Hotpoint-Ariston KIC 740 B IT: Start-up and use

9

GB

Start-up and use

!

 The glue applied on the gaskets leaves traces of grease on

the glass. Before using the appliance, we recommend you

remove these with a special non-abrasive cleaning product.

During the first few hours of use there may be a smell of

rubber which will disappear very quickly.

!

 A few seconds after the hob is connected to the electricity

supply, a buzzer will sound. The hob may now be switched

on.

!

 The software running the hob adjusts the maximum power

absorbed by all cooking zones as necessary, so that the

maximum total power output may be utilised in a flexible and

independent manner. Two operating examples are illustrated

in the pictures below.

In picture A, the front left-hand cooking zone is operating

at maximum power (level 9) and, as a result, the rear left-

hand cooking zone cannot be set any higher than level 7;

the corresponding Max indicator light is illuminated. As soon

as the power of the front cooking zone has decreased, the

corresponding Max indicator light will switch off and the rear

cooking zone may be set to a higher power level.

Picture B illustrates a similar example, but with cooking zones

positioned diagonally. If the front left-hand cooking zone is

set to maximum (level 9), the rear right-hand cooking zone

cannot be set any higher than level 4.

Information relating to the amount of energy consumed is

provided by the indicator lights

 which are illuminated

when each corresponding plate has reached its maximum

power output. When all the indicator lights corresponding to

the active hotplates are illuminated, if you wish to increase

the power level of one of the hotplates you will have to

reduce the power level of another of the active hotplates first.

5-7

5-7

8-9

8-9

1-4

1-4

8-9

8-9

A

B

Types of noise during normal hob operation:

•  Buzz: due to the vibration of the metallic parts that make

up the induction element and the pot; it is generated

by the electromagnetic field required for heating

and increases as the power of the induction element

increases.

•  Soft whistle: heard when the pot placed on the heating

zone is empty; the noise disappears once food or water is

placed into the pot.

•  Crackle: produced by the vibration of materials on the

bottom of the pot due to the flow of parasitic currents

caused by electromagnetic fields (induction); can be more

or less intense depending on the material making up the

bottom of the pot, and decreases as the pot dimensions

increase.

•  Loud whistle: heard when two induction elements of the

same group function simultaneously at maximum power

and/or when the booster function is set on the larger

element while the other is auto-adjusted. Noise is reduced

by decreasing the power level of the auto-adjusted

induction element; pot bottom layers made of different

kinds of materials are among the main causes of this

noise.

•  Fan noise: a fan is necessary to ensure the hob functions

correctly and to safeguard the electronic unit from

possible overheating. The fan functions at maximum

power when the large induction element is at maximum

power or when the booster function is on; in all other

cases, it works at average power depending on the

temperature detected. Furthermore, the fan may continue

to work even after switching the hob off, if the temperature

detected is high.

The types of noise listed above are due to induction

technology and are not necessarily operational faults.

!

 If the

-

 or

+

 button is pressed for an extended period of

time, the display scrolls quickly though the power levels and

timer minutes.

Switching on the hob

To switch the hob on, press and hold the

 button for

approximately one second.

Switching on the cooking zones

Each cooking zone is controlled using a selector button

and a power adjustment device consisting of a double

-

 and

+

 button.

•  To begin operating a cooking zone, press the

corresponding control button and set the desired power

level (between 0 and 9) using the buttons

-

 and

+

.

Switching off the cooking zones

To switch off a cooking zone, select it using the

corresponding selector button

 and:

• Press the

-

 button: the power of the cooking zone will

progressively decrease until it is switched off.

Programming the cooking duration

!

 All the cooking zones may be programmed simultaneously,

for a duration between 1 and 99 minutes.

*

 Only available in certain models.

10

GB

1. Select the cooking zone using the corresponding selector

button.

2. Adjust the power level.

3. Press the

 programming button. The indicator

light corresponding to the selected zone will start

flashing.

4. Set the cooking duration using the

-

 and

+

buttons.

5. Confirm by pressing the

 button or automatic

selection occurs after 10 seconds.

The timer begins counting down immediately. A buzzer

sounds for approximately 1 minute and the cooking zone

switches off when the set programme has finished.

Repeat the above procedure for each hotplate you wish to

programme.

Using multiple programmes and the display

If one or more hotplates are programmed, the display will

show the data for the hotplate with the least time remaining,

and the light corresponding to the position of the hotplate

will flash. The lights corresponding to the other hotplates

programmed will be switched on.

To visualise the time remaining for the other

programmed hotplates, press the

 button

repeatedly: the time remaining for each hotplate will be

shown sequentially in clockwise order, starting from the

front left hotplate.

Changing the programme

1. Press the

 button repeatedly until the

duration you wish to change is shown.

2. Use the

-

 and

+

 buttons to set the new duration.

3. Confirm by pressing the

 button.

To cancel a programme, follow the above instructions.

At step 2, press the

-

 button: the duration decreases

progressively until it reaches 0 and switches off. The

programme resets and the display exits programming mode.

Timer

The hob must be switched on.

The timer can be used to set a duration up to 99 minutes.

1. Press the

 programming button until the timer indicator

light is illuminated

.

