Fagor 6H-750BE: Safety

e n g l i s h

19

Instruction manual

Important! Read the entire manual before using the oven. The documentation and accessories are

inside the oven.

The texts in the manual correspond to the numbered diagrams.

Safety

•  The electrical installation that feeds the oven must have circuit

breakers installed in accordance with current local installation

regulations.

•  The oven must be installed by an authorised installer in

accordance with the manufacturer’s instructions and diagrams.

•  The electrical installation must be dimensioned for the

maximum power indicated on the reference plate and the

electrical socket must have a regulatory earth connection.

•  If the power cord is damaged, it must be replaced by the after-

sales technical service or by similarly qualifi ed staff, to avoid

hazard.

•  Ensure the appliance is unplugged from the mains before

replacing the oven lamp, to avoid electric shock.

•  Do not use abrasive cleaning products or metal scouring pads

to clean the oven door, as they could scratch the surface and

cause the glass to shatter.

•  During operation, some accessible parts may become hot.

Children under the age of 8 must not go near the appliance

unless under permanent supervision.

•  Do not touch the heating elements inside the oven.

Important

  Keep this manual with the appliance. If you sell or give the

appliance to another person, make sure you also pass on

the user manual. Read these instructions carefully when

using and installing the appliance. They are designed to

protect your own and others’ safety.

20

e n g l i s h

•  This appliance can be used by children aged from 8 years

and above and persons with reduced physical, sensory or

mental capabilities or lack of experience and knowledge if they

have been given supervision or instruction concerning use

of the appliance in a safe way and understand the hazards

involved. Children shall not play with the appliance. Cleaning

and user maintenance shall not be made by children without

supervision.

•  This appliance is designed for normal household use only.

Do not use it for commercial or industrial purposes. Use

exclusively for cooking food products.

•  Do not try to modify the characteristics of the appliance. It

could be dangerous.

•  During cleaning by pyrolysis, surfaces become hotter than

during normal use. Keep out of reach of children.

•  Before cleaning with pyrolysis, remove all cooking items and

signifi cant overfl ows.

•  Do not put heavy weights on the oven door and make sure

that children do not climb or sit on it.

•  Always make sure that the oven is switched off before

cleaning.

•  After using the oven, make sure that all the controls are in the

off position.

•  Do not use the oven as a larder or to store accessories after

use.

•  Do not use steam or high pressure devices to clean the device

(electrical device safety reasons)

•  The oven door should always be kept closed when working,

for all programmes, including the grill.

21

e n g l i s h

1 2

Installation

Using the oven

1.1 Unpacking.

 Remove all the protective

packaging elements.

1.2 Mains connection.

Always take into account

the data on the reference plate (1.2.1) and

the measurements of the cabinet the oven

will be housed in (1.2.2, 1.2.3).

The appliance must be connected to the

mains with a fi xed single-phase connection

with the neutral-to-neutral (blue) connection

guaranteed (1.2.4). Fit the oven into the

space and centre it (1.2.5). Make sure there

is no excess cable in the upper part (1.2.6).

Screw it to the fi tting using the two screws

supplied (1.2.7). The fi tted furniture or its

surface must be heat-resistant. The time

must be set in order to fi nish the installation.

After a period of inactivity, the machine

will turn to standby and its brightness

will diminish or the screen will switch off,

depending on the model.

2.1  Adjusting the time.

When the oven is

switched on, the clock will fl ash (2.1.1).

Adjust the time by pressing the

,

buttons (2.1.2). After a few seconds, or if

the

button is pressed, the time will be

validated.

Note:

 In case of a power cut,

adjust the time again when the power

returns.

2.2  Changing the time

 .

With the oven

switched  off, hold down the

button until

the time starts to fl ash (2.2.1). Adjust the time

by pressing the

,   buttons (2.2.2). After a

few seconds, or if the

button is pressed,

the time will be validated.

2.3 Beeper function   .

Press the

button

until position

is reached (2.3.1). Adjust the

time using the

,   buttons (2.3.2). After a

few seconds, or if the

button is pressed,

the time will be validated and the countdown

will begin. When it is complete, a beep will

sound. Press any button to stop the beeper

(2.3.3).

2.4

Before using your new oven for the fi rst

time, heat it up while empty

 (with no food

in it and with the control turned to

 , for

30 minutes at 250ºC). It may produce some

smoke or a bad smell (this is normal and is

caused by the oven heating up grease residue

etc.). When it has cooled down, pre-clean it

by wiping the inside with a damp cloth.

2.5 Accessories.

Depending on the model

there is a Deep Tray (2.5.1), Flat Tray (2.5.2)

and Multifunctional Grill (2.5.3) that work

separately. If it also possible to combine

either tray with the Multifunctional Grill

(2.5.4) to make a set. All the accessories

or sets can be used directly or mounted

on the Partial Extraction Grill (2.5.5) or the

Total Extraction Grill (2.5.6, 2.5.7), (2.5.8).

