Sound adjustments
Selecting preset sound modes (C-EQ: custom equalizer)
ENGLISH
You can select a preset sound mode suitable to
Preset values
the music genre.
Indication For:
1
2
3
BAS
*
TRE
*
LOUD
*
USER (Flat sound) 00 00 OFF
~
ROCK Rock or
+03 +01 ON
disco music
CLASSIC Classical
+01 –02 OFF
music
POPS Light music +04 +01 OFF
Ÿ
HIP HOP Funk or rap
+02 00 ON
music
JAZZ Jazz music +02 +03 OFF
1
*
BAS: Bass
2
*
TRE: Treble
3
*
LOUD: Loudness
Ex.: When “ROCK” is selected
Indication pattern for each sound mode:
18
EN18-23_KD-G411[EX_EU]f.indd 18 9/16/04, 8:27:10 PM
Indication To do: Range
Adjusting the sound
1
BAS*
Adjust the bass. –06 (min.)
You can adjust the sound characteristics to your
(bass)
to
preference.
+06 (max.)
ENGLISH
1
TRE*
Adjust the treble. –06 (min.)
1
(treble)
to
+06 (max.)
2
FAD*
Adjust the front
R06 (Rear
(fader)
and rear speaker
only)
balance.
to
F06 (Front
only)
Ex.: When “TRE” is selected
BAL
Adjust the left
L06 (Left
(balance)
and right speaker
only)
2
balance.
to
R06 (Right
only)
1
LOUD*
Boost low and
LOUD ON
(loudness)
high frequencies
J
to produce a well-
LOUD OFF
Indication pattern changes as
balanced sound at
you adjust the level.
low volume level.
3
VOL*
Adjust the volume. 00 (min.) to
(volume)
30 or 50
4
(max.)*
1
*
When you adjust the bass, treble, or
loudness, the adjustment you have made is
stored for the currently selected sound mode
(C-EQ) including “USER.”
2
*
If you are using a two-speaker system, set
the fader level to “00.”
3
*
Normally the control dial works as the
volume control. So you do not have to select
“VOL” to adjust the volume level.
4
*
Depending on the amplifier gain control
setting. (See page 21 for details.)
19
EN18-23_KD-G411[EX_EU]f.indd 19 10/7/04, 11:29:36 AM
General settings — PSM
3 Adjust the PSM item selected.
Basic procedure
You can change PSM (Preferred Setting Mode)
items listed in the table that follows.
ENGLISH
1
4 Repeat steps 2 and 3 to adjust the
other PSM items if necessary.
5 Finish the procedure.
2
Select a PSM item.
Ex.: When you select “DIMMER”
Indications Selectable settings, [reference page]
DEMO
DEMO ON: [Initial]; Display demonstration will be activated
Display demonstration
automatically if no operation is done for about
20 seconds, [7].
DEMO OFF: Cancels.
CLOCK H
0 – 23 (1 – 12), [7]
Hour adjustment
[Initial: 0 (0:00)]
CLOCK M
00 – 59, [7]
Minute adjustment
[Initial: 00 (0:00)]
24H/12H
12H O 24H, [7]
24 hours or 12 hours time
[Initial: 24H]
display
CLK ADJ
AUTO: [Initial]; The built-in clock is automatically adjusted
Clock adjustment
using the CT (clock time) data in the RDS signal.
OFF: Cancels.
20
EN18-23_KD-G411[EX_EU]f.indd 20 10/7/04, 11:29:36 AM
Indications Selectable settings, [reference page]
AF-REG
When the received signals from the current station become weak...
Alternative frequency/
AF: [Initial]; Switches to another station (the programme
regionalization reception
may differ from the one currently received), [12].
ENGLISH
• The AF indicator lights up.
AF REG: Switches to another station broadcasting the same
programme.
• The AF and REG indicators light up.
OFF: Cancels.
PTY STBY
[Initial: OFF]; Activates PTY Standby Reception with one of the
PTY standby
29 PTY codes, [12].
TA VOL
[Initial: VOL 20]; VOL 00 – VOL 30 or 50*, [11]
Traffic announcement
* Depends on the amplifier gain control.
volume
P-SEARCH
ON: Using the AF data, the receiver tunes in to another
Programme search
frequency broadcasting the same programme as the
original preset RDS station is if the preset station
signals are not sufficient.
