Beurer MC 4000: 4. Unit description

13

1

Neck cushion

5

Controls

9

Pedestal

2

Back rest

6

Leg rest

10

Cutout switch

3

Arm rest

7

Main switch

4

Seat cushion

8

Locking mechanism

4.  Unit description

External features

11

Massage rollers

Internal features

4

5

6

7

9

2

8

10

1

3

11

14

Controls

7

6

2

3

4

5

8

1

1

On/off button

5

Intensity of seat and calf air pressure massage

2

Up button

6

Relax button

3

Down button

7

Refresh button

4

Air button

8

Therapy button

Controlling button functions

On/off button

The controls are activated using the on/off button.

The display is illuminated when the massage chair is in operation.

In standby mode, the display flashes.

Up button

Pressing the up button raises the back rest and lowers the leg rest at the same time.

Acoustic signals sound during the motion.

w

 Upright position/flat position section

Down button

Pressing the down button lowers the back rest and raises the leg rest at the same time.

Acoustic signals sound during the motion.

w

 Upright position/flat position section

Air button

There are four settings for the air pressure massage:

•  low

•  medium

•  high

•  off

The currently selected setting is displayed.
