Beurer HK 72: 2. Important instructions Retain for future use

2. Important instructions Retain for future use: Beurer HK 72

1. Included in delivery

1 Heating pad

1 Battery

1 Charger

1 Instructions for use

1.1 Device description

1. Charger

2. Battery pack

3. Connection socket for the battery pack

4. Connector plug for the charger

5. Connector plug for the connection cable

6. LED display for the temperature settings

(blue)

1 2 3 4

7. LED display for the state of charge (green)

8. Button for controlling ON/OFF and tem-

perature settings

2. Important instructions

Retain for future use

WARNING

• Non-observance of the following notes may result in personal injury

or material damage (electric shock, skin burns, fire). The following

safety and hazard information is not only intended to protect your

health and the health of others, it should also protect the product.

For this reason, pay attention to these safety notes and include these

instructions when handing over the product to others.

• This heating pad must not be used by persons who are not sensi-

tive to heat or by vulnerable persons who may not be able to react to

overheating.

• This heating pad may not be used by very young children (0 – 3 years

old) as they are unable to respond to overheating.

• This heating pad may not be used by young children (3 – 8 years old)

unless the controller has been set by a parent or responsible adult

and the child has been given adequate instructions on how to use

the heating pad safely.

• This heating pad may be used by children over the age of 8 and by

people with reduced physical, sensory or mental skills or a lack of

experience or knowledge, provided that they are supervised and

have been instructed on how to use the heating pad safely, and are

fully aware of the consequent risks of use.

• Children must not play with the heating pad.

10

1

1 2 3 4

1

6

2

1 2 3 4

7

8

5

3

4

• Cleaning and user maintenance must not be performed by children

unless supervised.

• This heating pad is not designed for use in hospitals.

• Do not insert needles.

• Do not use when folded or bunched up.

• Do not use if wet.

• This heating pad may only be used in conjunction with the battery

pack specified on the label.

• To charge the battery pack, you must use only the provided charger

type RSS1002-101084-W2E

• The electrical and magnetic fields emitted by this heating pad may

interfere with the function of a pacemaker. However, they are still well

below the limits: electrical field strength: max. 5000V/m, magnetic

field strength: max. 80A/m, magnetic flux density: max. 0.1 millitesla.

Please consult your doctor and the manufacturer of your pacemaker

before using this heating pad.

• Do not pull, twist or make sharp bends in the cables.

• Please check this heating pad frequently for signs of wear and tear

or damage. If you detect signs of improper use of the heating pad,

then this must be inspected by the manufacturer before switching on

again.

• If the cables of the heating pad or the charger are damaged, they

must be replaced by the manufacturer, its customer service depart-

ment or a similarly qualified person to avoid any risk.

• When this heating pad is switched on:

– Do not place any objects on it (e.g. suitcase or washing basket).

– Heat sources, such as hot water bottles, heating pads or similar,

must not be placed on the pad.

• While charging, do not cover the battery pack with covers, cushions

or similar items.

• Always observe the notes on operation (section 4), cleaning and

maintenance (section 5) and storage (section 6).

• If you should have any questions about using our devices, please

contact Customer Services.

3. Intended use

IMPORTANT

This heating pad is only designed to warm up the human body.

11

4. Operation

4.1 Safety

IMPORTANT

The heating pad is fitted with a SAFETY SWITCH-OFF. A sensor prevents the heating pad from

overheating by means of automatic switch-off in the event of an error. Once the SAFETY SWITCH-

OFF has taken place, the blue LED display for the temperature settings (6) that is shown when

switched on is no longer lit up. After cooling down to room temperature, the heating pad can

be switched on again.

4.2 Charging the battery pack

IMPORTANT

The battery pack (2) must be charged prior to initial use or if the device has not been used for a long

period.

– To do this, insert the charger (1) into a socket with the mains voltage corresponding to the specifications

on the charger.

– Connect the connector plug of the charger (4) to the connection socket on the battery pack (3). When

charging, the green LED display for the state of charge (7) flashes on the battery pack.

– The battery pack is fully charged when the green display for the state of charge is permanently lit (it takes

approx. 2 – 3 hours to fully charge an empty battery pack).

– The green LED display for the state of charge of the battery pack goes out once the battery pack has been

disconnected from the charger.

– The battery pack should be charged at least 1x per year to maintain its capacity.

– While charging, do not cover the battery pack with covers, cushions or similar items.

– Only charge the battery pack in a dry environment at normal room temperature.

4.3 Checking the state of charge of the battery pack

The heating pad must not be connected to the battery pack.

Press the button for controlling ON/OFF and temperature settings (8)

– If the green LED display for the state of charge (7) lights up for 3 sec.: the battery pack has more than 25%

charging capacity.

– If the green LED display for the state of charge (7) flashes 3x 1 sec.: the battery pack has less than 25%

charging capacity.

4.4 Operating the heating pad

• Insert the charged battery pack (2) into the integrated pouch in the heating pad with the rounded side facing

forward. Then insert the connector plug for the connection cable (5) of the heating pad into the connection

socket on the battery pack (3). The heating pad is now ready for use.

•

Place the heating pad on your stomach or on your back with the light oval facing towards your body. Sub-

sequently guide the right strap of the heating pad around the body and secure the heating pad by closing

the hook-and-loop fastener.

