Braun 570cc-5751 Series 5: English

English

Our products are designed to meet the

Shaver

highest standards of quality, functionality and

7 Shaver foil

design. We hope you enjoy your new Braun

8 Cutter block

Shaver.

9 Foil release buttons

10 Long hair trimmer

11 Comfort setting switch «sensitive»

Warning

12 Shaver-to-station contacts

Your shaving system is provided with a

13 On/off switch

special cord set, which has an integrated

14 Shaver display

Safety Extra Low Voltage power supply. Do

15 Cleaning light (yellow)

not exchange or tamper with any part of it,

16 Replacement light for shaving parts

otherwise there is risk of an electric shock.

17 Shaver power socket

18 Special cord set

This appliance is not intended for use by

19 Etui

children or persons with reduced physical or

mental capabilities, unless they are given

supervision by a person responsible for their

A Before shaving

safety. In general, we recommend that you

keep the appliance out of reach of children.

Prior to first use, you have to connect the

shaver to an electrical outlet using the special

To prevent the cleaning fluid from leaking,

cord set (18) or alternatively, proceed as

ensure that the Clean&Renew station is

follows:

placed on a flat surface. When a cleaning

cartridge is installed, do not tip, move

Installing the Clean&Renew station

suddenly or transport the station in any

•

Using the special cord set (18), connect the

way as cleaning fluid might spill out of the

station power socket (5) to an electrical

cartridge. Do not place the station inside a

outlet.

mirror cabinet, nor place it on a polished or

•

Press the lift button (2) to open the housing

lacquered surface.

•

Hold the cleaning cartridge (6) down on a

flat, stable surface (e.g. table).

The cleaning cartridge contains a highly

•

Carefully remove the lid from the cartridge.

flammable liquid so keep it away from

•

Slide the cartridge into the base of the

sources of ignition. Do not expose to direct

station as far as it will go.

sunlight and cigarette smoking nor store it

•

Slowly close the housing by pushing it

over a radiator.

down until it locks.

Do not refill the cartridge and use only

original Braun refill cartridges.

Charging the shaver in the Clean&Renew

station

Insert the shaver head down into the cleaning

station. (The contacts (12) on the back of the

Description

shaver will align with the contacts (3) in the

Clean&Renew™ station

cleaning station).

1 Level indicator

If required, the Clean&Renew station will start

2 Lift button for cartridge exchange

charging the shaver now.

3 Station-to-shaver contacts

4 Start button

A full charge provides up to 45 minutes of

5 Station power socket

cordless shaving time. This may vary

6 Cleaning cartridge

according to your beard growth.

6

99265630_590cc_S6-64.indd 699265630_590cc_S6-64.indd 6 26.05.2009 11:00:13 Uhr26.05.2009 11:00:13 Uhr

The best environmental temperature for

Tips for the perfect shave

charging is between 5 °C to 35 °C. Do not

For best results, Braun recommends you

expose the shaver to temperatures higher

follow 3 simple steps:

than 50 °C for extended periods of time.

1. Always shave before washing your face.

2. At all times, hold the shaver at right

angles (90°) to your skin.

Shaver display

3. Stretch your skin and shave against the

direction of your beard growth.

The shaver display (14) shows the charge

status of the battery. During charging or

when using the shaver, the respective battery

Shaving with the cord

segment will blink (green). When fully

If the shaver has run out of power

charged, all segments will light up for

(discharged), you may also shave with the

approximately one hour, provided the shaver

shaver connected to an electrical outlet via

sits in the C&R station.

the special cord set.

The red low-charge light flashes when the

battery is running low.

Cleaning

You should be able to finish your shave.

For best shaving results, we recommend

cleaning the shaver in the station after each

B Shaving

shave (see «Automatic cleaning»).

All charging and cleaning needs are then

Press the on/off switch (13) to operate the

automatically taken care of.

shaver.

Cleaning indicator

Comfort setting switch «sensitive»

Clean your shaver in the Clean&Renew

Setting the shaver head according to your

station at the latest when the yellow cleaning

comfort needs.

light (15) shines constantly after shaving.

If this is not done, the cleaning light will go

The «sensitive» switch (11) provides three

off after some time and the counter will be

options for comfort setting:

reset.

1 « + » :

The shaver head is in full swing, freely

follows the contours of your skin to

C Automatic cleaning

provide more comfort.

The Clean&Renew has been developed for

2 middle position:

cleaning, charging and storing your shaver.

The shaver head is semi-fixed for more

After each shave, return the shaver to the

control.

