Dear Customer,
2. Important information
Thank you for choosing one of our products. Our name
Signs and symbols
stands for high-quality, thoroughly tested products for the
applications in the areas of heat, weight, blood pressure,
The following symbols are used in these instructions for
body temperature, pulse, gentle therapy, massage and air.
use, on the packaging and on the type plate for the device
Please read these instructions for use carefully and keep
and accessories:
them for later use, be sure to make them accessible to other
Caution
users and observe the information they contain.
Best regards,
Your Beurer Team
Note
Note on important information
1. Getting to know your instrument
The wrist blood pressure monitor is used for non-invasive
Follow instructions for use
measurement and monitoring of adults’ arterial blood pres-
sure. You can use it to measure your blood pressure quickly
Type BF applied part
and easily, storing the results and displaying the progres-
sion of readings together with the average.
A warning is issued for anyone suffering from cardiac
Direct current
arrhythmia.
The values determined are classified and graphically evalu-
Disposal in accordance with EC Directive
ated according to WHO guidelines.
2002/96/EC – WEEE (Waste Electrical and
Keep these instructions carefully for further use and also let
Electronic Equipment).
other users have access to them.
13
•
Do not take a measurement within 30 minutes after eat-
Manufacturer
ing, drinking, smoking or exercising.
•
Repeat the measurement if you are unsure of the meas-
60°C
Temperature limitation
ured value.
-10°C
•
The measurements taken by you are for your information
only – they are not a substitute for a medical examination!
Permissible storage humidity
Discuss the measurements with your doctor, and never
base any medical decisions on them (e.g. medicines and
RH 10-90%
their administration)!
•
Do not use the blood pressure monitor on newborns,
Keep dry
pregnant women or patients with preeclampsia.
•
In the case of restricted circulation on the arm as a result
of chronic or acute vascular diseases (including vascu-
SN Serial number
lar constriction), the accuracy of the wrist measurement is
The CE labelling certifies that the prod-
limited. In this case you should avoid using an upper arm
uct complies with the essential require-
blood pressure monitor.
0483
ments of Directive 93/42/EEC on medical
•
Cardiovascular diseases may lead to incorrect measure-
products.
ments or have a detrimental effect on measurement accu-
racy. The same also applies to very low blood pressure,
Advice on use
diabetes, circulatory disorders and arrhythmias as well as
chills or shaking.
•
In order to ensure comparable values, always measure
•
The blood pressure monitor must not be used in connec-
your blood pressure at the same time of day.
tion with a high-frequency surgical unit.
•
Before every measurement, relax for about five minutes.
•
Only use the unit on people who have the specified wrist
•
If you want to perform several measurements on the same
measurement for the device.
person, wait five minutes between each measurement.
•
Please note that when inflating, the functions of the limb
in question may be impaired.
14
•
During the blood pressure measurement, blood circulation
– You should protect the device from impact, moisture,
must not be stopped for an unnecessarily long time. If the
dirt, major temperature fluctuations and direct exposure
device malfunctions, remove the cuff from the arm.
to the sun’s rays.
•
Do not allow sustained pressure in the cuff or frequent
– Never drop the device.
measurements. The resulting restriction of the blood flow
– Do not use near strong electromagnetic fields, i.e. keep
may cause injury.
it away from any radio systems and mobile phones.
•
Ensure that the cuff is not placed on an arm in which the
– Only ever use the cuffs provided with the monitor or
arteries or veins are undergoing medical treatment, e.g.
original replacement cuffs. Otherwise erroneous results
intravascular access or therapy, or an arteriovenous (AV)
will be recorded.
shunt.
•
Do not press any buttons until the cuff is in position.
•
Do not use the cuff on people who have undergone a
•
If the instrument is not used for any length of time, we
mastectomy.
recommend removing the batteries.
•
Do not place the cuff over wounds as this may cause fur-
Advice on batteries
ther injury.
•
The blood pressure monitor can only be operated with
•
Batteries can be fatal if swallowed. You should therefore
batteries.
store the batteries and products where they are inaccessi-
•
To conserve the batteries, the monitor switches off auto-
ble to small children. If a battery has been swallowed, call
matically if no buttons are pressed for one minute.
a doctor immediately.
