Instruction manual

Very important: Please read this manual fully before using your refrigerator.

This manual has been designed so that the text is linked to the relevant drawings.

Installation

Identify the model of your refrigerator

(“

a

”, “

b

”,

“

c

”, “

d

”) by comparing the control panel with the

illustrations.

1.1 Unpacking.

 Remove all the protection.

1.2 Location.

Position the refrigerator away

from heat sources and protected from direct

sunlight to reduce consumption.

Do not install the refrigerator outside or

anywhere it is exposed to rain.

Air must be able to circulate around the back

of the refrigerator. Leave 25 mm between the

back of the refrigerator and the wall behind

it. Do not block the space between your

refrigerator and the fl oor or ceiling with any

object.

Level the refrigerator to prevent any vibrations

or noise. Remember that if the refrigerator

is located next to a wall or cabinet, it might

make a small noise.

Also check that the shelves have been fi tted

correctly, and place containers apart to

prevent any vibrations.

1.3 Electrical connection.

Stand the refrigerator

upright for at least 2 hours before plugging it

in. Check the information on the specifi cations

plate (220-240V earthed) (1.3.1, 1.3.2).

Do not use any adapters or extension leads.

Make sure that the lead is not touching the

motor or trapped underneath it.

1.4  Changing the direction the door opens.

Unplug the refrigerator from the mains supply

and empty it completely.

Gently lay the appliance on its back (1.4.1).

Undo the screws (1.4.2) and remove the top

hinge and the rotating bushing with the aid of

a screwdriver (1.4.3).

0

Identifi cation

e n g l i s h

Unplug by pressing on the connector tab

(1.4.4). Remove the refrigerator door (1.4.5).

Remove the control panel, levering it up

by inserting a screwdriver in the notches

provided for that purpose (1.4.6).

Make a notch for the lead on the other side,

in the area indicated on the casing (1.4.7).

Replace the control panel passing the lead

through the notch made (1.4.8).

Undo the screws from the bottom hinge and

remove it. Change the position of the pin in

the hinge and position it on the other side

(1.4.9).

Remove the vertical handle and fi t it on the

other side of the door turning it 180º (1.4.10).

Fit the door (1.4.11).

Fit the closing capsule in the top hinge

space on the other side (1.14.12). Press the

connector to plug it into the door (1.4.13).

Fit the top hinge and the rotating bushing,

inserting any spare lead in the control panel

(1.4.14) and replace the screws (1.4.15).

Lift the refrigerator up carefully (1.4.16).

1.5  Levelling the appliance.

Adjust the feet so

that it is tilting backwards slightly, to help the

door close correctly (1.5.1).

2.1  Switching on the refrigerator.

Press the

button (2.1.1) or (2.1.2). Press    ,   until

a digit appears on the display (2.1.3) or turn

the control (2.1.4). In models

c

 and

, the “on” LED will come on to indicate that

the appliance is switched on.

The child lock is automatically activated in

model

a

, to release it press the   button

for 3 seconds (2.3.10). Models

b

,

c

and

 do not have the automatic lock

function.

2.2  Setting the temperature.

Press the

,

 buttons (2.2.1, 2.2.2). Press    ,

 (2.2.3), or turn the control (2.2.4). Once

you have set the temperature required,

you can fi nd out the actual temperature by

pressing the

 or

 (2.2.5, 2.2.6),

2

Use

e n g l i s h

14

or

 (2.2.7) buttons for fi ve seconds. The

temperature will fl ash. Model

 does not

have this function.

 Recommendation:

 The recommended

temperature for your refrigerator is

degrees. It is best to always keep it between

 and

 degrees.

Remember that the temperature inside

the refrigerator depends on the ambient

temperature, the location and how often the

refrigerator door is opened.

2.3 Refrigerator functions.

Fast cooling function:

This function sets the

refrigerator to the coolest temperature for 6

hours. It is recommended that you activate

this function when you put a large amount

of food into the refrigerator. To activate

and deactivate it: Press

 (2.3.1, 2.3.2) or

 (2.3.3, 2.3.4), in model

c

 the

display will show

 whilst the function is

activated.

 Holiday

function:

 Ideal for when you

are away from home for a long time. The

refrigerator will remain set at

   degrees,

preventing any bad smells from developing

and keeping electricity consumption very low.

To activate holiday mode:

 Models

a

 and

c

: Press the    or

 button

until   appears on the display (2.3.5,

2.3.7).

 Model

b

 : Press the   button until

appears on the display (2.3.6).

 is displayed on the screen while the

option is active. Model

 does not have

this option.

To disable holiday mode:

 Models

a

 and

c

: Press the   or

button until the desired temperature appears

on the display.

 Model

b

 : Press the    button until the

desired temperature appears is displayed.

Warning:

 For the holiday function to work

correctly, the refrigerator door must be

closed.

setting:

 This helps you to economise

by better preserving foods. Activate or

disable by pressing the

 button and

appears on the screen (2.3.8, 2.3.9). Models

c

 and

 do not have this option.

 Child

lock:

 Ideal for preventing changes

being made inadvertently to appliance

settings or children from interfering with

them. The screen will display the   icon

whilst the child lock is activated. Press

(2.3.10) or   (2.3.11). The screen will show

 or

 alternating with the normal display

whilst the function is activated. Models

b

and

 do not have this option.

2.4  Arranging food in your refrigerator.

The

temperature is not uniform inside your

refrigerator. Some areas are colder than

others. Food must be stored in the right area

to make sure that it is kept correctly (2.4.1):

1.

 Butter.

2.

Hors d’oeuvres, cheese, yoghurts, cream,

sauces, eggs.

3.

Bottles, milk.

4.

Meat, poultry, game and fresh fi sh, cooked

meats.

