ROC6507

User manual

Manuel d’utilisation

Bedienungsanleitung

Manuale di utilizzazione

Manual de utilización

Gebruiksaanwijzing

Руководство по применению

ENGLISH...................................2

FRANÇ

................................8

D

UT

C

.............................

14

T

O

.............................

20

P

ÑO

...............................

26

..................... 32

PУCCКИЙ

........................... 38

Characteristics - Caractéristiques - Eigenschaften -

Caratteristiche - Características - Eigenschappen -

Технические характеристики

Weight = 103 grammes

oids = 103 grammes

Gewicht = 103 Gramm

eso = 103 grammi

вес = 103 грамм

eso = 103 gramos

Gewicht = 103 gram

Dimensions - Dimensions - Abmessungen - Dimensioni - Dimensiones -

Afmetingen - размеры

= 213 x 50 x 21 mm

ROC6507

This universal remote control (6 in 1) is compatible with most television sets, DVD players, video cassette recorders,

ampliers and Hi-Fi and Home Cinema systems, as well as with most digital decoders such as satellite or cable

receivers, ADSL decoders, etc. These digital decoders are grouped together under the name STB (Set Top Box).

This remote control was factory-programmed in order to allow you to use it immediately with most devices with

Thomson group brand names. We suggest that you thus try it out before programming it using one of the methods

in this users manual. But rst of all, you must install 2 batteries (AAA - LR03) in it.

Keep this manual and its related documents so that you can refer to them for new programming operations

whenever you acquire new devices.

The LCD display always shows the active mode of the remote control (TV, DVD,

etc.) and the current time. These indications will be displayed as long as the

batteries are not worn down.

Navigation keys

The navigation keys serve to scan and then select the functions on the LCD

display.

The EXIT key serves to return to normal use of the remote control. In some cases,

this return to normal is automatic.

The keys and their functions

Programming the remote control

1 � - On/Standby, or Standby only, depending on the

The SETUP key is used for programming or to access

device.

the secondary functions such as, for example,

2 Mode keys – Select the device to be controlled (TV,

adjusting brightness or contrast on certain TV sets, etc.

DVD, etc.).

Programming is required if you wish to control devices of

3 SETUP – Programing the remote control.

other brands than Thomson.

4

Selec ting TV channels with one or two digits

(-/-),

Selec ting a plug/external feed (AV),

Access to the secondary functions

choosing a macro- command (1/T V, 2/DVD,

Briey press the SETUP key once. The date will show

3/STB).

on the screen. Then press the desired secondary

5 MENU, 5,6,4,3, OK, EXIT – Access to

function key. The remote control will exit this mode

the Navigation/Selection, Conrmation menus

30 seconds after a key is last pressed or if you press the

Exit from the menus.

EXIT key.

6 L1, L2, L3, L4 – Additional programmable keys

(learning function).

Programming the remote control

7 Activating and using Teletext (Videotext, Fastext,

Hold down the SETUP key until CODE SETUP appears

etc.).

on the display. If you see SET on the right side of

8 Playing a disc or cassette.

the display, this confirms that the remote control

9 Volume control, Mute ( ), Change TV channel/

is being programmed. Pressing SETUP repeatedly

station, Display in 16 : 9.

then allows you to scroll through the settings

10 Turns on the MACRO mode (sequence of automatic

options in the order given below. You may exit the

commands).

programming mode by pressing the EXIT key or by

11 LCD display

navigating up to the exit option and confirming by

a remote control mode (TV, DVD, etc.),

pressing OK.

b day, date, (press SETUP),

c hour, date or code of the device controlled, (press

SETUP or the mode key),

CODE SETUP - Allows you to access one of the

d shows transmission to the device,

4 programming modes using the OK key.

e SET is displayed when the remote control is in

You may thus choose to scroll through the list of codes,

programming mode.

enter a code, launch a code search or enter a code based

f Sleep timer is programmed

on the brand of the equipment to be controlled (the

g is displayed when a Timer is programmed

code booklet comes separately).

h Time format AM (morning) / PM (afternoon) when

the time is set in the 12Hr mode. Not shown when in

SYSTEM SETUP - Allows you to access settings for time,

the 24Hr mode.

date, volume, etc. using the OK key.