•
The device is only intended for the purpose described in
•
Batteries should not be charged or reactivated with any
these instructions for use. The manufacturer is not liable
other means, nor should they be taken apart, thrown in
for damage resulting from improper or careless use.
the fire or short-circuited.
•
Remove the batteries from the instrument if they are worn
Storage and Care
out or if you are not going to use the instrument for any
•
The blood pressure monitor is made up of precision elec-
length of time. This prevents any damage as a result of
tronic components. Accuracy of readings and the instru-
leakage. Always replace all the batteries at the same time.
ment’s service life depend on careful handling.
15
•
Never use different types of battery, battery brands or
3. Unit description
batteries with different capacities. You should preferably
1. LCD Display
use alkaline batteries.
1
2. Battery Cover
2
3. Date/Time Set Key
Repair and disposal
4
4. Memory Recall Key M
•
Batteries do not belong in domestic refuse. Used batteries
5. ON/OFF Key
7
should be disposed of at the collection points provided.
6. User-Switching Key
•
Never open the instrument. If these instructions are not
6
7. Wrist Cuff
heeded, the warranty will be null and void.
3
•
Never attempt to repair the instrument or adjust it your-
5
self. We can no longer guarantee perfect functioning if
you do.
Icons in the display:
•
Repairs may only be performed by Beurer Customer Ser-
vice or authorized dealers. However, always check the
1. Date/Time Indicator
1
batteries and replace them if necessary prior to making
2. WHO classification
3. Memory Zones
2
any complaint.
10
•
The appliance should be disposed of according to
4. Weak Battery Mark
5. Memory Sequence Number
3
Regulation 2002/96/EC-WEEE (Waste Electrical
9
6. Cardiac arrhythmia icon
4
and Electronic Equipment). In case of queries,
please contact the municipal authorities responsible for
7. Pulse Mark
waste disposal in your area.
8. Pulse Rate
5
8
9. Diastolic Pressure
6
7
10. Systolic Pressure
11. Problem shown on the display
11
16
4. Prepare measurement
Press the key and to adjust the month. Then press the
and in turn to adjust the date, hour, minute and con-
Inserting battery
firm the entry .
•
Remove the battery compartment cover.
The time is being displayed in 12-hour format, which means
•
Insert the two batteries into the battery compartment
a time from 13:00 onwards is being displayed as pm 1:00.
ensuring correct polarity.
•
Use exclusively brand-name batteries of the type 2 x 1.5 V
5. Measuring blood pressure
Micro (Alkaline Type LR03).
Positioning cuff
•
Then close the battery compartment by fitting the cover
and clicking it in position.
If the battery change is continuously illuminated, meas-
urement is no longer possible and you must replace all the bat-
teries. Once batteries have been removed from the device, the
time must be reset. The stored measured values are last.
Used batteries do not belong in the household waste. You are
legally obliged to dispose of the batteries. Dispose of them
•
Bare your left wrist, making sure that the circulation in the
via your specialist electrical supplier or local collec ting point
arm is not restricted by any clothes etc. that are too tight.
for recyclable waste.
Position the cuff on the inside of your wrist.
Note:
Batteries containing pollutant substances
•
Fasten the cuff with the Velcro fastening so that the upper
are marked as follows: Pb = Battery contains
edge of the monitor is positioned approx. 1 cm below the
lead, Cd = Battery contains cadmium,
ball of your thumb.
Hg = Battery contains mercury.
•
The cuff has to be fitted tightly around the wristbut should
not constrict it.
Setting date and time
It is vital to set date and time. Only in this way is it possi-
Important: The instrument should only be operated with the
ble to save and subsequently retrieve your measured values
original cuff.
with the right date and time.
17
Correct posture
Measuring blood pressure
•
Rest for approx. 5 minutes before each measurement.
•
Put on the cuff as described previously and assume the
Otherwise there may be divergences.
position in which you want to carry out the measurement.
