7 Adjustments

7.1

Connecting electric power tools

CAUTION

Risk of injury

-  Make sure that the electric power tool is

switched off.

-  Observe the maximum appliance socket con-

nected load (see "Technical data")

•  Connect the electric power tool to the appliance

socket [1-5].

7.2

Connecting suction hoses

•  Insert the suction hose into the intake opening

[1-2].

• Set the hose diameter adjuster [1-6] to match

the diameter of the connected hose.

This ensures that the suction capacity is meas-

ured correctly.

7.3

Adjusting the suction power

You can use the suction power adjuster [1-4] to

adapt the machine suction power to different ap-

plications.

7.4

Applying the brake

The brake prevents the mobile dust extractor from

rolling.

•  Applying the brake

[1-12]

•  Releasing the brake

[1-13]

8

Working with the machine

The extraction hose is connected to the extraction

sleeve on the outlet spigot of the electric power

tool. The special hose supplied with the suction

sleeve is designed for use with the

PLANEX

 and

most other Festool machines.

Check the fi lter element for damage before start-

ing work.

Check the volume monitor before starting work:

• Cover the end of the hose while the motor is

running.

An acoustic warning signal sounds after 1 sec-

ond.

You may now start extracting.

8.1

Extracting dry materials

CAUTION

Hazardous dust!

-  Use a fi lter or disposal bag when extracting

hazardous materials!

The fi lter element will become damp when fl uids

are extracted. A damp filter element will clog

more quickly when dry materials are extracted.

Therefore, dry the fi lter element before extracting

dry materials or replace the damp fi lter with a dry

one.

8.2

Extracting fl uids

•   Remove the fi lter bag before extracting any fl u-

ids.

The dust extractor stops automatically when the

maximum level is reached.

If foam or fl uid starts to escape, switch off the

machine immediately and empty the dust con-

tainer.

8.3

The antistatic system

Friction inside the extraction hose causes static

electricity to develop during extraction. Operating

personnel may receive unpleasant electric shocks

while working. The mobile dust extractor is fi tted

with an antistatic system as standard to discharge

any static electricity that may develop. However,

always use the enclosed AS extraction hose.

8.4

After fi nishing work

•  Switch off the mobile dust extractor and discon-

nect the plug.

•  Empty the dust container.

•  Wind up the mains power cable on the cable hook

[1-7].

CAUTION

Hazardous dust!

-  Wipe down the mobile dust extractor and clean

all accessories thoroughly using the extrac-

tor (inside and out) before removing from the

working area.

-  Parts that you were not able to clean thoroughly

must be sealed in an airtight plastic bag prior

to transportation.

-  Wear a dust mask!

• Place the mobile dust extractor in a dry room

inaccessible to unauthorised users.

9

Service and maintenance

9.1

Acoustic warning signal

An acoustic warning signal sounds if the air speed

in the suction hose falls below 20 m/s.

Possible causes and remedies

-  Suction power adjuster setting too low:

  Set the suction power adjuster to a higher set-

ting.

-  Hose diameter setting does not match the diam-

16

eter of the connected suction hose:

  Set the correct hose diameter.

-   Suction hose clogged or kinked:

  Eliminate blockage or kink.

-  Disposal/Filter bag full:

  Change the disposal/fi lter bag.

-  Filter element clogged:

  Clean the fi lter element or replace if damaged

or heavily clogged.

9.2

Automatic fi lter cleaning

To maintain a constant suction power, the fi lter

element is cleaned automatically every 30 seconds

during operation.

We recommend cleaning the fi lter element com-

pletely if severely clogged:

After extracting with a disposal bag:

•  Set the suction power control to the maximum

setting.

•  Cover the end of the nozzle or suction hose with

your hand for 10 seconds.

NOTE

In intensive applications that generate adherent

dust, it may be necessary to clean the fi lter ele-

ment mechanically under certain circumstances

(extract). Wear a dust mask!

9.3

Changing fi lters

CAUTION

Hazardous dust!

-  Do not generate clouds of dust unnecessarily.

