Start-up and use

!

 The glue applied on the gaskets leaves traces of

grease on the glass. Before using the appliance, we

recommend you remove these with a special non-

abrasive cleaning product. During the fi rst few hours of

use there may be a smell of rubber which will disappear

very quickly.

!

 A few seconds after the hob is connected to the electricity

supply, a buzzer will sound. The hob may now be switched

on.

Types of noise during normal hob operation:

•

Buzz:

 due to the vibration of the metallic parts that

make up the induction element and the pot; it is

generated by the electromagnetic fi eld required for

heating and increases as the power of the induction

element increases.

•

Soft whistle:

 heard when the pot placed on the

heating zone is empty; the noise disappears once

food or water is placed into the pot.

•

Crackle:

 produced by the vibration of materials on

the bottom of the pot due to the fl ow of parasitic

currents caused by electromagnetic fi elds

(induction); can be more or less intense depending

on the material making up the bottom of the pot, and

decreases as the pot dimensions increase.

•

Loud whistle:

 heard when two induction elements of

the same group function simultaneously at maximum

power and/or when the booster function is set on

the larger element while the other is auto-adjusted.

Noise is reduced by decreasing the power level of

the auto-adjusted induction element; pot bottom

layers made of different kinds of materials are among

the main causes of this noise.

•

Fan noise:

 a fan is necessary to ensure the hob

functions correctly and to safeguard the electronic

unit from possible overheating. The fan functions at

maximum power when the large induction element is

at maximum power or when the booster function is on;

in all other cases, it works at average power depending

on the temperature detected. Furthermore, the fan may

continue to work even after switching the hob off, if the

temperature detected is high.

The types of noise listed above are due to induction

technology and are not necessarily operational faults.

!

 If the

-

 or

+

 button is pressed for an extended

period of time, the display scrolls quickly though the

power levels and timer minutes.

Switching on the hob

To switch the hob on, press and hold the

 button for

approximately one second.

Switching on the cooking zones

Each cooking zone is controlled using a selector button

and a power adjustment device consisting of a double

-

 and

+

 button.

•  To begin operating a cooking zone, press the

corresponding control button and set the desired power

level (between 0 and 9) using the buttons

-

 and

+

.

Booster function*

The booster function for some of the cooking zones may

be used to shorten heating-up times. It may be activated

by pressing the

Booster

 button. The indicator light directly

above the button will illuminate. This function boosts the

power to 2000 W or 3000 W, depending on the size of the

relevant cooking zone.

The booster stops automatically after 4 minutes. While

the booster for one of the cooking zones is active, the

corresponding front or rear cooking zone will operate

at a reduced power level (e.g. if the booster for the rear

left-hand hotplate has been activated, the power level of

the front left-hand hotplate will be reduced). For further

information, please refer to the

Technical description of

the models

.

Switching off the cooking zones

To switch off a cooking zone, select it using the corresponding

selector button

 and:

•  Press the

-

 button: the power of the cooking zone will

progressively decrease until it is switched off.

Programming the cooking duration

!

 All the cooking zones may be programmed

simultaneously, for a duration between 1 and 99 minutes.

1. Select the cooking zone using the corresponding

selector button.

2. Adjust the power level of the cooking zone.

3. Press the

 programming button. The indicator light

corresponding to the selected zone will start fl ashing.

10

GB

4. Set the cooking duration using the

-

 and

+

buttons.

5. Confi rm by pressing the

  button or automatic

selection occurs after 10 seconds.

The timer begins counting down immediately.

A buzzer sounds for approximately 1 minute and the

cooking zone switches off when the set programme has

fi nished.

Repeat the above procedure for each hotplate you wish

to programme.

Using multiple programmes and the display

If one or more hotplates are programmed, the display

will show the data for the hotplate with the least time

remaining, and the light corresponding to the position of

the hotplate will fl ash. The lights corresponding to the

other hotplates programmed will be switched on.

To visualise the time remaining for the other

programmed hotplates, press the

 button

repeatedly: the time remaining for each hotplate will be

shown sequentially in a clockwise order,

starting from the front left hotplate.

Changing the programme

1. Press the

 button repeatedly until the duration

you wish to change is shown.

2. Use the

 buttons to set the new duration.

3. Confi rm by pressing the

 button.

To cancel a programme, follow the above instructions.

At step 2, press the

-

 button: the duration decreases

progressively until it reaches 0 and switches off. The

programme resets and the display exits programming

mode.

Timer

The hob must be switched on.

The timer can be used to set a duration up to 99

minutes.

1. Press the

 programming button until the timer

indicator light is illuminated

.

2. Set the desired duration using the

-

 and

+

 buttons.

3. Confi rm by pressing the

 button.

The timer begins counting down immediately. When the

time has elapsed, a buzzer will sound (for one minute).

Control panel lock

When the hob is switched on, it is possible to lock the

oven controls in order to avoid accidental changes

being made to the settings (by children, during cleaning,

etc.). Press the

 button to lock the control panel:

the indicator light above the button will switch on.

To use any of the controls (e.g. to stop cooking), you

must switch off this function. Press the

 button for a

few moments, the indicator light will switch off and the

lock function will be removed.

Switching off the hob

Press the button

 to switch off the appliance - do not

rely solely on the pan sensor.

If the control panel lock has been activated, the controls

will continue to be locked even after the hob is switched

on again. In order to switch the hob on again, you must

fi rst remove the lock function.

“Demo” mode

It is possible to set the hob to a demonstration mode

where all the controls work normally but the heating

elements do not switch on. To activate the “demo” mode

the hob must be switched on, with all the hotplates

switched off.

