Technische Daten
HDS 7/11
HDS 7/12 *AU HDS 8/17
HDS 8/17
Classic *KAP
Classic *KAP
*AU/Classic
*EU
Netzanschluss
Spannung V 220 240 220 400-420
Stromart Hz 1~ 60 1~ 50 3~ 60 3~ 50
Anschlussleistung kW 3,4 3,4 5,5 5,5
Absicherung (träge) A 16 15 32 16
Schutzart -- IPX5 IPX5 IPX5 IPX5
Schutzklasse -- I I I I
Maximal zulässige Netzimpedanz Ohm (0,321+
(0,321+
-- --
j0,200)
j0,200)
Wasseranschluss
Zulauftemperatur (max.) °C 30 30 30 30
Zulaufmenge (min.) l/h (l/min) 1000 (16,7) 1000 (16,7) 1100 (18,3) 1100 (18,3)
Saughöhe aus offenem Behälter (20 °C) m 0,5 0,5 0,5 0,5
Zulaufdruck (max.) MPa (bar) 0,6 (6) 0,6 (6) 0,6 (6) 0,6 (6)
Leistungsdaten
Fördermenge Wasser l/h (l/min) 350-700 (5,8-
350-700 (5,8-
400-800 (6,7-
400-800 (6,7-
11,7)
11,7)
13,3)
13,3)
Arbeitsdruck Wasser (mit Standarddü-
MPa (bar) 3-11 (30-110) 3-12 (30-120) 3-17 (30-170) 3-17 (30-170)
se)
Max. Betriebsüberdruck (Sicherheits-
MPa (bar) 14 (140) 15 (150) 20,5 (205) 20,5 (205)
ventil)
Fördermenge Dampfbetrieb l/h (l/min) 330-360 (5,5-
330-360 (5,5-
340-420 (5,6-
340-420 (5,6-
6)
6)
7)
7)
Max. Arbeitsdruck Dampfbetrieb (mit
MPa (bar) 3,2 (32) 3,2 (32) 3,2 (32) 3,2 (32)
Dampfdüse)
Teile-Nr. Dampfdüse -- 2.885-039.0 2.885-039.0 2.885-119.0 2.885-119.0
Max. Arbeitstemperatur Heißwasser °C 98 98 98 98
Arbeitstemperatur Dampfbetrieb °C 155 155 155 155
Reinigungsmittelansaugung l/h (l/min) 0-45 (0-0,75) 0-45 (0-0,75) 0-50 (0-0,8) 0-50 (0-0,8)
Brennerleistung kW 53 53 63 63
Maximaler Heizölverbrauch kg/h 4,6 4,6 5,3 5,3
Rückstoßkraft der Handspritzpistole
N 17,9 17,9 24,3 24,3
(max.)
Düsengröße -- 048 048 047 047
Ermittelte Werte gemäß EN 60335-2-79
Geräuschemission
Schalldruckpegel L
pA
dB(A) 70 70 71 71
Unsicherheit K
pA
dB(A) 2222
Schallleistungspegel L
WA
+ Unsicher-
dB(A) 88 88 88 88
heit K
WA
Hand-Arm Vibrationswert
2
Handspritzpistole m/s
1,1 1,1 1,0 1,0
2
Strahlrohr m/s
3,4 3,4 3,4 3,4
2
Unsicherheit K m/s
1,0 1,0 1,0 1,0
Betriebsstoffe
Brennstoff -- Heizöl EL
Heizöl EL
Heizöl EL
Heizöl EL
oder Diesel
oder Diesel
oder Diesel
oder Diesel
Ölmenge l 0,75 0,75 0,75 0,75
Ölsorte -- 0W40 0W40 SAE 90 SAE 90
Maße und Gewichte
Länge x Breite x Höhe mm 1330 x 750 x
1330 x 750 x
1330 x 750 x
1330 x 750 x
1060
1060
1060
1060
Typisches Betriebsgewicht, M/S kg 146 146 155 155
Typisches Betriebsgewicht, MX/SX kg 154 154 163 163
Brennstofftank l 25 25 25 25
Reinigungsmitteltank l 10+20 10+20 10+20 10+20
– 15
21DE
HDS 10/20
HDS 10/20
HDS 12/18
HDS 12/18
Classic *KAP
*AU/Classic
Classic *KAP
*AU/Classic
*EU
*EU
Netzanschluss
Spannung V 220 400-420 220 400-420
Stromart Hz 3~ 60 3~ 50 3~ 60 3~ 50
Anschlussleistung kW 7,8 7,8 8,4 8,4
Absicherung (träge) A 32 16 32 16
Schutzart -- IPX5 IPX5 IPX5 IPX5
Schutzklasse -- I I I I
Maximal zulässige Netzimpedanz Ohm -- (0,169+
(0,163+
(0,163+
j0,105)
j0,102)
j0,102)
Wasseranschluss
Zulauftemperatur (max.) °C 30 30 30 30
Zulaufmenge (min.) l/h (l/min) 1500 (25) 1300 (21,7) 1500 (25) 1500 (25)
Saughöhe aus offenem Behälter (20 °C) m 0,5 0,5 0,5 0,5
Zulaufdruck (max.) MPa (bar) 0,6 (6) 0,6 (6) 0,6 (6) 0,6 (6)
Leistungsdaten