TIMER SETUP - Allows you to access the Timer settings

Note: The mode keys are pre-set for the devices indicated

using the OK key.

by their icons (

TV for a TV set, DVD for a DVD player, etc.).

Your remote control allows you to assign to each key a

LEARN SETUP - Allows you to access the learning function

dierent mode from the one indicated on it for all of the

of the keys using the OK key.

mode keys except the

TV key (e.g., DVD-HDD recorder to

the

VCR key, etc).

MACRO SETUP - Consists of dening the sequences of

automatic commands. Each sequence is made up of

commands involving several keys (10 keys maximum).

Start set-up

HOME CINEMA SETUP - The Home Cinema mode is

considered to be a «virtual mode» that uses up to 5

The rst time you install the batteries, instructions will

groups of keys per mode. By means of this function,

appear in English (SET USING...KEY). Press OK to display

users can see all of the keys and devices they most often

LANGUAGE? ENGLISH then select one of the 7 languages

use regrouped under a single «Virtual mode». (See Home

using the 56 keys and press OK. CONFIRM xxxx

Cinema fucntion, Page 6).

(depending on the language selected) is displayed Press

OK > SUCCESS is briey displayed, then CODE SET UP.

EXIT SETUP - Allows you to exit the programming mode

When CODE SET UP is displayed, you will have a few

using the OK key.

seconds to set up the codes for the devices you would

like to control with your ROC 6507. Refer to stage 3 of

Note 1: After 15 seconds of inactivity, the remote control

the A, B, C, D programming methods to continue the

exits the programming mode.

programming procedure.

Note: TIMEOUT appears when you have exceeded the

Note 2: If the remote control is searching for a code or

allotted time for an operation.

awaiting information,

PLEASE WAIT is displayed.

GB

Replacing the batteries: The settings for the time, day and date, and the macros are erased while the batteries are

replaced. Other settings entered will be preserved.

2

Method C - Programming by code search

Testing the remote control

before programming

Used to manually search for a code in any code library

GB

for a family of devices whose code or commercial brand

may not be included in the separate list or is led in

1. Turn on the device that you wish to control.

another fashion.

2. Press the key that corresponds to the type of device

to be controlled:

1. Turn on the equipment that you wish to control.

TV: TV set,

2. Hold down the SETUP key until CODE SETUP appears

DVD: DVD player/recorder,

on the display (for 7 seconds).

VCR: video cassette recorder,

3. Press OK once to display SCROLL A LIST OF CODES.

STB: satellite, cable, ADSL,

4. Using the navigation keys (5,6), display SEARCH

AMP: amplier

FOR THE CODES then conrm using OK in order to

AUDIO: Hi-Fi system,

display SELECT A MODE KEY.

3. Point the remote control at the device to be

5. Press once on the key of the device to be

controlled and try to turn it o using the � key. If

controlled (TV, DVD, VCR, etc.) to display SELECT

the device does not go o, you should program the

DEVICE TV?

remote control following one of the procedures A, B,

6. Conrm using OK to display TO SEARCH PRESS …P+

C or D described below.

or � (for the TV mode key, only TV can be selected).

7. Point the remote control at the device to be

Identifying a code: Press and hold a mode key. The

controlled and try to turn it o using the � key.

code stored in memory for this mode is displayed (e.g.,

8. If the device to be controlled goes o, press OK to

DVD…..0768).

store the code.

9. If the device does not go o, press the � again

Note: Except for the TV key, every mode key (DVD, VCR,

several times until the device goes o. Between

etc.) can be programmed to control a device other than

two presses on the key, leave time for the device to

the one indicated on the key. It is thus possible to assign,

respond (1-2 seconds).

for example, the

DVD mode to the VCR key. You should

10. As soon as the device to be controlled goes o, press

enter the code that corresponds to the desired brand and

OK to store the code.

device following one of the procedures indicated in this

11. The display briey indicates SUCCESS before exiting

manual.

the programming mode.

Note 1: Each time the (�) key is pressed, the remote control

sends a signal to the device. This signal corresponds to

Programming the remote control

a code in the code library stored in the remote control

Setting up the codes

memory. If you go past the required code, use the

PROG -

key to go back (or advance using

PROG +) inside the code

library.