OFF: [Initial]; Cancels.
DIMMER
ON: Activates dimmer.
Dimmer
OFF: [Initial]; Cancels.
TEL
MUTING 1/MUTING 2: Select either one which mutes the
Telephone muting
sounds while using the cellular phone.
OFF: [Initial]; Cancels.
SCROLL
ONCE: [Initial]; Scrolls the disc information once.
Scroll
AUTO: Repeats scrolling (5-second intervals in between).
OFF: Cancels.
• Pressing DISP for more than one second can scrolls the display
regardless of the setting.
TAG DISP
TAG ON : [Initial]; Shows the ID3 tag while playing
Tag display
MP3/WMA tracks, [16].
TAG OFF: Cancels.
AMP GAIN
You can change the maximum volume level of this receiver.
Amplifier gain control
LOW PWR: VOL 00 – VOL 30 (Select this if the maximum
power of the speaker is less than 50 W to prevent
them from damaging the speaker.)
HIGH PWR: [Initial]; VOL 00 – VOL 50
21
EN18-23_KD-G411[EY]f.indd 21 10/19/04, 10:06:11 AM
Detaching the control panel
When detaching or attaching the control panel,
Attaching the control panel
be careful not to damage the connectors on
the back of the control panel and on the panel
holder.
ENGLISH
Detaching the control panel
Before detaching the control panel, be sure to
turn off the power.
22
EN18-23_KD-G411[EX_EU]f.indd 22 9/15/04, 10:21:30 AM
Using the remote controller — RM-RK60
This receiver can be remotely controlled as
instructed here (with an optionally purchased
Main elements and features
remote controller). We recommend that you use
remote controller RM-RK60 with your receiver.
• When operating, aim the remote controller
ENGLISH
directly at the remote sensor on the
receiver. Make sure there is no obstacle in
between.
Installing the lithium coin battery
(CR2025)
1 (standby/on attenuator) button
• Turns on and off the power and also
attenuates the sound.
2 SRC (source) button
• Selects the source.
Warning:
3 R (reverse) / F (forward) buttons
• Store the battery in a place where children
• Searches for stations if pressed briefly.
cannot reach to avoid risk of accident.
• Fast-forwards or reverses the track if
• To prevent the battery from over-heating,
pressed and held.
cracking, or starting a fire:
• Changes the tracks on the disc.
– Do not recharge, short, disassemble, or
4 SOUND button
heat the battery or dispose of it in a fire.
• Selects the sound mode (C-EQ: custom
– Do not leave the battery with other
equalizer).
metallic materials.
5 U (up) / D (down) buttons
– Do not poke the battery with tweezers or
• U (up): Changes the FM/AM bands.
similar tools.
• D (down): Changes the preset stations.
– Wrap the battery with tape and insulate
• Changes the folder on the MP3/WMA
when throwing away or saving it.
discs.
6 VOLUME +/– buttons
• Adjusts the volume level.
Caution:
The receiver is equipped with the steering
wheel remote control function.
• See the Installation/Connection Manual
(separate volume) for connection.
23
EN18-23_KD-G411[EX_EU]f.indd 23 10/7/04, 11:30:04 AM
Maintenance
How to clean the connectors
To keep discs clean
Frequent detachment will deteriorate the
A dirty disc may not play correctly.
connectors.
If a disc does become dirty, wipe
To minimize this possibility, periodically wipe
it with a soft cloth in a straight line
ENGLISH
the connectors with a cotton swab or cloth
from center to edge.
moistened with alcohol, being careful not to
• Do not use any solvent (for
damage the connectors.
example, conventional record cleaner, spray,
thinner, benzine, etc.) to clean discs.
To play new discs
New discs may have some rough
spots around the inner and outer
edges. If such a disc is used, this
Connector
receiver may reject the disc.
To remove these rough spots, rub the edges
Moisture condensation
with a pencil or ball-point pen, etc.
Moisture may condense on the lens inside the
CD player in the following cases:
• After starting the heater in the car.
• If it becomes very humid inside the car.
Should this occur, the CD player may
malfunction. In this case, eject the disc and
leave the receiver turned on for a few hours
until the moisture evaporates.
