Hotpoint-Ariston FHR G /HA S: Installation

• Liquid petroleum gas sinks to the oor as it is heavier

Installation

GB

than air. Therefore, rooms containing LPG cylinders must

also be equipped with vents to allow gas to escape in

! Please keep this instruction booklet in a safe place for

the event of a leak. As a result LPG cylinders, whether

future reference. If the appliance is sold, given away or

partially or completely full, must not be installed or stored

moved, please make sure the booklet is also passed on to

in rooms or storage areas that are below ground level

the new owners so that they may benet from the advice

(cellars, etc.). It is advisable to keep only the cylinder

contained within it.

being used in the room, positioned so that it is not subject

to heat produced by external sources (ovens, replaces,

! Please read this instruction manual carefully: it contains

stoves, etc. ) which could raise the temperature of the

important information concerning the safe operation,

cylinder above 50°C.

installation and maintenance of the appliance.

Built-in appliances

Positioning

Use an appropriate cabinet to ensure that the appliance

! Do not let children play with the packaging material; it

operates properly:

should be disposed of in accordance with local separated

waste collection standards (see Precautions and tips).

• The panels adjacent to the oven must be made of heat-

resistant material.

! The appliance must be installed by a qualied professional in

• Cabinets with a veneer exterior must be assembled with

accordance with the instructions provided. Incorrect installation

glues which can withstand temperatures of up to 100°C.

may damage property or cause harm to people or animals.

• To install the oven under the counter (see diagram) or

in a kitchen unit, the cabinet must have the following

! This unit may be installed and used only in permanently

dimensions:

ventilated rooms in accordance with British Standard Codes Of

Practice: B.S. 6172 / B.S. 5440, Par. 2 and B.S. 6891 Current

Editions. The following requirements must be observed:

• The room must be equipped with an air extraction system

that expels any combustion fumes. This may consist of

a hood or an electric fan that automatically starts each

time the appliance is switched on.

In a chimney stack or branched flue.

Directly to

(exclusively for cooking appliances)

the Outside

• The room must also allow proper air circulation, as air is

needed for combustion to occur normally. The ow of air

3

must not be less than 2 m

/h per kW of installed power.

The air circulation system may

take air directly from the outside

by means of a pipe with an inner

2

cross section of at least 100 cm

;

A

the opening must not be vulnerable

to any type of blockages.

Examples of

ventilation holes

for comburant air.

Adjacent

Room to be

The system can also provide the air

Room

Vented

needed for combustion indirectly,

i.e. from adjacent rooms tted with

air circulation tubes as described

above. However, these rooms must

not be communal rooms, bedrooms

Enlarging the ventilation slot

or rooms that may present a re

between window and floor.

hazard.

20

547 mm. min.

45 mm.

23 mm.

558 mm.

575-585 mm.

567 mm.

5 mm.

595 mm.

545 mm.

25 mm.

! The appliance must not come into contact with electrical

parts once it has been installed.

The indications for consumption given on the data plate

have been calculated for this type of installation.

Ventilation

To ensure adequate ventilation, the back panel of the

cabinet must be removed. It is advisable to install the oven

so that it rests on two strips of wood, or on a completely

at surface with an opening of at least 45 x 560 mm (see

diagrams).

45 mm.

560 mm.

Centring and xing

! The installer must ensure that the correct electrical

Secure the appliance to the cabinet by opening the oven door

connection has been performed and that it is fully compliant

GB

and inserting 4 screws into the 4 holes on the outer frame.

with safety regulations.

Before connecting the appliance to the power supply, make

sure that

• The appliance is earthed and the plug is compliant with

the law.

• The socket can withstand the maximum power of the

appliance, which is indicated on the data plate.

• The voltage is in the range between the values indicated

on the data plate.

• The socket is compatible with the plug of the appliance.

If the socket is incompatible with the plug, ask an

! All parts which ensure the safe operation of the appliance

authorised technician to replace it. Do not use extension

must not be removable without the aid of a tool.

cords or multiple sockets.

Electrical connection

! Once the appliance has been installed, the power supply

Ovens equipped with a three-pole power supply cable are

cable and the electrical socket must be easily accessible.

designed to operate with alternating current at the voltage

! The cable must not be bent or compressed.

and frequency indicated on the data plate located on the

! The cable must be checked regularly and replaced by

appliance (see below).

authorised technicians only (see Assistance).

! The manufacturer declines any liability should these

Fitting the power supply cable

safety measures not be observed.

