops of the (water-
measuring jug into the device. Ob-
based) aroma oil that you want to
serve the
“MAX” marking
in the de-
use.
vice.
18
5. Replace the cover. 6.
Insert the mains cable into the rear of
the device and connect to a socket.
6� Operation
Press the ON/OFF button to switch on the device ( ).
Note
The device has three dierent modes:
Aroma diuser Blue LED light
ON OFF
Press the ON/OFF button (
) 1x
ON ON
Press the ON/OFF button (
) 2x
OFF OFF
Press the ON/OFF button (
) 3x
The device has an automatic switch-o function. If the tank is empty, the device
switches itself o after 2-3 seconds.
After use
1. Disconnect the device from the socket.
2. Remove the cover from the device in an
upward direction.
3.
Pour any remaining water down the drain.
4.
Clean the device as described under
“7.Cleaning”.
19
7� Cleaning
Note
Before cleaning the device, ensure that the device is disconnected from the
power supply and that there is no water left in the water tank. Regular cleaning
is a prerequisite for hygienic and fault-free operation. The aroma diuser can be
dismantled for cleaning easily and without tools.
•
Clean the device after every use using a soft, slightly damp cloth or the clean-
ing brush included in the delivery, paying particular attention to the cover and
the inside of the water tank. Never use abrasive, corrosive or solvent-based
cleaning products.
8� Replacement parts and additional items
Replacement parts and additional items are available from the corresponding
service address (according to the service address list). Please state the corre-
sponding item number. Replacement parts and additional items are also avail-
able from retailers.
Item Item number
Beurer by Taoasis “Vitality” aroma oil (10 ml) 681.30
Beurer by Taoasis “Harmony” aroma oil (10 ml) 681.31
Beurer by Taoasis “Relax” aroma oil (10 ml) 681.32
9� Disposal
Dispose of the device in accordance with EC Directive – WEEE
(Waste Electrical and Electronic Equipment). If you have any questions,
please contact the local authorities responsible for
waste disposal.
20
10� What if there are problems?
Problem Cause Solution
No mist is being
Mains adapter is not
Insert the mains adapter into a
emitted from the
plugged in.
suitable socket.
device
There is not enough
Fill the water tank up to the
water in the water tank.
“MAX” marking.
There is too much water
Pour away excess water from
in the water tank.
the water tank until it only
reaches the “MAX” marking.
The outlet in the cover is
Check that the outlet in the
blocked.
cover is not blocked.
If you cannot find a solution to your problem here, contact our Customer Services.
11� Technical data
Product name LA 50
Mains voltage/frequency 220–240 V AC / 50/60 Hz DC:24 V
Water tank capacity 100 ml
Nominal power 12 W
2
Room size up to approx. 15 m
How it works Ultrasonic atomiser
Run time approx. 4-8 hours
IP50, protection against harmful quanti-
Protection class
ties of dust, no protection against water.
LA 50: approx. 295 g
Weight
adapter: approx. 113 g
Dimensions 116 x 112 x 162 mm