How to handle discs
When removing a disc from
Center holder
its case, press down the center
holder of the case and lift the
disc out, holding it by the
edges.
• Always hold the disc by the edges. Do not
touch its recording surface.
When storing a disc into its case, gently insert
the disc around the center holder (with the
printed surface facing up).
• Make sure to store discs into the cases after
use.
Do not use the following discs:
Sticker
Sticker
Stick-on
Warped
residue
Disc
label
disc
24
EN24-29_KD-G411[EY]f.indd 24 10/19/04, 11:45:05 AM
More about this receiver
Basic operations
Inserting a disc
• When a disc is inserted upside down, the disc
Turning off the power
automatically ejects.
• If you turn off the power while listening to a
• Do not insert 8 cm discs (single CD) and
disc, disc play will start from where playback
ENGLISH
unusual shape discs (heart, flower, etc.) into
has been stopped previously, next time you
the loading slot.
turn on the power.
Playing a disc
Tuner operations
• While fast-forwarding or reversing on an MP3
Storing stations in memory
or WMA disc, you can only hear intermittent
• During SSM search...
sounds.
– All previously stored stations are erased and
stations are stored newly.
Playing a CD-R or CD-RW
– Received stations are preset in No. 1 (lowest
• Use only “finalized” CD-Rs or CD-RWs.
frequency) to No. 6 (highest frequency).
• This receiver can play back only the files of
– When SSM is over, the station stored in
the same type which is first detected if a disc
No. 1 will be automatically tuned in.
includes both audio CD (CD-DA) files and
• When storing a station manually, a previously
MP3/WMA files.
preset station is erased when a new station is
• This receiver can play back multi-session
stored in the same preset number.
discs; however, unclosed sessions will be
skipped while playing.
FM RDS operations
• Some CD-Rs or CD-RWs may not play
• Network-Tracking Reception requires two
back on this receiver because of their disc
types of RDS signals—PI (Programme
characteristics, and for the following causes:
Identification) and AF (Alternative
– Discs are dirty or scratched.
Frequency) to work correctly. Without
– Moisture condensation occurs on the lens
receiving these data correctly, Network-
inside the receiver.
Tracking Reception will not operate.
– The pickup lens inside the receiver is dirty.
• If a Traffic Announcement is received, the
– CD-R/CD-RW on which the files are
volume level (TA Volume) automatically
written with “Packet Write” method.
changes to the preset level.
– There are improper recording conditions
(missing data, etc.) or media conditions
Disc operations
(stain, scratch, warp, etc.).
• CD-RWs may require a longer readout time
General
since the reflectance of CD-RWs is lower
• This receiver has been designed to reproduce
than that of regular CDs.
CDs/CD Texts, and CD-Rs (Recordable)/
• Do not use the following CD-Rs or CD-RWs:
CD-RWs (Rewritable) in audio CD (CD-DA),
– Discs with stickers, labels, or protective seal
MP3 and WMA format.
stuck to the surface.
• When a disc has been loaded, selecting “CD”
– Discs on which labels can be directly
for the playback source starts disc play.
printed by an ink jet printer.
Using these discs under high temperatures
or high humidity may cause malfunctions or
damage to discs.
25
EN24-29_KD-G411[EX_EU]f.indd 25 10/7/04, 11:33:46 AM
• This receiver cannot play back the following
Playing an MP3/WMA disc
files:
• This receiver can play back MP3/WMA files
– MP3 files encoded with MP3i and MP3
with the extension code <.mp3> or <.wma>
PRO formats.
(regardless of the letter case—upper/lower).
– MP3 files encoded in an unappropriated
ENGLISH
• This receiver can show the names of albums,
format.
artists (performer), and ID3 Tag (Version 1.0,
– MP3 files encoded with Layer 1/2.
1.1, 2.2, 2.3, or 2.4) for MP3 files and for
– WMA files encoded with lossless,
WMA files.
professional, and voice formats.
• This receiver can handle only one-byte
– WMA files which are not based upon
characters. No other characters can be
®
Windows Media
Audio.
correctly displayed.