1. Open the terminal board

Gas connection

by inserting a screwdriver

The appliance should be connected to the main gas supply

into the side tabs of the

or to a gas cylinder in compliance with current National

cover. Use the screwdriver

regulations. Before carrying out the connection, make sure

as a lever by pushing it

the cooker is compatible with the gas supply you wish to

down to open the cover (see

use. If this is not the case, follow the instructions indicated

diagram).

in the paragraph “Adapting to different types of gas.”

When using liquid gas from a cylinder, install a pressure

2. Install the power supply

regulator that complies with current National regulations.

cable by loosening the

! Check that the pressure of the gas supply is consistent

cable clamp screw and the

with the values indicated in Table 1 (“Burner and nozzle

three wire contact screws

specications”) since this will ensure the safe operation

L

L-N- .

and longevity of your appliance while maintaining efcient

Connect the wires to the

energy consumption.

corresponding terminals:

! Should you need to install a gas hob on top of a built-in gas

the Blue wire to the terminal

oven, it is strictly forbidden to connect the two or to use a

marked (N), the Brown wire

single cut-off tap. The two appliances should be connected

to the terminal marked (L)

separately, and each one should have its own stop tap

and the Yellow/Green wire

in order to make them completely independent from one

to the terminal marked

another (see gures).

N

(see diagram).

3. Secure the cable by fastening the clamp screw.

NO

OK

4. Close the cover of the terminal board.

Connecting the supply cable to the mains

Install a standardised plug corresponding to the load

indicated on the data plate (see table).

The appliance must be directly connected to the mains using

an omnipolar switch with a minimum contact opening of 3

mm installed between the appliance and the mains. The

switch must be suitable for the charge indicated and must

comply with current electrical regulations (the earthing wire

Connection with a rigid pipe (copper or steel)

must not be interrupted by the switch). The supply cable

! Connection to the gas system must be carried out in such a

must be positioned so that it does not come into contact

way as not to place any strain of any kind on the appliance.

with temperatures higher than 50°C at any point (the back

panel of the oven, for example).

21

There is an adjustable L-shaped pipe tting on the appliance

! Take particular care when handling the spark plug

GB

supply ramp and this is tted with a seal in order to prevent

wires and the thermocouple pipes.

leaks. The seal must always be replaced after rotating the pipe

tting (the seal is provided with the appliance). The gas supply

• Primary air regulation for the oven burner

pipe tting is a threaded 1/2 gas cylindrical male attachment.

The burner was designed not to need any adjustments to

the primary air.

Connecting a exible jointless stainless steel pipe to

a threaded attachment

• Setting the oven burner to minimum

The gas supply pipe tting is a threaded 1/2 gas cylindrical male

1. Turn the knob rst to the Max setting for about 10 minutes

attachment. These pipes must be installed so that they are never

and then to Min.

longer than 2000 mm when fully extended. Once connection has

2. Remove the knob.

been carried out, make sure that the exible metal pipe does

3. Remove the disk fastened to the control panel.

not touch any moving parts and is not compressed.

4. Adjust the screw located outside the thermostat cock pin

until the ame is small but steady (the ame can be seen

! Only use pipes and seals that comply with current National

through the slots on the oven bottom).

regulations.

5. Make sure the burner does

not switch off when you turn

Checking the tightness of the connection

the knob from Max to Min

! When installation has been completed, check the pipe

quickly, or when you open

ttings for leaks using a soapy solution. Never use a ame.

and close the oven door

quickly.

Adapting to different types of gas

In order to adapt the oven to a type of gas other than the

type for which it was manufactured (indicated on the label),

follow these simple steps:

• Replacing the oven burner nozzle

1. Open the oven door fully.

! If the appliance is connected to liquid gas, the regulation

2. Slide out the bottom of the

screw must be fastened as tightly as possible.

oven.

! Once this procedure is nished, replace the old rating

sticker with one indicating the new type of gas used. This

sticker is available from any of our Service Centres.

! If the gas pressure is different from the recommended

pressure, a suitable pressure regulator must be tted to the

inlet pipe in accordance with current National Regulations.

3. Unscrew the burner

fastening screws.

4. Remove screw “V” and

then the oven burner.

V

5. Unscrew the oven burner

nozzle using the special

socket spanner for the

nozzles, or better still a 7 mm

socket spanner, and replace

it with a nozzle suited to the

new type of gas (see Table 1).

6. Replace all the parts, following the steps described above

in the reverse order.