Clean&Renew station and proceed as

3 « – » :

follows:

The shaver head is fixed for full control

•

Insert the shaver head down into the

and precise handling in hard to reach

cleaning station.

areas.

•

Push down the start button (4). The clean-

ing process will start (approx. 5 minutes

Long hair trimmer

cleaning, 4 hours drying).

To trim sideburns, moustache or beard, slide

•

Do not interrupt the cleaning process, as

the long hair trimmer (10) upwards.

it leaves the shaver wet and not fit for use.

7

99265630_590cc_S6-64.indd 799265630_590cc_S6-64.indd 7 26.05.2009 11:00:14 Uhr26.05.2009 11:00:14 Uhr

If interruption is needed nonetheless, press

Rinsing the shaver head under running water

the start button (4).

is an alternative way to keep the shaver

•

When cleaning is finished, the yellow

clean, especially when traveling:

cleaning light will go off and the shaver is

•

Switch the shaver on (cordless) and rinse

ready for use.

the shaver head under hot running water.

•

A cleaning cartridge should be sufficient for

You may use liquid soap without abrasive

about 30 cleaning cycles. When the level

substances. Rinse off all foam and let the

indicator (1) has reached the «min» mark,

shaver run for a few more seconds.

the remaining fluid in the cartridge is

•

Next, switch off the shaver, press the foil

sufficient for about 5 more cycles. Then the

release buttons (9) to remove the shaver

cartridge should be replaced, when used

foil (7) and cutter block (8). Then leave the

daily approx. every 4 weeks.

disassembled shaving parts to dry.

•

The hygienic cleaning cartridge contains

•

If you regularly clean the shaver under

alcohol, which once opened will naturally

water, then once a week apply a drop of

evaporate slowly into the surrounding air.

light machine oil onto the long hair trimmer

Each cartridge, if not daily used, should be

(10) and shaver foil (7).

replaced after approximately 8 weeks.

•

The cleaning cartridge also contains

The following quick cleaning is another

lubricates, which may leave residual marks

alternative cleaning method:

on the shaver head after cleaning.

•

Press the foil release buttons (9) to lift

However, these marks can be removed

the shaver foil (do not remove the foil

easily by wiping gently with a cloth or soft

completely). Switch on the shaver for

tissue paper.

approx. 5–10 seconds so that the shaved

stubbles can fall out.

Cleaning the housing

•

Switch off the shaver. Remove the shaver

From time to time clean the housing of the

foil and tap it out on a flat surface. Using a

shaver and the Clean&Renew station with a

brush, clean the inner area of the shaver

damp cloth, especially inside the cleaning

head. However, do not clean the shaver foil

chamber where the shaver rests.

nor the cutter block with the brush as this

will damage them.

Replacing the cleaning cartridge

After having pressed the lift button (2) to

open the housing, wait for a few seconds

Keeping your shaver in top

before removing the used cartridge to avoid

shape

any dripping.

Before discarding the used cartridge, make

Replacing the foil and cutter block/reset

sure to close the openings using the lid of the

To maintain 100% shaving performance,

new cartridge, since the used cartridge will

replace the shaver foil (7) and cutter block (8),

contain contaminated cleaning solution.

when the replacement symbol (16) lights up

(after about 18 months) or when cassette is

worn.

The replacement symbol will remind you

D Manual cleaning

during the next 7 shaves to replace the

shaver foil and cutter block. Then the shaver

The shaver head is suitable for

will automatically reset the display.

cleaning under running tap water.

Warning: Detach the shaver from the

After you have replaced the shaver foil and

power supply before cleaning the

cutter block, press the on/off switch (13) for

shaver head in water.

at least 5 seconds to reset the counter.

8

99265630_590cc_S6-64.indd 899265630_590cc_S6-64.indd 8 26.05.2009 11:00:14 Uhr26.05.2009 11:00:14 Uhr

While doing so, the replacement light blinks

and goes off when the reset is complete. The

manual reset can be done at any time.

Accessories

Available at your dealer or Braun Service

Centres:

•

Shaver foil and cutter block: 51B

•

Cleaning cartridge Clean&Renew: CCR

Environmental notice

This product contains rechargeable

batteries. In the interest of protecting

the environment, please do not

dispose of the product in the house-

hold waste at the end of its useful life.

Disposal can take place at a Braun Service

Centre or at appropriate collection points

provided in your country.

The cleaning cartridge can be disposed with

regular household waste.

Subject to change without notice.

This product conforms to the European

Directives EMC 2004/108/EC and Low

Voltage 2006/95/EC.

For electric specifications, see printing on the

special cord set.