•
You can perform the measurement while
•
Press the User-Switching key
to select a memory
sitting or lying. To carry out a blood
zone, and press the key 2x to start measurement in
pressure measurement, make sure you
the chosen memory zone. After checking the display with
are sitting comfortably with your arms
all digits lighting up, the monitor will automatically inflate.
and back leaning on something. Do not
Following the self-test, during which all display elements
cross your legs. Place your feet flat on
briefly appear, the measurement begins. During inflation
the ground. Make sure to rest your arm
the device already determines measured values used to
and move it. Always make sure that the cuff is at heart
estimate the required inflation pressure. If this pressure is
level. Otherwise significant deviations can occur. Relax
insufficient, the device automatically inflates by another
your arm and the palm of your hand.
40 mmHg (Real Fuzzy Logic).
•
In order not to distort the result, it is important to keep still
•
Then the pressure in the cuff is slowly released and the
during the measurement and not talk.
pulse is measured.
•
When the measurement has been completed, the remain-
Select memory
ing air pressure is released very quickly. The pulse, the
You have two memories (50 memory spaces each) in order to
systolic and the diastolic blood pressure are displayed.
save the test results of 2 different people separately, or else
•
The device requires approx. 5 seconds to store the deter-
save measurements in the morning and evening separately.
mined measured value.
Select the required memory space by pressing the user
•
You can interrupt measurement at any time by pressing
selection button
.
the ON/OFF button .
•
To switch off and release the pressure, press the ON/OFF
button again. If you forget to switch off the device, it
switches off automatically after approx. 1 minute.
Wait at least 5 minutes before taking another measurement!
18
• • • • • • • • • • • • •
Evaluating results
move during the measurement. If the icon appears often,
Cardiac arrhythmia:
please contact your doctor. Any self-diagnosis and treat-
ment based on the test results may be dangerous. It is vital
This instrument can identify possible cardiac arrhythmia dis-
to follow your doctor’s instructions.
orders during measurement and if necessary indicates the
measurement with the flashing icon
.
WHO classification:
This may be an indicator for arrhythmia. Arrhythmia is a
The World Health Organization (WHO) and National High
condition where the heart rhythm is abnormal as a result of
Blood Pressure Education Program Coordinating Commit-
defects in the bioelectrical system controlling the heart beat.
tee have developed a blood pressure standard, according to
The symptoms (omitted or premature heart beats, slow or
which areas of low- and high-risk blood pressure are identi-
excessively fast heart rate) may be caused, among other
fied. This standard, however, is a general guideline as indi-
things, by heart disease, age, physical predisposition, exces-
vidual’s blood pressure varies among different people and
sive use of stimulants, stress or lack of sleep. Arrhythmia can
different age groups ... etc.
only be ascertained through examination by your doctor.
It is important that you consult with your physician regu-
Repeat the measurement if the flashing icon is dis-
larly. Your physician will tell you your normal blood pres-
played after the measurement. Please note that you should
sure range as well as the point at which you will be consid-
rest for 5 minutes between measurements and not talk or
ered at risk.
Table for classification of blood pressure values (unit of measurement mmHg) for adults:
Range Systolic Diastolic Action
Hypotonia (degraded blood pressure) lower than 105 lower than 60 Check with doctor
Normal range between 105 and 120 between 60 and 80 Self check
Pre-hypertensive blood pressure range (*)
between 120 and 140 between 80 and 90 Check with doctor
High blood pressure - degree
between 140 and 160 between 90 and 100 Consult your doctor
High blood pressure - degree
higher than 160 higher than 100
Consult your doctor
(*) Blood pressure range that might transfer to high blood pressure Adapted from JNC 2003
19
The WHO classification in the display shows the range of
7. Cleaning and storing the instrument
the measured blood pressure.
•
Clean your blood pressure monitor carefully using a
If the values for systolic and diastolic pressure are in two dif-
slightly damp cloth only.
ferent WHO ranges (e.g. systolic in the grade
hyperten-
•
Do not use any detergents or solvents.
sion range and diastolic pressure in the normal range), the
•
Never hold the instrument under water as otherwise liquid
WHO classification on the unit always indicates the higher
can penetrate and damage the instrument.
range (grade hypertension in the example described).