-  Always wear a P2 dust mask when working

with hazardous dust.

Changing the disposal bag

• Clean the fi lter element before changing the

disposal bag (Chap. 9.2).

•  Remove the top section [Fig. 2].

•  Pull the fi lter bag socket [5-2] carefully from the

intake opening [5-1].

•  Close off the fi lter bag socket with the slide piece

[5-3].

•  Close the disposal bag using the cord provided.

• Insert a new disposal bag [Fig. 3] in the clean

container.

•  Dispose of the used bag in accordance with statu-

tory regulations.

Changing the fi lter bag

•  Remove the top section [Fig. 2].

•  Pull the fi lter bag socket [5-2] carefully from the

extractor opening [5-1].

•  Close off the fi lter bag socket with the slide piece

[5-3].

•  Insert a new fi lter bag [Fig. 4].

•  Dispose of the used bag in accordance with statu-

tory regulations.

Changing the fi lter element

Never operate the machine without a fi lter ele-

ment as this may damage the motor.

•  Remove the top section [Fig. 2].

•  Pull the fi lter element upwards to remove [Fig.

6].

• Open the stirrup handle [6-3] and remove the

stirrup section.

•  Remove the fi lter retaining disc [6-1].

•  Remove the fi lter element.

Clean the fi lter seal and fi ll level tube [6-2].

•  Insert a new fi lter element.

•  Place the fi lter retaining disc in position.

•  Replace the stirrup and secure the stirrup handle.

•  Dispose of the used fi lter element in accordance

with statutory regulations.

9.4

Emptying the dust container

•  Remove the top section [Fig. 2].

•  Empty the extracted material.

•  Clean the edge of the container and replace the

top section of the extractor.

•  Clean the intake opening and the hose sleeve.

•  Dispose of the extracted material in accordance

with statutory regulations.

10 Accessories

Use only original Festool accessories and Festool

consumable material intended for this machine

because these components are designed specifi -

cally for the machine. Using accessories and con-

sumable material from other suppliers will most

likely affect the quality of your working results and

limit any warranty claims. Machine wear or your

own personal workload may increase depending on

the application. Protect yourself and your machine,

and preserve your warranty claims by always using

original Festool accessories and Festool consum-

able material!

11

Disposal

Do not throw the power tool in your household

waste! Dispose of the machine, accessories and

packaging at an environmentally-responsible

recycling centre! Observe the valid national regu-

lations.

EU only:

 European Directive 2002/96/EC stipulates

that used electric power tools must be collected

separately and disposed of at an environmentally

responsible recycling centre.

17

12 Warranty

For our tools, we give warranty for material and

production defects in accordance with the locally

applicable legal provisions, but in any case for at

least 12 months. Within the EU member states,

the warranty period is 24 months (verification

through invoice or delivery note). Damage caused

by the operator, natural wear, overloading, incor-

rect handling or through the use of the equipment

not specifi ed in the operating manual, or damage

which was known at the time of purchase, is not

covered by the warranty. Furthermore, damage

caused by the use of non-original Festool accesso-

ries and consumable material (e.g. sanding pads)

is also excluded. Complaints can only be recog-

nised if the tool is returned while still assembled

to the supplier or an authorised Festool Customer

Service workshop. Keep the operating manual,

safety instructions, spare parts list and purchase

receipt in a safe place. Otherwise the respective,

current warranty conditions of the manufacturer

shall apply.

Note

Due to continuous research and development work,

we reserve the right to make changes to the techni-

cal content of this documentation.

13

EU Declaration of Conformity

Mobile dust extractor

Serial no.

SRM 45 E-LHS 225

495079, 495080,

495081, 495082, 495499

Mobile dust extractor

Serial no.

Year of CE mark: 2007

We solely declare that this product conforms with

the following standards and normative documents:

EN 60335-1, EN 60335-2-69, EN 55014-1, EN

55014-2, EN 61000-3-2, EN 61000-3-3 in accord-

ance with the regulations in Directives 2006/95/

EC (until 28 Dec. 2009), 2006/42/EC (from 29 Dec.