Method A - Programming by scrolling

Note 2: the indication SEARCHING FOR: remains on display

during this mode.

Used to enter the codes using the list of codes shown

on the display.

1. Turn on the equipment that you wish to control.

Method D

2. Hold down the SETUP key until CODE SETUP appears

on the display (for 7 seconds).

Programming by search for Brand names

3. Press OK once to display SCROLL A LIST OF

CODES.

Used to manually search for a brand name (Thomson,

4. Press OK once to display SELECT A MODE KEY.

Philips, Sony, etc.) in the code library, which generally

5. Press once on the key of the device to be

contains 30 to 40 codes.

controlled (TV, DVD, VCR, etc.) to display SELECT

DEVICE TV?

1. Turn on the equipment that you wish to control.

6. Using the navigation keys (5,6), select the device

2. Hold down the SETUP key until CODE SETUP appears

(DVD, VCR, etc.) then conrm using OK. (for the TV

on the display (for 7 seconds).

mode key, only TV may be selected). The rst brand

3. Press OK once to display SCROLL A LIST OF CODES.

name and the rst code are displayed (e.g.: ADMIRAL,

4. Using the navigation keys (5,6), display USE

0000).

BRAND CODES then conrm using OK in order to

7. Select the brand using the navigation keys 56,

display SELECT A MODE KEY.

or by selecting the 1st letter of the brand of your

5. Press once on the key of the device to be

device using keys 2 - 9 (as on a mobile phone: 2=abc,

controlled (TV, DVD, VCR, etc.) to display SELECT

3=def, etc.) (e.g.: THOMSON : 8 4).

DEVICE TV?

8. Point the remote control at the device and try out

6. Conrm using OK in order to display ENTER THE

various keys, for example VOL +/-, PROG +/-, etc.

BRAND KEY 1-8 (for the TV mode key, only TV can be

9. If the device responds, store the code using OK.

selected).

10. If the device does not respond, change the code using

7. Refer to the separate list of codes by brand (this list

the 43 keys and try controlling the device again.

comes separately) and key in the number (1 to 8)

11. If you have tried all of the codes for your brand

that corresponds to the brand of the device to be

and the device still does not respond, try Method C

controlled. TO SEARCH PRESS P+ OR � is displayed

(programming by code search).

on the screen.

8. Point the remote control at the device to be

controlled and try to turn it o by pressing the � key

Method B - Programming by entering the code

once.

9. If the device to be controlled goes o, press OK to

Codes from the separate list (code tables).

store the code.

10. If the device does not go o, press the � again several

1. Turn on the equipment that you wish to control.

times until the device goes o. Between two presses

2. Hold down the SETUP key until CODE SETUP appears

on the key, leave time for the device to respond (1-2

on the display (for 7 seconds).

seconds).

3. Press OK once to display SCROLL A LIST OF CODES.

11. As soon as the device to be controlled turns o, press

4. Using the navigation keys (5,6), display ENTER

OK to store the code.

THE CODES then conrm using OK in order to display

12. The display briey indicates SUCCESS before exiting

SELECT A MODE KEY.

the programming mode.

5. Press once on the key of the device to be controlled

(TV, DVD, VCR, etc.). The key selected and the code

Note 1: Each time the (�) key is pressed, the remote control

stored in memory for this key are shown on the

sends a signal to the device. This signal corresponds to

display (e.g.: TV.....0166).

a code in the code library stored in the remote control

6. Enter one of the 4-digit codes oered on the list

memory. If you go past the required code, use the

PROG -

received separately.

key to go back (or advance using

PROG +) inside the code

7. The display briey indicates SUCCESS before exiting

library.

the programming mode.

Note 2: The indication SEARCHING FOR remains on display

during this mode.