•  Press and hold the

+

 and

-

 buttons simultaneously

for 6 seconds. When the 6 seconds have elapsed,

the ON/OFF and CONTROLS LOCKED indicator

lights will fl ash for one second. Release the

+

 and

-

 buttons and press the

 button;

•  The display will show the text DE and MO and the

hob will be switched off.

•  When the hob is switched on again it will be set to

the “demo” mode.

To exit this mode, follow the procedure described

above. The display will show the text DE and OF and

the hob will be switched off. When it is next switched

on, the hob will function normally.

Practical advice on using the appliance

!

 Use cookware made from materials which are

compatible with the induction principle (ferromagnetic

material). We especially recommend pans made from:

cast iron, coated steel or special stainless steel adapted

for induction. Use a magnet to test the compatibility of

11

GB

The FlexiZONE mode

The FLEXI Zone can be used to set the power of two

„interconnected” hotplates to the same level. It can be

activated if the two hotplates are OFF, by pressing the

FLEXI ZONE button

The FLEXI ZONE can be activated while the hob is on

by pressing the FLEXI ZONE button once; the LEDs

corresponding to both linked hotplates light up.

The 2 LEDs remain lit as long as the hotplates are

linked (if FLEXI ZONE button is pressed again, the

hotplates are disconnected and are both set to power

level 0).

Pressing the +, - or Max buttons for one of the two Flexi

hotplates also affects the display corresponding to the

other hotplate.

To deactivate the FLEXI ZONE, press the  button     .

A timer may be set for the FLEXI zone; this appears on

the display and both LEDs corresponding to the linked

hotplates light up.  When the Timer button is pressed,

the two linked hotplates are treated as if they were a

single zone.

Selecting and using  FLEXI ZONE

To begin using the FLEXI ZONE, press the      button.

To set the power level (see above).

 FLEXI ZONE operation

Once you have selected FLEXI ZONE by pressing

the button   , the 2  LEDs corresponding to the  FLEXI

ZONE for both hotplates light up; it will then be possible

to control both as if they were a single zone. The power

level will appear on both displays. If only the upper or

lower part is in use, the display corresponding to the

unused zone will begin to fl ash, and after 3 minutes

cooking will automatically revert to standard mode (not

FLEXI).

! Once activated, the FLEXI ZONE can also be

programmed, using the same procedure as described

for the individual hotplates.

! Accessories

For optimal FLEXI ZONE performance, we recommend

the use of pans with an elliptical or elongated base and

a major diameter of at least 250 mm; if using pans with

a smaller diameter, we recommend positioning them in

the upper or lower part as indicated by the X symbol.

If the saucepan is not in the centre of the screen

printing detail, you may hear a whistling sound or

a slight buzzing noise; this does not indicate a hob

malfunction. We recommend adjusting the position of

the pan so that it is in the centre of the FLEXI ZONE.

Practical cooking advice

ª

Pressure cooking

Pressure cooker

Frying

Grilling

Boiling

Very high-flame

cooking

High-flame

cooking

Medium-flame cooking

Low-flame

cooking

Very

low-flame

cooking

•

•

¶

Crêpes

Cooking on a high flame and browning

(roasts, steaks, escalopes, fish fillets,

fried eggs)

¶

§

Fast thickening (liquid juices)

Boiling water (pasta, rice, vegetables)

Milk

§

S

Slow thickening (dense juices)

S

¢

Bain-marie cooking

Pressure cooking after whistle

¢

£

™

Low-flame cooking (stews)

Reheating dishes

™

¡

Chocolate sauce

Keeping food hot

12

GB

the cookware.

*

SUITABLE

UNSUITABLE

Cast iron

Enamelled steel

Special stainless steel

Copper,

Aluminium, Glass, Earthenware,

Ceramic, non magnetic Stainless steel

In addition, to obtain the best results from your hob:

•  Use pans with a thick, fl at base in order to fully utilise

the cooking zone.

•  Always use pans with a diameter which is large

enough to cover the hotplate fully, in order to use all

the available heat.

•  Make sure that the base of the cookware is always

clean and dry, in order to fully utilise and extend the

life of both the cooking zones and the cookware.

•  Avoid using the same cookware which has been

used on gas burners: the heat concentration on gas

burners may distort the base of the pan, causing it

not to adhere correctly.

Safety devices

Pan sensor

Each cooking zone is equipped with a pan sensor

device. The hotplate only emits heat when a pan with

suitable measurements for the cooking zone is placed

on it. If the indicator light is fl ashing, it may indicate:

•  An incompatible pan

•  A pan whose diameter is too small

•  The pan has been removed from the hotplate.

Overheating protection

If the electronic elements overheat, the hob switches off

automatically and

F

 appears on the display, followed

by a fl ashing number. When the temperature has

reached a suitable level, this message disappears and

the hob may be used again.

Safety switch

The appliance has a safety switch which automatically

switches the cooking zones off after they have been in

operation for a certain amount of time at a particular

power level. When the safety switch has been triggered,

the display shows “

0

”.

For example: the right rear hotplate is set to 5 and will

switch off after 5 hours of continuous operation, while

the front left hotplate is set to 2 and will switch off after

8 hours.

Buzzer

This can also indicate several irregularities:

•  An object (a pan, cutlery, etc.) has been placed on

the control panel for more than 10 seconds.

•  Something has been spilt on the control panel.

•  A button has been pressed for too long. All of the

above situations may cause the buzzer to sound.

Remove the cause of the malfunction to stop the

buzzer. If the cause of the problem is not removed,

the buzzer will keep sounding and the hob will switch

off.

Power level

1

2

3

4

5

6

7

8

9

Maximum operating time in hours

9

8

7

6

5

4

3

2

1