If you have the partial extraction tray, it can

be used separately or together with trays

(3 types) (2.5.9). The Simple Grill is used

separately (2.5.10). If you have telescopic

rails, remove the tray before installing them in

the oven (2.5.11). The telescopic rails extend

automatically due to the weight of the tray

when the oven is opened (2.5.12). Food must

always be placed on a tray on the telescopic

rails (2.5.13). Bear in mind the position of the

grills when installing them. There are anti-

tipping stops at the sides (2.5.14).

2.6 Accessory positions.

 The accessories

can be fi tted in 5 different positions

.

2.7  Cooking the food.

Place the food in the

oven. Choose the accessory or accessories

to be used and their recommended position,

or consult the cooking table. Close the oven

door.

COOKING

2.8  Selecting the cooking function

. Turn

the function selector

 and select the

desired function according to the model.

Traditional fanned heat.

For any kind of

dish. Several dishes may be cooked at once

without their fl avours or smells mixing.

Turbo plus.

 The heat is produced by the

central element.

Fanned high grill.

This browns the food,

distributing the heat evenly. Ideal for large-

sized roasts.

High grill.

For browning pasta, souffl és and

bechamel sauce.

Low grill.

 For hamburgers, toast and food

with a small surface area.

High base heat.

The heat from the oven

base is evenly distributed. Ideal for paellas or

pizzas.

 Traditional  heat.

For bread, cakes, cakes

with fi lling and lean meat.

Defrost.

 Rapidly thaws any kind of food.

e n g l i s h

22

2.9  Selecting the temperature.

Turn the

temperature selector dial

 to the desired

setting.

2.10 Switching off the oven.

When the cooking

process is complete, turn the function and

temperature selector dial to 0. (2.10.1)

(2.10.2).

TIME FUNCTIONS

2.11 Selecting the cooking duration

 .

Select the desired cooking function and

temperature. Press

 until position

is

reached (2.11.1). Adjust the cooking time by

pressing the

,   buttons (2.11.2). After a

few seconds the time will be validated and

the countdown will begin (2.11.3). When the

cooking process is complete the oven will

emit a series of beeps. Press any button to

stop the beeps and switch off the oven.

2.12 Selecting the end time

 :

 Select the

cooking function, the temperature and the

duration

. Press

 until position

 is

reached (2.12.1). Adjust the end of cooking

time by pressing the

,   buttons. After a

few seconds it will be validated and oven

switch-on will be delayed so that it stops

at the time indicated (2.12.2). When the

cooking process is complete, the oven will

emit a series of beeps. Press any button

to stop the beeps and switch off the oven

(2.12.3).

2.13 Celeris Function.

 For pre-heating the oven.

Turn the function selector dial to

 and

enter the desired temperature (2.9). The oven

will quickly reach the temperature selected.

When it has been reached, place the food

inside the oven and select the cooking

function and cooking time required.

3

Maintenance and

cleaning

3.1  Cleaning the accessories.

The accessories

are dishwasher-safe. To wash them up by

hand, use ordinary detergent. Leave them to

soak for easier cleaning.

3.2 Pyrolysis cleaning.

• The cleaning process consists of the dirt

being burnt at high temperatures.

• The smoke and smells are eliminated by a

catalyser.

• There is no need to wait until the oven has

accumulated a large amount of grease to

perform the cleaning process.

• After pyrolysis, when the oven has cooled

down, wipe it with a damp cloth to remove

the white ash residue.

• Before starting the pyrolysis process,

take all the accessories out of the oven,

including the cooking accessories and the

telescopic runners.

• If any substances are stuck to the inside of

the oven due to spill-overs, remove them

before carrying out the pyrolysis process

as they could catch fi re or give off large

amounts of smoke.

• During the pyrolysis process the surfaces

become hotter than during normal use.

Keep children away from the oven.

Depending on how dirty the oven is, you can

choose between two types of pyrolysis.

Pyrolysis

 :

 This type of pyrolysis should

only be used when the oven is very dirty. The

cleaning process takes 2 hours. To activate

it, turn the function selector dial

 to

(3.2.1,3.2.2).

Note:

 Pyrolysis cleaning is possible with this

option, with the enamelled tray accessory.

Place it at level 2. First remove the excess

grease accumulated.

ECO pyrolysis

 :

 The cleaning process

takes 1 hour 30 minutes. To activate it, turn

the function selector

 to

(3.2.3, 3.2.4).

Note:

 The time and temperature parameters

are set parameters and cannot be altered.

  When the process begins, the oven reaches

very high temperatures, the door safety lock

is activated and the pilot light beside the

symbol comes on (3.2.5). When the oven has

cooled down, the pilot light switches off and

the door can be opened.

3.3  Cleaning the inside walls.

Take out the side

runners and clean off any grease or ash that

has been left after the cleaning processes.

Depending on the models, the side runners

are fi xed in two ways, either without a

support (3.3.1, 3.3.2) or with a support

(3.3.4, 3.3.5). When you have removed them,

use a damp cloth to clean the side walls

(3.3.3, 3.3.6). When you have cleaned the

oven walls, replace the runners. If your oven

has a fold-down grill, pull upwards and press

to fold it down (3.3.7) and clean the top wall

with a damp cloth (3.3.8).