•
Never place any heavy objects on the instrument.
6. Saving, retrieving and deleting results
8. Rectifying faults
The computer automatically saves the blood pressure read-
Error messages can occur when
ings of the last 50 measurements. When the 50 memory
•
the blood-pressure value is unusually high or low (
locations are exceeded, the current oldest value is deleted.
appears in the display),
You can display the memory as follows:
•
you move or talk during the measurement ( appears in
•
Press the User-Switching key
to select a mem-
the display),
ory zone, and press the M key to switch from memory to
•
the cuff tube is not properly inserted ( appears in the
memory with sequence numbers.
display),
•
The saved measured values are continuously stored.
•
inflation takes longer than 20 seconds ( appears in the
•
Press the On/Off switch to turn the unit off.
display),
•
If you forget to switch off the computer, it will switch off
•
the inflation pressure is higher than 300 mmHg (
automatically after 1 minute.
appears in the display),
Press the User-Switching key
to select a memory
•
an error occurs when storing the measured values (
zone, then press and hold the M key for approximately
appears in the display),
5-seconds to clear the data in the pre-designated memory
•
Exceeding measurement range ( appears in the display).
zone. The data in both memory zones – zone 1 and zone 2
In the about cases, you must repeat the measurement. Put
may be erased if any of the batteries is removed.
the batteries back in if necessary, or else replace them.
20
9. Specifications
Power supply
2 x 1,5 V
AA batteries
Model no. BC 16
Battery life For approx. 300 measurements,
Measurement
Oscillometric, non-invasive blood
depending on the blood pressure
method
pressure measurement on the wrist
level and/or pump pressure
Measurement range Cuff pressure 0 – 299 mmHg,
Accessories Instruction for use, 2 x 1.5 V AA bat-
systolic 30 – 260 mmHg,
teries, storage box
diastolic 30 – 260 mmHg,
Classification Internal supply, IPX0, no AP or
Pulse 40 – 199 beats/minute
APG, continuous operation, type BF
Display accuracy Systolic ± 3 mmHg,
applied part
diastolic ± 3 mmHg,
Technical information is subject to change without notifica-
pulse ± 5 % of the value shown
tion to allow for updates.
Measurement
Max. permissible standard deviation
inaccuracy
according to clinical testing:
•
This unit is in line with European Standard EN 60601-1-2
systolic 8 mmHg /diastolic 8 mmHg
and is subject to particular precautions with regard to
electromagnetic compatibility (EMC). Please note that
Memory 2 x 50 memory spaces
portable and mobile HF communication systems may
Dimensions L 82 mm x W 69 mm x H 28 mm
interfere with this unit. More details can be requested from
Weight Approx. 120 g (without batteries)
the stated Customer Service address or found at the end
Cuff size 135 to 220 mm
of the instructions for use.
•
This device is in line with the EU Medical Devices Direc-
Permissible operating
+10 °C to +40 °C, 40 – 85 % relative
tive 93/42/EC, the “Medizinproduktegesetz” (German
conditions
air humidity (non-condensing)
Medical Devices Act) and the standards EN1060-1
Permissible storage
-10 °C to +60 °C, 10 – 90 % relative
(non-invasive sphygmomanometers, Part 1: General
conditions
air humidity, 800-1050 hPa ambient
requirements), EN1060-3 (non-invasive sphygmoma-
pressure
nometers, Part 3: Supplementary requirements for elec-
21
tro-mechanical blood pressure measuring systems)
and IEC80601-2-30 (Medical electrical equipment –
Part 2 – 30: Particular requirements for the safety and
essential performance of automated non-invasive blood
pressure monitors).
•
The accuracy of this blood pressure monitor has been
carefully checked and developed with regard to a long
useful life. If using the device for commercial medical pur-
poses, it must be regularly tested for accuracy by appro-
priate means. Precise instructions for checking accuracy
may be requested from the service address.
22