2009), 2004/108/EC.

Dr. Johannes Steimel

Head of Research, Development and Technical

Documentation

Festool GmbH

Wertstraße 20

D-73240 Wendlingen

REACH for Festool products, their accessories

and consumables

REACh is a European Chemical Directive that

came into effect in 2007. As “downstream users”

and product manufacturers, we are aware of our

duty to provide our customers with information.

We have set up the following website to keep you

updated with all the latest news and provide you

with information on all the materials used in our

existing products:

www.festool.com/reach

14 Troubleshooting

Problem

Possible causes

Remedy

Extractor blows out

dust.

Dust entered the area around the

fi lter element retainer when the fi l-

ter element was changed.

Clean the fi lter element retainer.

The fi lter element is not installed

correctly / faulty.

Check that the fi lter element is installed cor-

rectly if necessary.

Acoustic warning

signal sounds.

Suction power setting too low.

Adjust the suction power to a higher setting.

Hose diameter setting does not

match the diameter of the connec-

ted suction hose.

Select the correct the suction hose diameter

(for

PLANEX

 use D = 36 mm).

Suction hose blocked or kinked.

Remove blockage and straighten hose.

Disposal bag full

Replace disposal bag.

You are working with the RTS/RS

400, DTS/DS 400, ETS/ES 125.

Please use the adapter with bypass function:

part no. 496112.

18

Problem

Possible causes

Remedy

Filter element on SRM 45 E

PLANEX

 blocked / clogged.

Clean the fi lter element regularly:

Option 1: Set the suction power control to the

maximum setting. Cover the nozzle, suction

hose or intake opening on the extractor with

the surface of your hand for 10 seconds until

the automatic cleaning cycle starts.

To clean the second fi lter half: switch off the

machine, switch on again and repeat the pro-

cedure.

Option 2: Clean the fi lter element mechanically

(extracting).

Option 3: Check the fi lter element for damage

and clogging. Insert a new fi lter element regu-

larly.

Disposal bag inserted incorrectly

The holes punched in the disposal bag must be

inside the container.

Paper bag inserted instead of dis-

posal bag.

Always work with the disposal bag when oper-

ating the

PLANEX

 (black bag).

Suction power de-

creases.

Filter element on SRM 45 E

PLANEX

 blocked / clogged.

Clean the fi lter element regularly:

Option 1: Set the suction power control to the

maximum setting. Cover the nozzle, suction

hose or intake opening on the extractor with

the surface of your hand for 10 seconds until

the automatic cleaning cycle starts.

To clean the second fi lter half: switch off the

machine, switch on again and repeat the pro-

cedure.

Option 2: Clean the fi lter element mechanically

(extracting).

Option 3: Check the fi lter element for damage

and clogging. Insert a new fi lter element regu-

larly.

Disposal bag inserted incorrectly.

The holes punched in the disposal bag must be

inside the container.

Paper bag inserted instead of dis-

posal bag.

Always work with the disposal bag when oper-

ating the

PLANEX

 (black bag).

Suction power setting on SRM 45 E

too low

Increase the suction power setting on the ext-

ractor.

Suction hose blocked or kinked.

Remove blockage and straighten hose.

Disposal bag full

Dispose of the bag.

Extractor switches

off automatically.

Disposal bag full

Dispose of the bag.

19

Problem

Possible causes

Remedy

Filter element clog-

ging.

Extreme air humidity

Clean the fi lter element regularly:

Option 1: Set the suction power control to the

maximum setting. Cover the nozzle, suction

hose or intake opening on the extractor with

the surface of your hand for 10 seconds until

the automatic cleaning cycle starts.

To clean the second fi lter half: switch off the

machine, switch on again and repeat the pro-

cedure.

Option 2: Clean the fi lter element mechanically

(extracting,).

Option 3: Check the fi lter element for damage

and clogging. Insert a new fi lter element regu-

larly.

Using special repair compounds,

e.g. extremely fi ne, soft fi ller that

generates large quantities of dust.

