Festool PD 20: 9 Working with the machine

14

Q U A D R I L L

GB

8.3

Angle attachment [5]

The angle attachment (partly as an accessory) al-

lows the user to drill and fasten at right angles to

the machine.



Prior to initial use:

apply some multi-purpose

grease to the drill spindle and the gearbox neck.

8.4

Depth stop [6]

The depth stop (partly as an accessory) allows the

user to insert screws to a predefined depth. You can

set the dimension by which the screw head pro-

trudes above or is recessed below the surface of the

workpiece.

Depth setting

Turn the housing

[6-1]

 to set the

desired fastening depth. Each

detent position changes the fas-

tening depth by 0.1 mm.

Sleeve A/B must be removed before a screw can be

unscrewed.

8.5

Tool holder in the drill spindle [7]

Bits can be inserted directly into the hexagon sock-

et holder of the drill spindle.

9 Working with the machine

Please observe all mentioned safety infor-

mations and the following rules when work-

ing:

– Only use tools designed for the specified maxi-

mum speed.

– Only sharp tools ensure efficient drilling and pre-

vent machine overload.

– Always use faultless, sharpened HSS drill bits

(HSS: High Speed Steel) when drilling into metal.

– Do not cause the machine to seize through over-

loading.

– Always switch off the machine before placing on

the nut/screw.

– Caution: when inserting long screws, there is a

risk the bit may slip from the screw head and

cause injury.

– Machine vice: clamp the workpiece securely in a

machine vice, for example, before drilling to pre-

vent the workpiece from turning and causing ac-

cidents.

9.1

Bit depot [1-1]

Magnetic, for storing bits and bit holders.

9.2

Belt clip [1-9]

The belt clip (right/left) allows the user to attach

the machine briefly to work clothing.

9.3

Lighting

ON: Press the LED light switch

[1-3]

.

OFF: Press the LED light switch

[1-3]

 again.



The light remains switched on for approx. 20 s

after the machine is disconnected from the

mains power.

9.4

Warning signals

Acoustic warning signal

An acoustic warning signal sounds and the ma-

chine switches off in the following operating states:

Visual warning signal

A visual warning signal is issued and the machine

switches off in the following operating states:

10 Service and maintenance

Customer service and repair

 only

through manufacturer or service

workshops: Please find the nearest

address at:

www.festool.com/Service

Use only original Festool spare parts!

Order No. at:

www.festool.com/Service

To ensure constant air circulation, al-

ways keep the cooling air openings in

the motor housing clean and free of blockages.

Machine overloaded.

LED

[1-3]

Red - flashing

Machine has overheated.

Press the Speed set button

[1-

4]

 to switch the machine to

recovery mode.

Do not place

under load

! The machine

reverts to normal operating

mode once the machine has

cooled, if the Speed set button

or on/off switch are pressed or

the machine is placed under

load.

WARNING

Risk of injury, electric shock



Always disconnect the mains plug from the

socket before performing maintenance work on

the machine!



All maintenance and repair work which requires

the motor housing to be opened must only be

carried out by an authorised service workshop.

peep peep peep