3

GB

4

Programming the combo (combined) codes:

1. Using the SETUP keys (hold down for 7

for certain combos (TV/VCR, TV/DVD, DVD/VCR, etc.), you

seconds), and navigation keys 5,6,4,3,

will have to press two keys in dierent modes in order

OK, display CODE SETUP followed by SYSTEM

to control the two devices the make up the combo. For

SETUP (press OK) then VOL/MUTE CONTROL SETUP

example, if you have a TV/DVD Combo, you may have

(press OK) navigate up to VOL/ MUTE CONTROL

to set a code using the TV key for the TV set AND a

RESET.

separate code (using another mode key) to control the

2. Press OK once.

DVD player.

3. CONFIRM OK TO RESET is displayed.

4. Press

OK once to conrm cancellation.

5. The screen briey displays PLEASE WAIT then

Combo commands:

SUCCESS before exiting this setup.

certain combos (TV/VCR, TV/DVD, DVD/VCR,…) have

separate keys on the original remote control for

Setting the time

selecting the Combo device that you wish to control.

1. Using the SETUP keys (hold down for 7 seconds),

For example, if your Combo is a DVD/VCR, its original

and navigation keys 5,6,4,3, OK, display

remote control may have separate DVD and VCR keys

CODE SETUP then SYSTEM SETUP (press OK) and

for selecting the combo device you wish to control.

navigate up to TIME SETUP.

You may obtain the equivalent key functions on your

2. Press OK once.

remote control using the Mode and SETUP keys.

3. Set the format to 12 or 24 hours using 5,6, and

Supposing that your Combo has a DVD and a VCR,

conrm using OK.

and that its code is programmed in DVD mode, hold

4. Set the hour then the minutes using 5,6,

down the DVD Mode key for over 1 second in order to

(move from hours to minutes using OK) and conrm

send the DVD key command. In order to send the VCR

using OK.

key command, press and quickly release the SETUP

5. The display briey indicates SUCCESS before

key, then press and release the DVD Mode key. This

returning to CODE SETUP.

procedure may apply regardless of the type of Combo

(TV/VCR, TV/DVD, DVD/VCR, etc.), and is available in

Setting the date

all modes. This function is not guaranteed for all the

1. Using the SETUP keys (hold down for 7 seconds)

codes.

and navigation keys 5,6,4,3, OK, display CODE

SETUP followed by SYSTEM SETUP (press OK) then

navigate up to DATE SETUP

2. Press OK once.

3. Using keys 5,6, and OK, successively set the year,

System setup

month, date and day.

4. The display briey indicates SUCCESS before

Using the SETUP keys (hold down for 7 seconds), and

returning to CODE SETUP.

the navigation keys 5,6,4,3, OK go to the SYSTEM

SETUP screen in order to access the settings for volume,

Setting the backlight

time, date, backlighting and deleting options. Then

Used for setting the backlight delay following a key

navigate using keys 5,6,4,3, OK.

action.

1. Using the

SETUP keys (hold down for 7 seconds),

Volume control and Mute setup

and navigation keys 5,6,4,3, OK, display CODE

This remote control allows you to dene the mode that

SETUP then SYSTEM SETUP (press OK) and navigate

the Volume and Mute ( ) keys will control.

up to BACKLIGHT SETUP.

When it is shipped, this remote control is set so that

2. Press OK once.

the Volume and Mute keys control the current mode

3. Using keys

5,6 and OK, set the backlight time,

the remote control is in. If this mode does not have a

from 5 to 60 seconds, when BACKLIGHT TIME? is

volume control function, then the Volume and Mute keys

displayed.

automatically control the TV mode.

Note: the default time is 10 seconds. In order to deactivate

Volume control and mute setup in one mode

the backlight function, set the time to 00 and press

OK

Used to assign to one mode (TV or AUDIO, or ...) the

once.

Volume and Mute keys ( ) without having to select

that mode during daily use.

4. The display briey indicates

SUCCESS before

1. Using the SETUP keys (hold down for 7 seconds),

returning to CODE SETUP.

and navigation keys 5,6,4,3, OK, display SET

CODES followed by SYSTEM SETUP (press OK) then

Setting the LCD display langauge

VOL/MUTE CONTROL SETUP. (press OK) then SET ALL

Used to select one of the 7 languages oered by your

VOL. TO 1 MODE (press OK) then SET ALL VOL. TO

remote control.

MODE?.

