Fagor B-515M: •

7

1.

 On/off

switch

2.

 Turbo

button

3.

 Motor

casing

4.

 Mixer

base

5.

 Blade

6.

 Plug

cable

7.

 Speed

control

8.

 Whisk

coupling

9.

 Whisk

10.

 Chopper lid

11.

 Chopper bowl

12.

 Chopper blade

13.

 Graduated jug

14.

 Removal button

Voltage:

230V 50Hz

•

Please read this manual carefully before

using the blender for the first time and

keep it handy for any later consultation.

This will ensure that you obtain the best

results with the maximum safety.

•

Before using the blender check that the

mains voltage is the same as that shown

on the blender.

•

If the electricity socket and the blender

plug are incompatible, change the

socket for a suitable one by contracting

a professionally qualified electrician.

•

We do not advise you to use adapters,

plugs or extension cables. If such a

device is indispensable, use only single

or multiple adapters and extension

3. SAFETY WARNINGS 2. TECHNICAL DATA 1. DESCRIPTION OF THE BLENDER  (Fig.1)

cables that comply with current safety

standards, taking care not to surpass the

capacity shown on the adapter and/or

the extension cable.

•

After unpacking, check that the blender

is in a perfect condition; if in doubt,

contact the nearest Service Centre.

•

The packaging (plastic bags, polystyrene

foam, etc.) should not be left within

reach of children, as it is a potential

source of danger.

•

This blender should be employed solely

for domestic use. Use for any other

purpose is considered inadequate and

dangerous.

•

In the event of the blender breaking

down or malfunctioning, switch it off and

do not attempt to repair it.

•

If the blender needs repairing, only

use a Service Centre authorised by the

manufacturer and request that original

spares are used. If this advice is not

followed, the safety of the blender may

be compromised.

•

Do not change the cable. If it is broken

or needs to be changed, contact a

Service Centre authorised by the

manufacturer. Do not use the blender

when the cable or plug is damaged.

•

The manufacturer will not be liable

for any damage that may arise from

inappropriate, erroneous or improper use

or from repairs carried out by unqualified

persons.

When using any electrical appliance,

certain fundamental rules must be

followed.

ESPECIALLY

•  Do not touch or pull the cable with wet

or damp hands or feet.

•

To prevent electric shocks, do

not immerse the appliance or the

cable or the plug in water or put

it under the tap.

•

Do not touch the blade whilst the

blender is in operation.

•

The whisk should be fitted or removed

only when the appliance is unplugged.

•

Do not allow the cable to hang over the

edge of a table or work-surface or to

EN

B-415 P

400 W

 B-515

M

 B-575

MA

500 W

 B-615

M

 B-675

MA

600 W

positioning marks and pressing it into the

motor body

(3)

until you hear a click.

 (Fig.2)

NOTE:

 To remove the blender stem, press

the removal button

(14)

.

After adjusting the blender stem

(4)

, plug in

the appliance. Place the food you wish to

blend in a suitable container, and position

the blender as shown in

figure 7

. Press the

On/Off switch

 (1)

. On models B-615M and

B-675 MA, select the speed by turning the

speed controller

 (7)

. If you wish, you may

press the turbo button

(2)

 to blend at top

speed.

IMPORTANT: Do not use the plastic

blender stem (model B-415 P only) to

blend any food at a temperature of over

60ºC.

Egg white beating function (mod.

B-575MA, B-675MA)

Insert the egg white beater into the blender

coupler until it fits into place

 (fig.5)

. Then

fit it to the blender body by aligning the

positioning marks and pressing it in until

you hear a click

 (fig. 6

). Place the blender

in the container, plug in the appliance and

press the On/Off button to start beating

the egg whites. Use the speed controller to

select a speed (models B-615M and B-675

MA), or press the turbo function button.

You may use the glass

 (13)

 or another type

of container for beating the egg whites.

Mincing function (mod. B-575 MA, B-675 MA)

The mincer can be used for fruit and nuts,

herbs, boiled eggs, dry bread, etc.

Place the mincer blade

(12)

 in the centre of

the bowl

(fig. 3)

. Place the ingredients you

wish to mince in the mincer bowl.

Place the mincer lid

(10)

 on the mincer jug,

making sure it is correctly aligned with the

mincer blade. Insert the motor body

 (3)

 in

the mincer lid

(3)

 by aligning the positioning

marks and pressing it in until you hear a

click

(Fig. 4)

. Plug in the appliance and

press the On/Off button. Use the speed

controller

(7)

 to select a speed (models

B-615M and B-675 MA only) or press the

turbo button

(2)

 for quicker mincing. When

you have finished mincing the food, make

8

come into contact with hot surfaces.

•

Do not pull the cable to unplug the

appliance.

•

Unplug the blender when it is not in use,

before fitting or removing the mixer base

and before cleaning it.

•

Do not allow children to use the

appliance.

•

Before connecting the blender, ensure

that the mixer base is correctly fitted to

the appliance.

•

Do not use or place any part of the

blender on or near to hot surfaces (gas

or electric hotplates or ovens).

•

This appliance should not be used

by physically, sensorially or mentally

handicapped people or people without

experience or knowledge of it (including

children), unless they are supervised or

instructed in the use of the appliance by

a person responsible for their safety.

•

Children should be watched to ensure

they do not play with the appliance.

•

For greater protection, we recommend

installing a residual current device (RCD)

with an operational residual current not

exceeding 30 mA. Ask your installer for

advice.

Preparing for use

This blender is designed to process small

quantities of foodstuff and should not be

used for any other purpose.

Before using for the first time, clean the

casing of the motor with a damp cloth.

Wash the shaft and the blade in hot, soapy

water; do not immerse the upper part of the

shaft. Dry all the pieces thoroughly.

IMPORTANT: Before fitting or removing any

of the parts of this blender, unplug it from

the mains.

Blender function

The blender can be used to blend

light foods, for making sauces, soups,

mayonnaise or puree, for example. Insert

the blender stem

(4)

 by aligning the

4. OPERATION