– WMA formatted files copy-protected with
• This receiver can play back MP3/WMA files
DRM.
meeting the conditions below:
– Files which have the data such as WAVE,
– Bit rate: 8 kbps — 320 kbps
ATRAC3, etc.
– Sampling frequency:
• The search function works but search speed is
48 kHz, 44.1 kHz, 32 kHz (for MPEG-1)
not constant.
24 kHz, 22.05 kHz, 16 kHz (for MPEG-2)
– Disc format: ISO 9660 Level 1/ Level 2,
Changing the source
Romeo, Joliet, Windows long file name
• The maximum number of characters for file/
• If you change the source, playback also stops
folder names vary among the disc format used
(without ejecting the disc).
(includes 4 extension characters—<.mp3> or
Next time you select “CD” for the playback
<.wma>).
source, disc play starts from where it has been
– ISO 9660 Level 1: up to 12 characters
stopped previously.
– ISO 9660 Level 2: up to 31 characters
– Romeo*: up to 128 (72) characters
Ejecting a disc
– Joliet*: up to 64 (36) characters
• If the ejected disc is not removed within
– Windows long file name*: up to 128 (72)
15 seconds, the disc is automatically inserted
characters
again into the loading slot to prevent it from
* The parenthetic figure is the maximum
dust. (Disc will not play this time.)
number of characters for file/folder names
in case the total number of files and folders
General settings—PSM
is 313 or more.
• This receiver can recognize the total of 512
• If you change the “AMP GAIN” setting from
files, of 200 folders, and of 8 hierarchies.
“HIGH PWR” to “LOW PWR” while the
• This receiver can play back the files recorded
volume level is set higher than “VOL 30,” the
in VBR (variable bit rate).
receiver automatically changes the volume
The files recorded in VBR have a discrepancy
level to “VOL 30.”
in elapsed time display, and do not show
the actual elapsed time. Especially, after
performing the search function, this difference
becomes noticeable.
26
EN24-29_KD-G411[EX_EU]f.indd 26 10/7/04, 11:33:47 AM
Troubleshooting
What appears to be trouble is not always serious. Check the following points before calling a service
center.
Symptoms Causes Remedies
ENGLISH
• Sound cannot be heard
The volume level is set to
Adjust it to the optimum
from the speakers.
the minimum level.
level.
Connections are incorrect.
Check the cords and
connections.
General
• The receiver does not
The built-in microcomputer
Reset the receiver (see page
work at all.
may have functioned
2).
incorrectly due to noise, etc.
• SSM automatic presetting
Signals are too weak.
Store stations manually.
does not work.
FM/AM
• Static noise while listening
The aerial is not connected
Connect the aerial firmly.
to the radio.
firmly.
• Disc automatically ejects. Disc is inserted upside
Insert the disc correctly.
down.
• CD-R/CD-RW cannot be
CD-R/CD-RW is not
• Insert a finalized CD-R/
played back.
finalized.
CD-RW.
• Tracks on the CD-R/
• Finalize the CD-R/CD-
CD-RW cannot be
RW with the component
skipped.
which you used for
recording.
• Disc can be neither played
Disc is locked.
Unlock the disc (see page
back nor ejected.
15).
The CD player may have
Eject the disc forcibly (see
functioned incorrectly.
page 2).
Disc playback
• Disc sound is sometimes
You are driving on rough
Stop playback while driving
interrupted.
roads.
on rough roads.
Disc is scratched.
Change the disc.
Connections are incorrect.
Check the cords and
connections.
• “NO DISC” appears on the
No disc in the loading slot.
Insert a disc into the loading
display.
slot.
Disc is inserted incorrectly.
Insert the disc correctly.
27
EN24-29_KD-G411[EX_EU]f.indd 27 10/1/04, 9:02:57 PM
Symptoms Causes Remedies
• Disc cannot be played
No MP3/WMA tracks are
Change the disc.
back.
recorded on the disc.
ENGLISH
MP3/WMA tracks do not
Add the extension code
have the extension code
<.mp3> or <.wma> to their
<.mp3> or <.wma> in their
file names.
file names.
MP3/WMA tracks are not
Change the disc.
recorded in the format
(Record MP3/WMA
compliant with ISO 9660
tracks using a compliant
Level 1, Level 2, Romeo, or
application.)
Joliet.
• Noise is generated.