5.

Pulses and vegetables.

6.

Vacuum box (accessory).

7.

Ice maker (accessory).

2.5 ICE MAKER.

This is an accessory in your

refrigerator that can generate up to 20 cubes

of ice. If you have an Ice Maker, take it out

of the refrigerator (2.5.1). Remove each of

the 5 ice-trays inside (2.5.2) and fi ll them

with water (2.5.3). Put the ice-trays back

trying not to spill any water (2.5.4). Put your

Ice Maker carefully back into place inside

the refrigerator (2.5.5). The ice cubes will be

ready for use in 24 hours.

2.6  Switching the refrigerator off.

Press   for

3 seconds or press

 until no temperature

appears on the display (2.6.1, 2.6.2, 2.6.3),

or turn the control to the off setting (2.6.4). In

models

c

 ,

 the “on” LED will go off.

2.7  Recommendations for use.

•   More effi cient energy consumption is

achieved when the drawers and shelves

are in the same position in which the

appliance is delivered.

•   Keep the fan switched off for greater

energy savings (2.7.1).

•   Do not open the doors for longer than

necessary. This will allow your refrigerator

to work more effi ciently and prevent any

increase in energy consumption.

•   Store food in sealed containers to prevent

it from drying out.

e n g l i s h

15

3

Maintenance and

cleaning

3.1  Cleaning the inside.

Use a sponge or cloth

soaked in water with bicarbonate of soda to

clean the inside of the refrigerator to prevent

any smells from forming.

Never use a steam cleaner, solvents or

scouring powders.

3.2  Cleaning the outside.

Never use a steam

cleaner to clean the displays.

It is a good idea to clean the grille at the back

once a year with a vacuum cleaner.

3.3  Cleaning the accessories.

 Do not put them

in the dishwasher. Clean them by hand with

the help of a sponge or cloth.

3.4  Changing the light bulb.

 If the light bulb

blows: switch off the refrigerator. Remove

the cover by pressing on the lug (3.4.1) and

removed the blown bulb (3.4.2). Replace it

with another with the same type of thread,

E14, 220-240V, 15/25W or as indicated on

the light fi tting.

3.5  Changing the carbon fi lter.

 Your refrigerator

may have a carbon fi lter to absorb any

strange smells from some types of food and

capture any microorganisms (fungus and

bacteria) circulating in the air.

The fi lter keeps its properties for a limited

time of 6 months. After this time it is

recommended that you replace it with a new

one. Its location varies depending on the

model.

To activate the fi lter: Press down on the tab

and remove the cover to access the fi lter

(3.5.1). Separate the used fi lter from the

cover (3.5.2). Remove the seals from the new

fi lter (3.5.3).

Press the BIOFILTER visor until you hear a

light click (3.5.4) and in a few seconds the

duration scale will start to colour. Put the fi lter

back into place.

Keep used and new fi lters out of the reach

of children;

 digesting large quantities can be

dangerous.

Do not wet the fi lter

as it can lose its

properties.

4

Troubleshooting

4.1  Door open.

If you leave the door open for

more than 1 minute, the

, signal will come

on, an alarm will sound and the refrigerator

light will go off (4.1.1, 4.1.2). The alarm will

stop when the door is closed.

4.2  Power cut.

Open the refrigerator as few times as

possible.

4.3  Normal noises in the refrigerator.

Your refrigerator may make a number of quite

normal operating noises which should not

concern you.

• The refrigerant may make a gargling noise

as it passes through the circuits.

• The compressor may make a buzzing and/

or a slight knocking noise, above all when it

switches on.

• The dilation or contraction of the materials

used can make clicking or creaking noises.

• The air moved by the freezer fan can make

a small background noise.

Do not tamper with your refrigerator in

an attempt to repair it.

Call for service.

5

Safety

•  Keep the ventilation grills clear.

• Be careful not to damage the refrigeration

circuit.

• Do not use any electrical appliances inside

your refrigerator unless they are of the type

recommended by the manufacturer.

• Do not use any mechanical devices or any other

means to speed up defrosting other than those

recommended by the manufacturer.

• This appliance is not intended for use by

people (including children) with reduced

physical, sensory or mental capabilities, or

lack of experience or knowledge, unless they

have been given supervision or instruction

concerning use of the appliance by a person

e n g l i s h

16

6

The environment

This refrigerator was designed with

environmental conservation in mind.

The appliance operates with coolant R600A,

which does not damage the environment.

Respect the environment.

Use the

recommended temperatures for each

compartment.  They will depend on the mode you

need for effi cient use of your refrigerator.

Disconnect the refrigerator or set it to holiday

mode when you will not be using it for a

prolonged period. You will reduce power

consumption and save energy.

Avoid leaving the doors open more time than

necessary.  It causes an increase in power use.

Waste management of electrical and

electronic appliances.

The symbol

 indicates that the appliance must

not be disposed of in traditional bins for domestic

waste.

Deliver your refrigerator to a special collection

centre.

responsible for their safety. Children should be

supervised to ensure that they do not play with

the appliance.

• If the power lead is damaged, it must be

replaced by the manufacturer, or by their after

sales service or a similar qualifi ed person to

prevent any risk.

• This appliance is designed for domestic and

similar uses, such as:

– staff kitchen facilities in shops, offi ces and

other workplace settings;

– rural guest houses and hotel guests, motels

and other residential type settings;

– bed and breakfast accommodation;

– restaurant services and similar non-retail

settings.

Do not store explosive substances such as

aerosol cans with infl ammable propellant in

the appliance.

Recycling domestic appliances prevents negative

impacts on health and the environment and helps

save energy and resources.

For more information, contact your local

authorities or the establishment where you

purchased your refrigerator.