Clean the fi lter element regularly (see above).

Replace the fi lter element regularly.

Machining materials that are not

yet dry

Read the technical data sheets and manufac-

turer recommendations.

Using the extractor in wet and dry

mode (mixed mode)

Before using the extractor in wet mode, clean

the fi lter element thoroughly after completing

extraction and allow the fi lter element to dry

completely.

If other problems other than those listed occur, please contact your Festool service workshop or your

local specialist dealer.

20

Aspirateur mobile SRM 45 E-LHS 225

PLANEX

Sommaire

1   Symboles

2 Caractéristiques

techniques

3   Eléments de l'appareil

4   Utilisation conforme aux prescriptions

5   Consignes de sécurité

6  Mise en service

6.1  Assemblage de l'appareil

6.2  Préparation de l'utilisation avec la pon-

ceuse PLANEX

6.3  Mise en marche / arrêt de l'appareil

7 Réglages

7.1   Raccordement de l'outil électrique

7.2   Raccordement du tuyau d'aspiration

7.3   Régulation de la puissance d'aspiration

7.4   Blocage du frein

8   Travail avec la machine

8.1   Aspiration de matières sèches

8.2   Aspiration de liquides

8.3   Système antistatique

8.4   Après le travail

9  Maintenance et entretien

9.1   Signal d'avertissement acoustique

9.2  Nettoyage automatique de l'élément fi l-

trant

9.3   Remplacement du fi ltre

9.4   Vidage du bac à poussières

10 Accessoires

11  Mise au rebut

12 Garantie

13  Déclaration de conformité CE

14 Dépannage

Les illustrations indiquées se trouvent au début de

la notice d’utilisation.

1 Symboles

Avertissement de danger général

  Lire la notice / les instructions !

Portez un masque antipoussières !

2 Caractéristiques

techniques

Puissance absorbée

1200 W

Puissance connectée max. à la prise de

l'appareil. UE

2400 W

   CH, DK

1100 W

   GB

1800 W

   AUS

1200 W

Débit volumétrique (air)

max. 3600 l/mn

Dépression maxi.

23000 Pa

Surface du fi ltre

7800 cm²

Tuyau d'aspiration

Ø 36 mm x 3,5 m - AS

Niveau de pression acoustique d'après

NE 60704-2-1

66 dB(A)

Capacité du bac

45 l

Dimensions L x l x h

497x472x663 mm

Poids 16

kg

Longueur du câble d'alimentation

secteur

7,5 m

Degré de protection

IP X4

3

Eléments de l'appareil

[1-1]

 Bac à poussières

[1-2]

Orifi ce d'aspiration

[1-3]

Panneau

d'avertissement

[1-4]

 Interrupteur de l'appareil avec régulation

de la puissance d'aspiration

[1-5]

 Prise de courant de l'appareil

[1-6]

 Réglage du diamètre de tuyau

[1-7]

 Crochet pour câble

[1-8]

 Support de crochet de câble

[1-9]

Poignée

[1-10]   Bride de fermeture

[1-11]   Frein de blocage

4

Utilisation conforme aux prescriptions

Conformément aux prescriptions, les aspirateurs

mobiles sont prévus pour l'aspiration de poussières

dangereuses pour la santé avec des valeurs MAK

jusqu'à 0,1 mg/m³, ainsi que pour des poussières

de bois correspondant à la classe de poussières

"M" selon CEI 60 335-2-69.

Conformément aux prescriptions, les aspirateurs

sont prévus pour l'aspiration d'eau.

Les aspirateurs sont appropriés pour des sollicita-

tions élevées conformément à NE 60 335-1 et à NE

60 335-2-69, en cas d'utilisation industrielle.

L'utilisateur est responsable des dommages et ac-

cidents résultant d'une utilisation non conforme.

5

Consignes de sécurité

ATTENTION ! Lire toutes les consignes de

sécurité et indications.

Le non-respect des

avertissements et instructions indiqués ci-après

peut entraîner un choc électrique, un incendie et/

ou de graves blessures.