The track played back
Skip to another track or
is not an MP3/WMA
change the disc. (Do not add
track (although it has the
the extension code <.mp3>
extension code <.mp3> or
or <.wma> to non-MP3 or
<.wma>).
WMA tracks.)
• A longer readout time is
Readout time varies due to
Do not use too many
required (“CHECK” keeps
the complexity of the folder/
hierarchies and folders.
flashing on the display).
file configuration.
MP3/WMA playback
• Tracks cannot be played
Playback order is determined
back as you have intended
when the files are recorded.
them to play.
• Elapsed playing time is not
This sometimes occurs
correct.
during play. This is caused
by how the tracks are
recorded on the disc.
• “NO FILES” appears on
The current disc does not
Insert a disc that contains
the display.
contain any MP3/WMA
MP3/WMA tracks.
tracks.
• Correct characters are
This receiver can only
not displayed (e.g. album
display alphabets (capital:
name).
A – Z), numbers, and a
limited number of symbols.
28
EN24-29_KD-G411[EX_EU]f.indd 28 10/14/04, 9:29:14 AM
Specifications
AUDIO AMPLIFIER SECTION
CD PLAYER SECTION
Maximum Power Output:
Type: Compact disc player
Front: 50 W per channel
Signal Detection System: Non-contact optical
Rear: 50 W per channel
pickup (semiconductor laser)
ENGLISH
Continuous Power Output (RMS):
Number of channels: 2 channels (stereo)
Front: 19 W per channel into 4 Ω, 40 Hz
Frequency Response: 5 Hz to 20 000 Hz
to 20 000 Hz at no more than 0.8%
Dynamic Range: 96 dB
total harmonic distortion.
Signal-to-Noise Ratio: 98 dB
Rear: 19 W per channel into 4 Ω, 40 Hz
Wow and Flutter: Less than measurable limit
to 20 000 Hz at no more than 0.8%
MP3 decoding format:
total harmonic distortion.
MPEG1/2 Audio Layer 3
Load Impedance: 4 Ω (4 Ω to 8 Ω allowance)
Max. Bit Rate: 320 Kbps
®
Tone Control Range:
WMA (Windows Media
Audio) decoding
Bass: ±10 dB at 100 Hz
format:
Treble: ±10 dB at 10 kHz
Max. Bit Rate: 192 Kbps
Frequency Response: 40 Hz to 20 000 Hz
Signal-to-Noise Ratio: 70 dB
Line-Out Level/Impedance:
GENERAL
2.5 V/20 kΩ load (full scale)
Power Requirement:
Output Impedance: 1 kΩ
Operating Voltage:
DC 14.4 V (11 V to 16 V allowance)
Grounding System: Negative ground
TUNER SECTION
Allowable Operating Temperature:
Frequency Range:
0°C to +40°C
FM: 87.5 MHz to 108.0 MHz
Dimensions (W × H × D):
AM: (MW) 522 kHz to 1 620 kHz
Installation Size (approx.):
(LW) 144 kHz to 279 kHz
182 mm × 52 mm × 150 mm
Panel Size (approx.):
[FM Tuner]
188 mm × 58 mm × 11 mm
Usable Sensitivity: 11.3 dBf (1.0 µV/75 Ω)
Mass (approx.):
50 dB Quieting Sensitivity:
1.3 kg (excluding accessories)
16.3 dBf (1.8 µV/75 Ω)
Alternate Channel Selectivity (400 kHz): 65 dB
Frequency Response: 40 Hz to 15 000 Hz
Stereo Separation: 30 dB
Design and specifications are subject to change
Capture Ratio: 1.5 dB
without notice.
[MW Tuner]
Sensitivity: 20 µV
Selectivity: 35 dB
[LW Tuner]
Sensitivity: 50 µV
• Microsoft and Windows Media are either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
29
EN24-29_KD-G411[EX_EU]f.indd 29 10/14/04, 9:29:43 AM
Wir danken Ihnen für den Kauf eines JVC Produkts.
Bitte lesen Sie die Anleitung vollständig durch, bevor Sie das Gerät in Betrieb nehmen, um
sicherzustellen, daß Sie alles vollständig verstehen und die bestmögliche Leistung des Geräts
erhalten.