1. Using the

SETUP keys (hold down for 7 seconds),

2. Press once on the key of the device to be controlled

and navigation keys 5,6,4,3, OK, display CODE

(TV, DVD, VCR, etc.).

SETUP then SYSTEM SETUP (press OK) and navigate

3. The screen briey displays PLEASE WAIT then

up to LANGUAGE SETUP.

SUCCESS before exiting this setup.

2. Press OK once.

3. Using keys

5,6 and OK, select the language when

Note: If the mode selected does not itself display the

LANGUAGE? is displayed.

Volume/Mute commands,

VOLUME CONTROL ERROR is

4. The display briey indicates

SUCCESS before

shown on the screen and the remote control exits the setup

returning to CODE SETUP.

function and returns to normal operation.

Cancelling your settings

Volume control and mute setup in each mode

Used to recongure the remote control to the default

Used to assign the Volume and Mute keys

settings by erasing all the settings and storage of codes

( ), for each mode desired.

and keys.

1. Using the SETUP keys (hold down for 7 seconds),

1. Using the

SETUP keys (hold down for 7 seconds),

and navigation keys 5,6,4,3, OK, display CODE

and navigation keys 5,6,4,3, OK, display

SETUP followed by SYSTEM SETUP (press OK) then

CODE SETUP then SYSTEM SETUP (press OK) and

VOL/MUTE CONTROL SETUP (press OK) navigate up

navigate up to SYSTEM RESET.

to SET VOLUME FOR 1 MODE (press OK) then SET

2. Press OK once.

THE VOLUME FOR MODE?.

3. Press

OK once when CONFIRM OK TO RESET is

2. Press once on the key of the device to be controlled

displayed.

(TV, DVD, VCR, etc.).

4. The display briey indicates

PLEASE WAIT before

3. The screen briey displays PLEASE WAIT then

leaving this setting.

SUCCESS before exiting this setup.

Note: before using this setting, verify that the mode selected

has its own Volume/Mute functions either in the code or

Setting the Timer

by learning; otherwise, the Volume/Mute keys will have no

eect.

Using the SETUP keys (hold down for 7 seconds), and

navigation keys 5,6,4,3, OK, go to the TIMER SETUP

Resetting the Volume control and mute control

display in order to access the stand-by settings for the

Used to cancel the settings of the preceding paragraphs

TV set and 4 other timers that send sequences of at most

(return to the default factory-installed settings).

4 keys. Then navigate using keys 5,6,4,3, OK.

GB

5

Automatic sleep setup for the TV set

Key learning

Used to program the sleep setup for a TV set using the TV

Sleep Timer mode (“Zzz”).

This function is used to copy the functions of keys

on other remote controls to the keys on your ROC

1. Turn on the device in TV Mode.

6507 in the mode and to the keys of your choice.

2. Using the

SETUP keys (hold down for 7 seconds),

Your ROC 6507 can store up to 150 keys (depending

and navigation keys 5,6,4,3, OK, display

on the format of the IR code to be learned). Only

CODE SETUP then navigate up to TIMER SETUP

one original remote control may be stored per Mode

(press OK) then TV SLEEP SETUP (press OK) then

(refer to the notes concerning learning). The remote

TV SLEEP SET.

control may also be pre-programmed using one

3. Press OK once.

of the codes in the library, and copied keys may

4. Using keys

5,6 and OK, select the number

be «superimposed» on the key positions selected by

of minutes (from 1 to 90 minutes) before the TV

the user: The remote control can thus be customised

enters sleep mode when TV SLEEP TIME? is

by the user, who uses a pre-programmed code, then learn

displayed.

the key functions from his original IR remote control.

5. The display briey indicates

SUCCESS before

returning to CODE SETUP.

6. Press EXIT twice to exit this mode.

Careful: You may not copy onto the Setup, Home Cinema or

Macro keys • All of the commands copied for one mode are

erased if an identical or new 4-digit code is entered for this

Note: The “Zzz” symbol is displayed when a TV Sleep Timer

mode (also applies to direct entry of a code, a code search

is set.

or brand search) • The screen and key backlighting is o

during learning.

7. Set the remote control down on a table or at surface

at the level of the TV set’s infrared receiver with its

Advice before you begin:

front end pointed toward the TV set.

