or lack of experience and knowledge,

unless they have been given supervi-

sion or instruction concerning use of the

appliance by a person responsible for

their safety.

• Children should be supervised to ensure

that they do not play with the appliance.

•

Before using the fan, place it on a stable,

flat surface.

•   Press the "0" button to ensure the fan is

in stop position, and plug it in.

Before assembling the fan, take the

different parts out of the packaging and

check that the supply cable is not damaged

and that the appliance has not received any

knocks during transport. If the appliance is

damaged, do not switch it on.

1A. ASSEMBLING THE BASE

1A1.-

 MODELS: VTR-10 / VTR-10M /

VTR-12 / VTR-12M / VTR-16 / VTR-16M

1.  Thread the cable through the hole in the

base.

2.  Mount the motor support on the base as

shown in the figure.

1A2.-

 MODEL: VTR-16P

1.  Remove the nut screwed onto the shaft.

2.  Mount the shaft on the base support and

fix it in place with the nut.

3.  Loosen the screw and pull the inner

shaft up to the desired height. Then

tighten the screw again. Place the motor

support on the base and fasten it in

place with the fixing screw.

1A3.-

 MODEL: VTR-15P

1.  Remove the nut screwed onto the shaft

and fit the legs to the fan as shown in

the picture.

2.  Place the shaft so that the holes for

fitting the screws coincide. Then screw

in and tighten the screws. Insert the

embellisher first, followed by the nut.

3.  Pull the inner shaft upwards to the

desired height and tighten the nut. Fit

the motor support to the base and

3. ASSEMBLY INSTRUCTIONS 4. OPERATING INSTRUCTIONS

fasten it in place with the fixing screw.

1B. ASSEMBLING THE FAN

1B1.-

 MODELS: VTR-10 / VTR-10M /

VTR-12 / VTR-12M / VTR-16 / VTR-16M /

VTR-16P

1.  Unscrew the nuts on the motor shaft

(anticlockwise) and the motor casing

(clockwise) respectively.

2.  Mount the rear protection grille on the

motor casing and fix it in place with the

fastening nut.

3.  Insert the blades on the motor shaft,

fastening them in place with the blade

fixing nut. Turn the blades manually to

ensure they spin freely. If they do not

turn freely go back to point 2 and mount

them again.

4.  Mount the front protection grille and

gently press it until it fits into the plastic

ring.

5.  Close the safety clip and tighten the

screw.

1B2.-

MODEL: VTR-15P

1.  Unscrew the nut on the motor casing.

2.  Mount the decorative ring on the motor

support and then fit the rear protection

grille onto the motor support, fixing it in

place with the nut.

3.  Insert the blades on the motor shaft,

fastening them in place with the blade

fixing nut.

  Turn the blades manually to ensure they

spin freely. If they do not turn freely go

back to point 2 and mount them again.

4.  Fit the plastic ring to the front protection

grille, then fit the front protection grille

onto the rear protection grille and tighten

the fixing screw.