WICHTIG FÜR LASER-PRODUKTE
1. LASER-PRODUKT DER KLASSE 1
2. ACHTUNG: Die obere Abdeckung nicht öffnen. Das Gerät enthält keine Teile, die vom
Benutzer gewartet werden können. Wartungen nur von qualifziertem Fachpersonal durchführen
lassen.
DEUTSCH
3. ACHTUNG: Sichtbare und unsichtbare Laserstrahlung bei offenem Gerät und Defekt oder
Umgehen der Verriegelung. Setzen Sie sich dem Strahl nicht direkt aus.
4. ANBRINGEN DES ETIKETTS: WARNHINWEIS-ETIKETT, AUSSEN AM GERÄT
ANGEBRACHT.
Warnung:
Wenn Sie den Receiver beim Fahren
Zwangsweises Ausschieben
bedienen müssen, dürfen Sie nicht den Blick
einer Disk
von der Straße nehmen, da sonst die Gefahr
Wenn eine Disk vom Receiver nicht erkannt
von Verkehrsunfällen besteht.
wird oder nicht ausgeschoben kann, können
Sie zwangsweisen Ausschub wie folgt
ausführen.
Zurücksetzen des Geräts
• Wenn das nicht funktioniert, führen Sie
• Dadurch wird der Mikrocomputer
einen Reset am Receiver aus.
zurückgesetzt. Ihre vorgegebenen
• Achten Sie darauf, die ausgeschobene Disk
Einstellungen werden ebenfalls gelöscht.
nicht fallen zu lassen.
• Wenn eine Disk eingelegt ist, wird sie
ausgeschoben. Achten Sie darauf, die Disk
nicht fallenzulassen.
Aus Sicherheitsgründen wird eine nummerierte ID-Karte mit diesem Receiver mitgeliefert, und die
gleiche ID-Nummer ist auf dem Chassis des Receivers aufgedruckt. Die Karte muss an sicherer
Stelle aufbewahrt werden, da sie den Behörden bei der Identifikation des Receivers im Falle eines
Diebstahls helfen kann.
2
GE02-05_KD-G411[EY]f.indd 2 13/10/04, 5:44:10 PM
Inhalt
Zurücksetzen des Geräts........................ 2
Klangeinstellungen ................ 18
Zwangsweises Ausschieben einer
Wählen der vorgegebenen Klangmodi
Disk.................................................... 2
(C-EQ: Spezieller Equalizer) .............. 18
Wie Sie diese Anleitung lesen............... 4
Einstellen des Klangs............................. 19
Wie Sie die MODE-Taste verwenden ... 4
Allgemeine Einstellungen
Bedienfeld — KD-G411 ............. 5
— PSM................................. 20
Beschreibung der Teile.......................... 5
Grundlegendes Verfahren...................... 20
Erste Schritte .......................... 6
Abnehmen des Bedienfelds .... 22
Grundlegende Bedienung...................... 6
DEUTSCH
Abbrechen der Display
Verwenden der Fernbedienung
-Demonstrationen............................... 7
— RM-RK60............................ 23
Einstellung der Uhr................................ 7
Hauptelemente und Merkmale............... 23
Bedienung des Tuners ............ 8
Wartung ................................ 24
Rundfunkempfang ............................... 8
Speichern von Sendern .......................... 9
Weitere Informationen zu
Hören eines Festsenders ........................ 9
Ihrem Receiver .................... 25
UKW-RDS-Funktionen............. 10
Störungssuche........................ 27
Suche nach bevorzugten UKW-RDS
Technische Daten ................... 29
-Sendungen ..........................................
10
Speichern Ihrer Lieblingsprogramme.... 11
Verwenden des Standbyempfangs......... 11
Verfolgen des gleichen Programms
—Network-Tracking-Empfang.......... 12
Bedienung der Disk................ 13
Wiedergabe einer Disk ........................ 13
Weitere Hauptfunktionen ...................... 15
Ändern der Displayinformation............. 16
Auswählen von Wiedergabemodi.......... 17
*Für die Sicherheit....
*Temperatur im Auto....