• Place the remote controls face to face so that the

IR LED diodes of the two remote controls are precisely

Note: to clear the programming, navigate up to TV SLEEP

lined up. You may need to adjust the height of

SETUP then TV SLEEP CLEAR. Press OK once when CONFIRM

the remote controls so that the LED diodes are

OK TO CLEAR is displayed. The display briey indicates

properly aligned. Verify that the gap between the

SUCCESS before returning to CODE SETUP.

two remote controls is about 25 mm [1 inch]. Do not

change the gap between the two remote controls

during the learning of all the keys required for this

Setting the timer

mode.

Used to program up to 4 timers. You may assign up to 4

• Begin by copying 2 or 3 keys (to get used to it), then

keys to the Timer so that it will activate at the set time (for

perform the “Clear All Learn Modes“ function (clear

example, to change the Mode SAT channel over to 123 at

all learn modes) before learning the entire keyboard

22:35). The rst key must always be a mode key. The

of your original remote control.

following keys may not include 5,6,4,3, OK EXIT,

MACRO, SETUP, or any other mode key. Timers may only

be set to be activated within the following 24 hour

How to copy (learn) keys

period. Timers are automatically cleared after having

1. Using the

SETUP keys (hold down for 7 seconds),

been activated. The Timer

“ ”

symbol is displayed when

and navigation keys 5,6,4,3, OK, display CODE

a Timer is set.

SETUP then navigate up to LEARN SETUP (press OK)

1. Turn on the device in TV Mode.

then LEARN ONE MODE (press OK) then SELECT A

2. Using the

SETUP keys, and navigation keys

MODE KEY.

5,6,4,3, OK display CODE SETUP then OPTION

2. Press OK once.

SETUP then TIMER SETUP (press OK) then TV SLEEP

3.

Press the desired mode key once (TV, DVD, VCR, etc.)

SETUP then TIMER X SETUP (X corresponds to one of

to display SELECT A MODE KEY TO LEARN

.

the 4 timers).

4. Press once on the key of your ROC 6507 to which

3. Press

OK once to display TIMER X SET.

you wish to copy the code of the original remote

control.

5. The indication

LEARNING: PLEASE WAIT appears.

Note: Clear the timer if it already contains a program (see

6. While

LEARNING: PLEASE WAIT is displayed, hold

below).

down the key on the original remote control until

SUCCESS or KEY LEARN ERROR appears on the

4. Using keys

5,6, OK, select the desired start time

display before releasing the key on the original

(hour and minutes), Press OK.

remote control (normally after 2-3 seconds).

5.

SELECT TIMER X MODE? is displayed. Using the

7. The indication

OK – LEARN MORE or EXIT? is

mode keys, indicate the device to be controlled (TV,

displayed. To copy another key, press once on OK

DVD, VCR).

then begin again starting with Step 5 or press EXIT

6. The indication SELECT TIMER X KEYY? is displayed.

once to exit this mode.

Press once on the key that corresponds to the desired

8. The display briey indicates

PLEASE WAIT before

command (e.g. 1).

leaving this mode.

7. The indication

SELECT KEY 2 is displayed. Press

once on the desired key (e.g. 3) or on OK if you do

Erasing the functions learned in a mode

only want to send one command, and go to Point 10,

Erases all the keys copied in a given mode

below.

1. Using the

SETUP keys, (hold down for 7 seconds)

8. The indication

SELECT key 3 is displayed. Press once

and navigation keys 5,6,4,3, OK, display CODE

on the desired key (e.g. 8).

SETUP then navigate up to LEARN SETUP (press OK)

9. The display briey indicates

SUCCESS before

then LEARN ONE MODE then CLEAR ONE LEARN

returning to CODE SETUP.

MODE.

10. Press EXIT to exit this mode.

2. Press OK once to display SELECT A MODE KEY.

11. Set the remote control down on a table or at

3. Press the desired key (TV, DVD, VCR, etc.) once to

surface at the level of the TV set’s infrared receiver

display CONFIRM OK TO CLEAR

with its front end pointed toward the device to be

4. Press

OK once.

controlled.

5. The display briey indicates

PLEASE WAIT before

leaving this mode.

