Scarlett SL-MC411S01: инструкция
Характеристики, спецификации
Инструкция к Мультиварке Scarlett SL-MC411S01
IM012
2 SL-MC411S01
www.scarlett-europe.com
GB DESCRIPTION
RUS УСТРОЙСТВО ИЗДЕЛИЯ
1. Hinged Lid
2. Steam Outlet
3. Lid Open Button
4. Control Panel
5. Handle
6. Case
7. Power Cable Socket
8. Power Cord
9. Wire Rack
10. Measuring Cup
11. Ladle
12. Spoon
13. Bowl
1. Откидная крышка
2. Клапан для выхода пара
3. Кнопка открытия крышки
4. Панель управления
5. Ручка
6. Корпус
7. Разъем для шнура питания
8. Шнур питания
9. Решетка пароварки
10. Мерный стаканчик
11. Половник
12. Ложка
13. Чаша
CZ POPIS
BG ОПИСАНИЕ
1. Odklopné víko
2. Odpařovací otvor
3. Tlačítko pro otevírání víka
4. Ovládací panel
5. Držák
6. Těleso
7. Konektor pro napájecí kabel
8. Napájecí kabel
9. Mřížka parního hrnce
10. Odměrka
11. Naběračka
12. Lžíce
13. Mísa
1. Отварящ се капак
2. Отвор за излизане на пара
3. Бутон за отваряне на капака
4. Панела за управление
5. Дръжка
6. Корпус
7. Разклонител за захранващия кабел
8. Захранващ кабел
9. Решетка на уреда за готвене на пара
10. Мерна чаша
11. Черпак
12. Лъжица
13. Чаша
UA ОПИС
SCG ОПИС
1. Відкидна кришка
2. Отвір для виходу пари
3. Кнопка відчинення кришки
4. Панель управління
5. Ручка
6. Корпус
7. Роз’єм для кабелю живлення
8. Кабель живлення
9. Решітка пароварки
10. Мірна склянка
11. Половник
12. Ложка
13. Чаша
1. Преклопни поклопац
2. Излаз за пару
3. Дугме за отварање поклопца
4. Контролна плоча
5. Ручка
6. Кућиште
7. Утичница за кабл
8. Кабл
9. Носач кабла
10. Мерна шоља
11. Кутлача
12. Кашика
13. Чинија
EST KIRJELDUS
LV APRAKSTS
1. Liigendkaas
2. Auru väljaviik
3. Kaane avamisnupp
4. Juhtpaneel
5. Käepide
6. Korpus
7. Toitejuhtme pesa
8. Toitejuhe
9. Traatraam
10. Mõõtetass
11. Kulp
12. Lusikas
13. Kauss
1. Paceļams vāks
2. Tvaika izvadīšanas atvere
3. Vāka atvēršanas poga
4. Vadības panelis
5. Rokturis
6. Korpuss
7. Barošanas vada spraudnis
8. Barošanas vads
9. Tvaicēšanas režģis
10. Mērglāze
11. Smeļamkauss
12. Karote
13. Trauks
LT APRAŠYMAS
H LEÍRÁS
1. Atlenkiamasis dangtis
2. Garų išėjimo anga
3. Dangčio atidarymo mygtukas
4. Valdymo pultas
5. Rankenėlė
6. Korpusas
7. Išėma maitinimo laidui
8. Maitinimo laidas
9. Garų puodo grotelės
10. Matuoklė
11. Samtelis
12. Šaukštelis
13. Indas
1. Lehajtható fedél
2. Párakieresztő nyílás
3. Fedélnyitó gomb
4. Vezérlőpad
5. Fogantyú
6. Készüléktest
7. Vezeték-csatlakozó
8. Vezeték
9. Gőzfőzőrács
10. Mérőpohár
11. Merítőkanál
12. Kanál
13. Főzőedény
IM012
3 SL-MC411S01
www.scarlett-europe.com
KZ СИПАТТАМА
SL STAVBA VYROBKU
1. Көтермелі қақпақ
2. Бу шығатын саңылау
3. Қақпақты ашатын түймешік
4. Басқару панелі
5. Тұтқа
6. Корпус
7. Қуат сымына арналған ағытпа
8. Қуат сымы
9. Бу қасқанның торы
10. Өлшер стақан
11. Ожау
12. Қасық
13. Шара
1. Odkladacie veko
2. Otvor na vypúšťanie pary
3. Tlačidlo na otvorenie veka
4. Ovládací panel
5. Rukoväť
6. Pevná časť hrnca
7. Prívod pre napájací kábel
8. Napájací kábel
9. Mriežka na jedlá na pare
10. Odmerná nádoba
11. Naberačka
12. Lyžica
13. Misa
220-240 V~ 50 Hz
800 W
4 L
3.4/4.5 kg
mm
195
370
270
GB SAFETY MEASURES
Important safety instructions. Please read carefully and save for future reference.