• Die Lautstärke nicht zu laut stellen, da
Wenn Sie das Auto für lange Zeit in heißem
dadurch Außengeräusche überdeckt und das
oder kaltem Wetter parken, bitte warten, bis
Autofahren gefährlich wird.
sich die Temperatur im Auto sich normalisiert
• Das Auto vor dem Durchführen von
hat, bevor Sie das Gerät einschalten.
komplizierten Bedienschritten anhalten.
3
GE02-05_KD-G411[EY]f.indd 3 13/10/04, 5:44:12 PM
Wie Sie diese Anleitung lesen
Wie Sie die MODE-Taste verwenden
Die folgenden Methoden werden eingesetzt, um
Wenn Sie MODE drücken, schaltet de Receiver
die Erklärungen einfach und leichtverständlich
auf Funktion-Modus um, und die Zifferntasten
zu gestalten:
sowie die Tasten 5/∞ erhalten andere
• Einige zugehörige Tipps und Hinweise
Funktionen.
werden unter „Weitere Informationen zu
Ihrem Receiver“ gegeben (siehe Seite 25).
Beisp.: Wenn die Zifferntaste 2 als
• Tastenfunktionen werden im Wesentlichen
MO (Mono)-Taste fungiert.
mit den folgenden Abbildungen erläutert:
DEUTSCH
Kurz drücken.
Wiederholt drücken.
Eine davon drücken.
Zeit-Countdown-Anzeige
Um diese Tasten wieder für die
ursprünglichen Funktionen zu verwenden,
nachdem MODE gedrückt wurde, warten
Gedrückt halten,
Sie 5 Sekunden, ohne eine dieser Tasten zu
bis die gewünschte
drücken, bis der Funktion-Modus wieder
Reaktion beginnt.
aufgehoben ist.
• Durch erneutes Drücken von MODE wird der
Halten Sie die beide
Funktion-Modus ebenfalls aufgehoben.
Tasten gleichzeitig
gedrückt.
4
GE02-05_KD-G411[EY]f.indd 4 13/10/04, 5:44:12 PM
Bedienfeld — KD-G411
Beschreibung der Teile
Displayfenster
DEUTSCH
1 (Standby/Ein-Dämpfung)-Taste
;
4/¢ -Tasten
2 SEL (Wählen)-Taste
a
(Bedienfeld-Freigabe)-Taste
3 CD-Taste
s ∞ (Niedriger)-Taste / –10-Taste
4 FM/AM-Taste
5 Ladeschlitz
Displayfenster
6 Displayfenster
d Tuner-Empfangsanzeigen—MO (Mono),
7 0 (Auswurf)-Taste
ST (Stereo)
8 TP PTY (Verkehrsprogramm/Programmtyp)
f WMA-Anzeige
-Taste
g RDS-Anzeigen—TP, PTY, AF, REG
9 Fernbedienungssensor
h MP3-Anzeige
•
Sie können diesen Receiver mit einer
j CD-Anzeige
optional gekauften Fernbedienung steuern.
k Wiedergabemodus / Gegenstand-
• Setzen Sie den Fernbedienungssensor
Anzeigen—RND (Zufall),
(Disk),
KEINEM intensiven Licht (direkte
(Ordner), RPT (Wiederholung)
Sonneneinstrahlung oder künstliches Licht)
l LOUD (Loudness)-Anzeige
aus.
/ EQ (Equalizer)-Anzeige
p 5 (Höher)-Taste / +10-Taste
z Sound-Modus (C-EQ: spezieller Equalizer)-
q Regelscheibe
Anzeigen—ROCK, CLASSIC, POPS,
w Zifferntasten
HIP HOP, JAZZ, USER
e EQ (Equalizer)-Taste
•
fungiert auch als Zeit-Countdown-
r MO (Mono)-Taste
Anzeige.
t SSM (Sequentieller Speicher für starke
x Disk-Information-Anzeigen—TAG (ID3-
Sender)-Taste
Tag),
(Ordner), (Titel/Datei)
y RPT (Wiederholung)-Taste
c Hauptdisplay
u RND (Zufall)-Taste
v Quellenanzeige / Lautstärkepegelanzeige
i MODE-Taste
b Tr (Titel)-Anzeige
o DISP (Display)-Taste
5
GE02-05_KD-G411[EY]f.indd 5 13/10/04, 7:02:11 PM