Note: the symbol “ ” is displayed when a Timer is set.

Erasing functions learned for all modes

Clearing a timer

Erases all the keys copied (overall erasing is recommended

1. Using the

SETUP keys (hold down for 7 seconds),

for the rst learning)

and navigation keys 5,6,4,3, OK display

1. Using the

SETUP keys (hold down for 7 seconds),

CODE SETUP then OPTION SETUP then TIMER

and navigation keys 5,6,4,3, OK, display

SETUP (press OK) then TV SLEEP SETUP then

CODE SETUP then navigate up to LEARN SETUP

TIMER X SETUP (press OK) then TIMER X CLEAR.

(press OK) then navigate up to CLEAR ALL LEARN

2. Press OK once to display TIMER X CLEAR.

MODES.

3. Press OK once to display CONFIRM OK TO CLEAR.

2. Press OK once to display CONFIRM OK TO CLEAR.

4. Press OK once.

3. Press OK once.

5. The display briey indicates

SUCCESS before

4. The display briey indicates

PLEASE WAIT before

returning to CODE SETUP.

leaving this mode.

GB

6

Notes on learning: Do not try to perform learning

How to clear a macro

directly under fluorescent lights or in weak lighting

1. Using the

SETUP keys (hold down for 7 seconds),

conditions since this could cause interference with the IR

and navigation keys 5,6,4,3, OK, display CODE

transmissions. Place the remote control at least 1 metre

SETUP then navigate up to MACRO SETUP (press OK)

[3 feet] from any light source • Avoid copying the volume

then MACRO KEY CLEAR (press OK) then SELECT A

and mute keys on your original remote control, unless

MACRO KEY.

you are sure that they activate the same target device;

2. Press once on key 1, 2 or 3 of the macro to be cleared

for example, certain original DVD remote controls may

to display CONFIRM OK TO CLEAR

also include a TV volume/mute key: they may have two

3. Press OK once.

different types of codes • Avoid learning VCR keys on your

4. The display briey indicates

SUCCESS before leaving

original remote control unless you are sure that they

this mode.

activate the same target device; for example, certain

original TV remote controls may also include a VCR key:

How to use a macro

they may have two different types of codes • Copying

In normal operation, to activate the Macro, press and

a key may take up to 3 seconds. Do not release the key

release the MACRO key, then (within 20 seconds) press

being copied unless the “

Success” or “Key Learn Error”

and release key 1, 2 or 3 to display MACRO X while the

screens are displayed.

Macro sequence is being run and remote control returns

to normal function. While the Macro is being executed,

If copying the rst or second keys for a certain mode

the remote control must be pointed at the devices to be

constantly cause errors, use the following procedure:

controlled.

i. End the learning session by pressing the

EXIT key.

ii. Clear the commands learned for this mode.

Note: if there is no Macro stored for the number key selected,

iii. Verify that the IR LED’s are properly aligned between the

“Macro X Void“ is displayed.

two remote controls.

iv. Ajust the gap between the two remote controls so as to

reduce or increase the distance (from 15 mm to 50 mm

Notes on macros: The time elapsed between each automatic

[1/2 to 2»]).

command during the execution of a macro is 1/2 second.

v. Try learning the original remote control again for this

For certain commands, you may have to add pauses in a

mode.

macro sequence (for example, to allow the TV set to warm

up). These pauses may be adjusted by using the

PAUSE key,

If the problem continues for the same key, verify that the key

followed by a number of seconds from 1 to 9. The rst key

on the original remote control was properly learned; does

stored in a Macro sequence must be a Mode key (

TV, VCR,

it send the signals? Does it activate the target device? Try

etc.). The SETUP, HOME CINEMA and MACRO keys may

copying this key using a dierent mode. If the learning is

not be included in a Macro. Press

SETUP in order to exit

correct, the type of code may be dierent from the others

Macro Setup.

and cannot be copied in the same mode.