Incorrect use of the device may damage the device and harm the user.
Before switching on the appliance for the first time please check if the technical specifications indicated on the
unit correspond to the mains parameters.
CAUTION! The plug of the power cord is grounding type and has a wire. Plug the device only into the
corresponding grounded sockets.
Use the device only for household purposes and in accordance with this Operating Manual. The device is not
intended for industrial use
Do not use outside.
Always unplug the device from the socket before cleaning the device or if You are not using the device.
The device may not be used by persons (including children) with underdeveloped physical, mental and sensual
abilities when these persons do not have the experience or the knowledge or if they are not supervised or guided
by a person who is responsible for their safety.
Children should be supervised at all times and should never play with the device.
Do not leave switched-on device unattended.
Do not use the parts which are not included in the package.
Do not use the device if the power cord or/and the plug are damaged. To avoid danger the damaged cord should
be replaced by an authorized service center.
Do not submerge the device or the power cord in water or other liquids. However, if this happened unplug the
device from the socket immediately and before using the device again have qualified specialists check the
operability of the device.
Make sure that the power cord doesn’t touch sharp edges and hot surfaces.
Do not pull the power cord and do not twist or wrap the cord around the device.
The multicooker is to be used only for cooking food. Never use the multicooker for drying clothes, paper and
other items.
Do not turn the multicooker when the pot is empty.
Do not use the multicooker without the pot.
Do not put the foodstuffs on the bottom of the multicooker, always use the pot.
Do not replace the pot with any other container.
Do not use metal items which may scratch the pot.
The inner coating of the pot may initially wear off, therefore be careful when using the pot.
Follow cooking recipes.
Do not let water get into the vent holes in order to avoid short circuit.
If using an extension cord make sure that maximum capacity of the cord corresponds to the capacity of the
device.
Caution! The device becomes hot during operation! If you need to touch the multicooker when it is operating use
tacks or cooking gloves.
Protect Your face and hands from the steam coming out of the valve.
Do not insert metal and other items into the outlet hole or into any other parts of the device.
Do not cover the cover of the multicooker with the towels or other items.
If the product has been exposed to temperatures below 0ºC for some time it should be kept at room temperature
for at least 2 hours before turning it on.
The manufacturer reserves the right to introduce minor changes into the product design without prior notice,
unless such changes influence significantly the product safety, performance, and functions.
INSTALLATION
Make sure that there is no packaging material or any other items inside the multicooker.
Check whether the following remained undamaged during the transportation: the cover; the casing; additional
appliances; the removable pot.
In case you notice any defects do not turn on the device and contact the salesperson or the service center.
Place the device on a dry, even and heat-proof surface. Do not place the device close to combustible materials,
explosives and self-igniting gases. Do not place the device close to a gas or electric stove or any other sources
of heat. Do not place the device very close to walls or furniture.
Do not put anything on top of the multicooker. Do not cover the vent holes.
Do not place the multicooker in a kitchen cabinet. For proper operation the device needs free space for
ventilation: at least 20 cm from the top, 10 cm from the back and 5 cm from the sides.
Before first use wipe the removable pot, the steamer, the measuring cup, the spoon, the inside and the outside
surface of the multicooker with a clean wet cloth.
The inside surface of the pot contains a conventional scale for cereal and water: the scale on the right marks the
number of cups for rice, the scale on the left marks liters of water. The maximum amount of cereal to be cooked
– 8 cups and 1.5 liters of liquid.
OPERATION
Before initial use, wipe the cooking pot, the surface of heating element and internal surface of the universal
cooker.
Put water and food in the cooking pot. DO NOT fill the cooker more than to 3/5 of its capacity. During cooking
food products that expand in hot water (rice, dry vegetables) or foam, do not fill the pot more than to the half of
its capacity. At that, the entire volume of food products and water should not exceed 1/5 of the total pot capacity.
www.scarlett-europe.com 4
SL-MC411S01
- 1
- 2
