MOUNTING PRECAUTIONS

• This product is for use indoors.

• If it is difcult to provide sufcient space for any reason

ENGLISH

• A mounting bracket compliant with VESA specications is

such as the installation of the monitor inside a housing, or

required.

if the ambient temperature may be outside of the range

• Since the monitor is heavy, consult your dealer before

of 41°F (5°C) to 95°F (35°C), install a fan or take other

installing, removing or moving the monitor.

measures to keep the ambient temperature within the

• Mounting the monitor on the wall requires special expertise

required range.

and the work must be performed by an authorized SHARP

• Temperature condition may change when using the monitor

dealer. You should never attempt to perform any of this

together with the optional equipments recommended by

work yourself. Our company will bear no responsibility

SHARP. In such cases, please check the temperature

for accidents or injuries caused by improper mounting or

condition specied by the optional equipments.

mishandling.

• Do not block any ventilation openings. If the temperature

• Use the monitor with the surface perpendicular to a level

inside the monitor rises, this could lead to a malfunction.

surface. If necessary, the monitor may be tilted up to 20

• Do not place the monitor on a device which generates heat.

degrees upward.

• Do not use the product in locations where the unit is

• When moving the monitor, be sure to hold it with the

exposed to direct sunlight or other strong light. Since this

handles and the unit bottom. Do not grasp the screen or

product operates with infrared rays, such light may cause a

tray. This may cause product damage, failure, or injury.

malfunction.

• This monitor should be used at an ambient temperature

• When using multiple monitors closely, be sure the infrared

between 41°F (5°C) and 95°F (35°C). Provide enough

transmitter/receiver does not affect the other ones.

space around the monitor to prevent heat from

accumulating inside.

Unit: inch [cm]

7-7/8 [20]

1-7/16 [3.5]

2

2

[5]

[5]

2 [5]

Specications

Model PN-70TW3 PN-60TW3

Power requirement AC 100 V - 240 V, 2.7 A, 50/60 Hz AC 100 V - 240 V, 2.3 A, 50/60 Hz

Operating temperature

*

41°F to 95°F (5°C to 35°C)

Operating humidity 20% to 80% (no condensation)

Power consumption (Maximum) 235 W 190 W

Dimensions (excluding protrusions) inch (mm)

Approx. 64-13/16 (W) x 3-11/16 (D) x

Approx. 56-9/16 (W) x 3-11/16 (D) x

39-3/4 (H)

(1647 x 94 x 1010)

35

-1/16

(H) (1437 x 94 x 890)

Weight lbs. (kg)

Approx. 134.5 (61) Approx. 105.9 (48)

* Temperature condition may change when using the monitor together with the optional equipments recommended by SHARP.

In such cases, please check the temperature condition specied by the optional equipments.

As a part of our policy of continuous improvement, SHARP reserves the right to make design and specication changes for product improvement

without prior notice. The performance specication gures indicated are nominal values of production units. There may be some deviations from

these values in individual units.