IMPORTANT

Ensure that the heating pad will not bunch up or become folded during use.

12

4.5 Switching on

Switch on the heating pad by pressing the button for controlling ON/OFF and temperature settings (8).

The blue LED display for temperature setting 1 lights up. Press the button repeatedly to increase the tem-

perature setting.

The corresponding blue LED displays for the temperature settings (6) light up. Press the button again to

switch off the heating pad.

Switching sequence: 1, 2, 3, 4, OFF, 1, ……

When switched on, the blue LED display for the temperature settings is lit up.

NOTE

The fastest way to warm up the heating pad is to initially set the highest temperature setting.

NOTE

This heating pad has a fast heating function, which allows the heating pad to warm up quickly in the

first 10 minutes.

WARNING

If the heating pad is being used over several hours, we recommend that

you set the lowest temperature setting on the battery pack (2) to avoid

overheating the heated body part, which may lead to burns to the skin.

NOTE

When the battery pack (2) has been almost completely run down, the heating pad is switched off

automatically to protect the battery pack. The battery pack must then be charged.

4.6 Setting the temperature

Setting 1: minimum heat

Setting 2 – 3: medium heat

Setting 4: maximum heat

4.7 Switching off

Press the button for controlling ON/OFF and temperature settings (8) to switch off the heating pad. The

switching sequence is 1 – 2 – 3 – 4 – OFF … The blue LED display for the temperature settings (6) goes out

when the heating pad is switched off.

NOTE

Please note that the battery pack must be protected against extreme cold (such as being placed under

clothing) to maintain its performance.

4.8 Automatic switch-off time

This heating pad is equipped with an automatic switch-off function. This turns off the heat supply approx. 90

minutes after the initial use. The blue LED display for the temperature settings (6) is no longer lit up after this.

You can switch the heating pad on again immediately by pressing the button for controlling ON/OFF and

temperature settings (8). If the heating pad can no longer be switched on, then the battery pack (2) has been

run down.

13

5. Cleaning and maintenance

IMPORTANT

• Prior to cleaning, you must always disconnect the battery pack (2) from the heating pad and remove

it from the heating pad pouch, otherwise there is a risk of damage.

IMPORTANT

• The battery pack (2) must never come into contact with water or other liquids, as this may cause

damage.

To clean the battery pack, use a dry, lint-free cloth. Do not use any chemical or abrasive cleaning agents.

IMPORTANT

• Please note that the heating pad may not be dry cleaned, wrung out, tumble dried, put through a

mangle or ironed. Otherwise the heating pad may be damaged.

This heating pad is machine-washable. For this purpose, close the hook-and-loop fastener of the heating pad

and place it in a pillow case. Set the washing machine to a particularly gentle wash cycle at 30 °C (wool cycle).

For ecological reasons, always wash the heating pad together with other textiles.

Use a delicate laundry detergent and measure it out according to the manufacturer’s instructions.

IMPORTANT

• Please note that frequent washing of the heating pad has a negative effect on the product.

The heating pad should therefore be washed in a washing machine a maximum of 10 times during its life.

Let the heating pad dry flat on a clothes horse.

IMPORTANT

• Do not use pegs or similar items to attach the heating pad to the clothes horse, otherwise the

heating pad may be damaged.

• Only reconnect the heating pad to the battery pack (2) once the heating pad and the connector

plug of the connection cable (5) are completely dry, otherwise this could damage them.

6. Storage

If you do not plan to use the heating pad for a long period of time, we recommend that you store it in the

original packaging.

IMPORTANT

Please allow the heating pad to cool down before storing. Otherwise the heating pad may be damaged.

To avoid making sharp bends in the heating pad, do not place any objects on top of it whilst storing.

IMPORTANT

The battery pack should be charged 1x per year to maintain its capacity.

7. Disposal

Please dispose of the device in accordance with EC Directive – WEEE (Waste Electrical and Elec-

tronic Equipment). If you have any questions, please contact the local authorities responsible for

waste disposal.

14

8. What if there are problems?

Problem Cause Solution

The blue LED display for the temperature

The battery pack has been fully run

Charge the battery pack.

settings (6) does not light up when:

down.

– the battery pack is connected to the

There was a SAFETY SWITCH-OFF

Allow the heating pad to

heating pad and

due to an error.

cool down to room tempe-

– the button for controlling ON/OFF and

rature and switch on again.

temperature settings has been pressed.

The blue LED display for the temperature

The heating pad or the battery

Send the heating pad and

settings (6) does not light up when:

pack is faulty.

the battery pack to Service.

– the fully charged battery pack is con-

nected to the heating pad and

– the button for controlling ON/OFF and

temperature settings has been pressed.

The green LED display for the state of

Display for the state of charge of

charge lights up or flashes when the bat-

the battery pack:

tery pack is not connected to the heating

LED lights up for approx. 3 se-

pad.

conds: state of charge > 25%

LED flashes 3x: state of charge

< 25%

9. Technical data

See the type plate label on the heating pad, on the battery pack and on the charger.

10. Replacement parts

You can obtain the following replacement parts directly from Customer Services:

• Battery pack (item des. 108.303)

• Charger (item des. 546.007)

• Extension strap (item des. 162.685)

15