Home Cinema Function

Macro commands

The Home Cinema function uses up to 5 devices with

This function permits storing sequences of commands

one mode key: the HOME CINEMA key. The 5 devices

using the MACRO key. You can program and store up

correspond to the ve mode keys (TV, DVD, AMP...) that

to 3 sequences of successive keystrokes for several

will be associated with predened keys. The keys are:

keys of your choice. By pressing the respective Macro

a. The 2 program keys

PROG + / -.

digital key, this sequence of successive keystrokes

b. The 3 volume

VOL + / - keys and the mute ( ) key.

(IR commands) is sent. Any sequence of successive

c. The 6 run keys Play, Pause, Stop, Fast Forward, Fast

keystrokes performed frequently may be reduced to

Rewind and Record 7,4,8,=,<,;.

only two commands (MACRO key plus one of the 1, 2 or

d. Directional keys: up, down, right and left

5,6,4,3

3 keys). For example, by pressing MACRO and then only

and the MENU, EXIT, OK keys.

one key, you can turn on your TV set, display your favorite

e. For the remaining keys: "base" mode

HOME CINEMA

channel, turn on your VCR and start a recording, etc.

(any one of the other modes).

You can store a sequence of 10 commands for each 1, 2

or 3 key.

Example: In Home Cinema mode, you can set up the

PROG+/ keys to control the satellite receiver, the VOL +/

How to set up a macro

and ( ) keys to control the amplier, the Run keys (PLAY,

Tip: Set up your macro on a sheet of paper by

PAUSE, etc.) to control the DVD player, the MENU, EXIT, etc.

writing down the series of 10 keystrokes (maximum)

keys to control the DVD player, and the other keys to control

that it is composed of. As an example, if you want to

the TV set.

turn on your TV set to Channel 3 and then turn on a

satellite receiver to Channel 5, you should write down:

How to program the Home Cinema function

MACRO, 1 (for storage for this key), TV (�), 3, SAT (�),

1. Using the

SETUP keys (hold down for 7 seconds),

5, MACRO.

and navigation keys 5,6,4,3, OK, display CODE

SETUP then navigate to HOME CINEMA SETUP (press

1. Using the

SETUP keys (hold down for 7 seconds),

OK) then HOME CINEMA SET (press OK) then PROG/

and navigation keys 5,6,4,3, OK, display CODE

CHAN KEY GROUP MODE?.

SETUP then navigate up to MACRO SETUP (press

2. Choose a mode key (TV, DVD, VCR, etc.) for the PROG

OK) then MACRO KEY SET (press OK) then SELECT A

+ / - keys.

MACRO KEY.

>

VOLUME & MUTE KEYS MODE? appears.

2. Press once on the 1, 2 or 3 key to which you wish to

3. Choose a mode key (

TV, SAT, AMP, AUDIO, etc.) for

assign the macro.

the VOL + / - keys.

3.

The indication SELECT MACRO X MODE? appears.

>

RUN KEYS MODE? appears.

4. Press once on the desired mode key (TV, DVD,

4. Choose a mode key (

TV, DVD, VCR, etc.) for the

VCR, etc.) to select the device that will receive the

7,4,8,=,<,;run keys.

command SELECT MACRO X KEY? is displayed.

>

xxx MENU, OK, EXIT MODE? appears

5. Choose a mode key (

TV, DVD, VCR, etc.) for the

navigation keys MENU, EXIT, OK.

Note: The rst key in the Macro sequence must always be

>

ALL OTHER KEYS MODE? appears.

a mode key.

6. Choose a mode key (

TV, DVD, VCR, etc.) for the other

remote control keys to be used for Home Cinema

5. Press each of the keys in order that make up the

mode.

macro.

The display briey indicates

PLEASE WAIT then

6. Store the macro by pressing the

MACRO key once.

SUCCESS before returning to CODE SETUP.

7. The display briey indicates

PLEASE WAIT before

leaving this mode.

How to delete the Home Cinema function

1. Using the

SETUP keys (hold down for 7 seconds),

Note: the Macro is automatically stored the 10th time the

and navigation keys 5,6,4,3, OK, display CODE

key is pressed.

SETUP then navigate to HOME CINEMA SETUP (press

OK) then HOME CINEMA RESET.

8. The display briey indicates

SUCCESS before leaving

2. Press OK once to display CONFIRM OK TO RESET.

this mode.

3. Press OK once.
