Nikon PD-10: Specifications En

Specifications

En

Interface USB

IEEE 802.11g Wireless LAN (OFDM, 54 Mbps in 2.4 GHz band)

The distance to communicate: 0 - 25 m Condition of the distance: Line of sight

IEEE 802.11b Wireless LAN (DSSS, 11 Mbps in 2.4 GHz band)

Wireless LAN interface

The distance to communicate: 0 - 40 m Condition of the distance: Line of sight

Wireless mode Ad-hoc mode

Security WEP 128 bit

Batteries Two LR6 (AA) Alkaline batteries (two rechargeable Nikon EN-MH1 batteries, two ZR6 (AA)

nickel manganese batteries and two FR6/L91 (AA) lithium batteries also can be used)

USB connector on printer 5 V, 100 mA

Power sources

Battery life Approximately 120 minutes (when using LR6 (AA) Alkaline batteries; this may differ de-

pending on the type of printer, file size of pictures to be printed, and wireless connection

conditions)

Body: Approximately 117 × 45.5 × 29.5 mm/4.6 in. × 1.8 in. × 1.2 in. including cable boot (not including cable)

Dimensions (W × H × D)

USB cable: Approximately 500 mm/19.7 in.

Approximate weight 73 g without batteries

Temperature: 0 to 40°C

Operation Environment

Humidity: 10 to 90 %

11