2. Set the desired duration using the

-

 and

+

 buttons.

3. Confirm by pressing the

 button.

The timer begins counting down immediately. When the time

has elapsed, a buzzer will sound (for one minute).

Control panel lock

When the hob is switched on, it is possible to lock the oven

controls in order to avoid accidental changes being made

to the settings (by children, during cleaning, etc.). Press

the

 button to lock the control panel: the indicator light

above the button will switch on.

To use any of the controls (e.g. to stop cooking), you must

switch off this function. Press the

 button for a few

moments, the indicator light will switch off and the lock

function will be removed.

Switching off the hob

Press the

 button to switch the appliance off.

If the control panel lock has been activated, the controls

will continue to be locked even after the hob is switched on

again. In order to switch the hob on again, you must first

remove the lock function.

“Demo” mode

It is possible to set the hob to a demonstration mode where

all the controls work normally but the heating elements do

not switch on. To activate the “demo” mode the hob must be

switched on, with all the hotplates switched off.

•  Press and hold the

+

 and

-

 buttons simultaneously for

6 seconds. When the 6 seconds have elapsed, the ON/

OFF and CONTROLS LOCKED indicator lights will flash

for one second. Release the

+

 and

-

 buttons and press

the

 button;

•  The display will show the text DE and MO and the hob will

be switched off.

•  When the hob is switched on again it will be set to the

“demo” mode.

To exit this mode, follow the procedure described above.

The display will show the text DE and OF and the hob will

be switched off. When it is next switched on, the hob will

function normally.

Practical advice on using the appliance

!

 Use cookware made from materials which are compatible

with the induction principle (ferromagnetic material). We

especially recommend pans made from: cast iron, coated

steel or special stainless steel adapted for induction. Use a

magnet to test the compatibility of the cookware.

11

GB

*

SUITABLE

UNSUITABLE

Cast iron

Enamelled steel

Special stainless steel

Copper,

Aluminium, Glass, Earthenware,

Ceramic, non magnetic Stainless steel

In addition, to obtain the best results from your hob:

•  Use pans with a thick, flat base in order to fully utilise the

cooking zone.

•  Always use pans with a diameter which is large enough

to cover the hotplate fully, in order to use all the available

heat.

•  Make sure that the base of the cookware is always clean

and dry, in order to fully utilise and extend the life of both

the cooking zones and the cookware.

•  Avoid using the same cookware which has been used

on gas burners: the heat concentration on gas burners

may distort the base of the pan, causing it not to adhere

correctly.

Safety devices

Pan sensor

Each cooking zone is equipped with a pan sensor device.

The hotplate only emits heat when a pan with suitable

measurements for the cooking zone is placed on it. If the

indicator light is flashing, it may indicate:

•  An incompatible pan

•  A pan whose diameter is too small

•  The pan has been removed from the hotplate.

Overheating protection

If the electronic elements overheat, the hob switches off

automatically and

F

 appears on the display, followed by

a flashing number. When the temperature has reached a

suitable level, this message disappears and the hob may be

used again.

Residual heat indicators

Each cooking zone is equipped with a residual heat

indicator. This indicator signals which cooking zones are still

at a high temperature. If the power display shows

, the

cooking zone is still hot. It is possible, for example, to keep a

dish warm or melt butter or chocolate. As the cooking zone

cools, the power display will show

. The display switches

off when the cooking zone has cooled sufficiently.

Safety switch

The appliance has a safety switch which automatically

switches the cooking zones off after they have been in

operation for a certain amount of time at a particular power

level. When the safety switch has been triggered, the display

shows “0”.

For example: the right rear hotplate is set to 5 and will switch

off after 5 hours of continuous operation, while the front left

hotplate is set to 2 and will switch off after 8 hours.

Buzzer

This can also indicate several irregularities:

•  An object (a pan, cutlery, etc.) has been placed on the

control panel for more than 10 seconds.

•  Something has been spilt on the control panel.

•  A button has been pressed for too long. All of the above

situations may cause the buzzer to sound. Remove the

cause of the malfunction to stop the buzzer. If the cause of

the problem is not removed, the buzzer will keep sounding

and the hob will switch off.

Power level

Maximum operating

time in hours

1

9

2

8

3

7

4

6

5

5

6

4

7

3

8

2

9

1

12

GB

Practical cooking advice

V

er

y h

ig

h

-f

la

m

e

co

ok

in

g

ª

Pressure cooking

Pressure cooker

Frying

•

Grilling Boiling

H

ig

h

-f

lam

e

co

ok

in

g

• ¶

Crêpes

Cooking on a high flame and browning

(roasts, steaks, escalopes, fish fillets,

fried eggs)

M

ed

ium

-f

la

m

e c

o

o

ki

n

g

¶ §

Fast thickening (liquid juices)

Boiling water (pasta, rice, vegetables)

Milk

§ S

Slow thickening (dense juices)

S ¢

Bain-marie cooking

Pressure cooking after whistle

L

ow

-fl

am

e

co

ok

in

g

¢

Low-flame cooking

(stews)

-{}-

Reheating dishes

£ ™

Ver

y l

ow

-

fl

am

e

co

o

ki

n

g

™ ¡

Chocolate sauce

Keeping food hot