3.4  Cleaning the glass.

e n g l i s h

23

4

Troubleshooting

You can solve the following problems yourself:

4.1  The oven is not heating up.

Check it is

plugged in and switched on and that the fuse

has not blown. Select a higher temperature

setting.

4.2 The interior light is not working.

Change the

bulb or replace the fuse.

4.3 Smoke is coming out during cooking.

Turn

the temperature down and/or clean the oven.

Cleaning the outside of the glass:

 Use a

soft cloth soaked in a glass cleaning product.

Cleaning the inside of the glass:

 If the

inside of the glass is dirty, you can remove it

for cleaning.

When the oven has cooled down, open the

door as wide as possible (3.4.1) and fi x it

in place with the red stop supplied in the

accessories bag (3.4.2). Use the remaining

sheet accessory on one side of the glass to

raise up the glass like a lever. Do the same on

the other side of the glass. Remove the red

stop and close the door (3.4.3). Remove the

glass (3.4.4), clean it and dry it with a cloth

(3.4.5). If necessary, remove the whole glass

panel unit inside the door. This unit consists

of either one or two glass panels, depending

on the model, with a black stop in each

corner. To remove them, place your hand

under the door and pull upwards (3.4.6).

When you have taken out the unit, remove

the stops to clean the glass panels (3.4.7).

When the glass panels are clean (3.4.8) fi t

them onto the rubber stops again, with the

stud facing upwards (3.4.9) and replace the

glass panels so that the letters “L” (left) and

“R” (right) are beside the hinges (3.4.10).

Lastly, place the remaining glass panel so

that the word PYROLYTIC can be read

(3.4.11). Remove the stops (3.4.12) and

close the door.

 Warnings:

•  Make sure the oven is switched off.

•  Allow the glass to cool down before

removing it.

•  Never use steam cleaning machines.

3.5  Cleaning the outside of the oven.

 Use

neutral cleaning products. Dry the oven well

with a soft cloth.

4.4 The pyrolysis cleaning process is not being

carried out.

Ensure the door is correctly

closed. Locking system or temperature

sensor failure. Call the Technical Service.

4.5 A beep is sounding.

The selected

temperature setting has been reached. The

cooking cycle is complete.

4.6 The oven makes a noise after cooking.

This

is normal, as the fan keeps running until the

temperature inside and outside the oven is

reduced.

4.7 Failure warnings.

 Temperature sensor failure.

  Do not try to repair the oven yourself.

Call

the technical assistance service.

5

The Environment

This oven has been designed with

environmental protection in mind.

Respect the environment.

 Only preheat the

oven when necessary (see table). Use dark

coloured cake tins whenever possible. For

long cooking times, switch off the oven 5 or 10

minutes before the end of cooking time.

Management of waste electrical and

electronic equipment.

The symbol

 indicates that the appliance must

not be disposed of in traditional bins for domestic

waste.

Take your oven to the a special collection centre.

Recycling domestic appliances will prevent

negative consequences for health and the

environment and will allow savings on energy and

resources.

For further information, contact the local

authorities or the shop where you bought the

oven.

e n g l i s h

24

Cooking Table

lamb 1,2 Kg

turkey 4 Kg

Food

beef 1,5 Kg

190º C

150º C

200º C

170º C

210º C

190º C

200º C

210º C

220º C

200º C

210º C

50 - 60 min

no

no

no

no

no

no

no

yes

yes

yes

no

85 - 95 min

40 - 50 min

115 - 125 min

50 - 60 min

30 - 40 min

15 - 19 min

7 - 9 min

4 - 5 min

18 - 22 min

180º C

220º C

190º C

230º C

210º C

220º C

230º C

240º C

220º C

pizza

roasted red

peppers

1,25 Kg

baked hake/

baked cod

1,5 Kg

pork 1,5 Kg

stuffed toma-

toes 4 servings

roasted

lobster

1 Kg

8.4.1 Butter

cookies

9.1 Surface

browning

8.4.2 Fairy

cakes

8.5.1 Fat-free

sponge cake

8.5.2 Apple tart

chicken 1,25 Kg

defrosting, all

types of food

Programme and

temperature

Time

Position Preheat

Accessories

meat and poultry

vegetables

fi sh and seafood

sundry

PERFORMANCE TESTING ACCORDING TO

ST

ANDARD IEC/EN60350

40º C

-

50ºC

no

Fermenting

dough for

bread/cakes

yes

Pre-heat

for 5 min

yes

no

no

no

no

no

Deep Tray

Cook 2-3 min.

on grill

Deep Tray

Mould on grill

Grill

Deep Tray/

standard

2 moulds on 1

grills and deep

2 moulds on 1

grills and deep

25 - 30 min

1

2

2

2

2

2

4

3

3

2

2

1

2

1

1

1

3

1

3

1

3

1

0

175º C

40º C

-

50ºC

*

 Depending on the model.

75º C

22 min

185º C

21 min

180º C

28 min

185º C

40 min

*160º C

35 min

*180º C

50 min

*180º C

65-70 min

2-3 min

*275º C
