Save all warnings and instructions for future

reference.

-  The machine should only be used by appointed

persons instructed in correct machine han-

dling.

-  Use original Festool accessories only.

-

Warning:

the machine may contain hazardous

dust. Only authorised and qualifi ed personnel

with suitable protective equipment may perform

maintenance work,  including emptying the con-

tainer and changing the fi lter. Do not operate the

machine without a fully fi tted fi lter system.

-  The machine is not intended for use by persons

(including children) with limited physical, sensory

or mental ability or without suffi cient experience

and/or knowledge, unless they are supervised by

a person responsible for their safety or have been

instructed on how to use the machine. Children

should always be supervised to ensure that they

do not play with the machine.

-  Observe the safety requirements that apply for

the dust you intend to extract.

-

Risk of explosion and fi re hazard:

 do not extract

sparks or hot dust, fl ammable or explosive dust

(e.g. magnesium, aluminium), fl ammable  or

explosive fl uids (e.g. petrol, thinner), aggressive

fl uids/solids (e.g. acid, leach, solvent). This mo-

bile dust extractor is suitable for extracting paint

dust. Operate the machine in a well-ventilated

room!

-  Pull the plug from the socket when the machine

is not in use and prior to maintenance and clean-

ing work.

-  Check the plug and the cable regularly and have

them replaced by an authorised after-sales serv-

ice workshop should either become damaged.

-  Always replace the mains power cable with the

type specifi ed in the manual.

-  Do not damage the mains power cable (e.g. by

driving over, dragging, etc.). Do not pull the plug

from socket by the cable.

-  Always use the machine socket for the purpose

specifi ed in the manual.

-  Clean the integral water level fl oat regularly and

check for damage.

-  Do not expose the machine to rain.

-  Do not lift or transport the machine by the handle

using a crane or lifting gear.

-  For reasons of safety, never operate the machine

from an unearthed socket.

6 Commissioning

WARNING

Risk of accident if the machine is operated using

unauthorised voltages or frequencies.

-   The operating voltage specifi ed on the mobile

dust extractor name plate must match the

voltage of the mains power!

-  Make sure that the mobile dust extractor is

switched off when plugging in the mains ca-

ble.

6.1

Assembling the machine

The parts included in the scope of delivery are en-

closed inside the dust container [1-1] on delivery

and must be removed before initial use.

• Affi x the accompanying sticker in your national

language over the text fi eld on the warning sign

[1-3].

Inserting the fi lter bag/disposal bag

•  Remove the top section [Fig. 2].

•  Insert the disposal bag [Fig. 3] or the fi lter bag

[Fig. 4].

• Replace the top section and close the locking

clips.

Inserting the cable hook

• Slide the cable hook [1-7] for storing the mains

power cable into the holder [1-8] from above.

6.2

Preparing for use with the

PLANEX

To use the mobile dust extractor in combination

with the PLANEX:

•  Fit the tool holder as described in the there en-

closed installation instructions.

•  You can store sandpaper, the brush segment and

the PLANEX on the tool holder storage area.

•  Only use disposal bags when performing extrac-

tion work with the PLANEX.

6.3

Switching the machine on/off

Make sure that the connected machine is

switched off before actuating the switch [1-4].

"0" switch position

Appliance socket [1-5] is disconnected from the

power, mobile dust extractor is switched off.

"MAN" switch position

Appliance socket is connected to the power, extrac-

tion motor starts.

"Auto" switch position

Appliance socket is connected to the power, extrac-

tion motor starts when the connected machine is

switched on.