Fördermenge Wasser l/h (l/min) 500-1000
500-1000
600-1200 (10-
600-1200 (10-
(8,3-16,7)
(8,3-16,7)
20)
20)
Arbeitsdruck Wasser (mit Standarddü-
MPa (bar) 5-20 (50-200) 3-20 (30-200) 3-18 (30-180) 3-18 (30-180)
se)
Max. Betriebsüberdruck (Sicherheits-
MPa (bar) 24 (240) 24 (240) 21,5 (215) 21,5 (215)
ventil)
Fördermenge Dampfbetrieb l/h (l/min) 460-505 (7,6-
460-505 (7,6-
550-610 (9,1-
550-610 (9,1-
8,4)
8,4)
10,1)
10,1)
Max. Arbeitsdruck Dampfbetrieb (mit
MPa (bar) 3,2 (32) 3,2 (32) 3,2 (32) 3,2 (32)
Dampfdüse)
Teile-Nr. Dampfdüse -- 2.885-041.0 2.885-041.0 2.885-120.0 2.885-120.0
Max. Arbeitstemperatur Heißwasser °C 98 98 98 98
Arbeitstemperatur Dampfbetrieb °C 155 155 155 155
Reinigungsmittelansaugung l/h (l/min) 0-60 (0-1) 0-60 (0-1) 0-72 (0-1,2) 0-72 (0-1,2)
Brennerleistung kW 83 75 91 91
Maximaler Heizölverbrauch kg/h 6,7 6,4 7,7 7,7
Rückstoßkraft der Handspritzpistole
N 33,0 33,0 37,6 37,6
(max.)
Düsengröße -- 054 054 068 068
Ermittelte Werte gemäß EN 60335-2-79
Geräuschemission
Schalldruckpegel L
pA
dB(A) 73 73 73 73
Unsicherheit K
pA
dB(A) 2222
Schallleistungspegel L
WA
+ Unsicher-
dB(A) 90 90 90 90
heit K
WA
Hand-Arm Vibrationswert
2
Handspritzpistole m/s
1,2 1,2 1,5 1,5
2
Strahlrohr m/s
5,2 5,2 4,8 4,8
2
Unsicherheit K m/s
1,0 1,0 1,0 1,0
Betriebsstoffe
Brennstoff -- Heizöl EL
Heizöl EL
Heizöl EL
Heizöl EL
oder Diesel
oder Diesel
oder Diesel
oder Diesel
Ölmenge l 1,0 1,0 1,0 1,0
Ölsorte -- SAE 90 SAE 90 SAE 90 SAE 90
Maße und Gewichte
Länge x Breite x Höhe mm 1330 x 750 x
1330 x 750 x
1330 x 750 x
1330 x 750 x
1060
1060
1060
1060
Typisches Betriebsgewicht, M/S kg 175 175 178 178
Typisches Betriebsgewicht, MX/SX kg 182 182 185 185
Brennstofftank l 25 25 25 25
Reinigungsmitteltank l 10+20 10+20 10+20 10+20
22 DE
– 16
Wiederkehrende Prüfungen
Hinweis: Die Prüffristempfehlungen entsprechend der jeweiligen nationalen Anforderun-
gen des Betreiberlandes sind zu beachten.
Prüfung durchge-
Äußere Prüfung Innere Prüfung Festigkeitsprü-
führt durch:
fung
Name Unterschrift der be-
Unterschrift der be-
Unterschrift der be-
fähigten Person/
fähigten Person/
fähigten Person/
Datum
Datum
Datum
Name Unterschrift der be-
Unterschrift der be-
Unterschrift der be-
fähigten Person/
fähigten Person/
fähigten Person/
Datum
Datum
Datum
Name Unterschrift der be-
Unterschrift der be-
Unterschrift der be-
fähigten Person/
fähigten Person/
fähigten Person/
Datum
Datum
Datum
Name Unterschrift der be-
Unterschrift der be-
Unterschrift der be-
fähigten Person/
fähigten Person/
fähigten Person/
Datum
Datum
Datum
Name Unterschrift der be-
Unterschrift der be-
Unterschrift der be-
fähigten Person/
fähigten Person/
fähigten Person/
Datum
Datum
Datum
Name Unterschrift der be-
Unterschrift der be-
Unterschrift der be-
fähigten Person/
fähigten Person/
fähigten Person/
Datum
Datum
Datum
– 17
23DE
Please read and comply with
Environmental protection
these original instructions prior
to the initial operation of your appliance and
The packaging material can be
store them for later use or subsequent own-
recycled. Please do not throw
ers.
the packaging material into
– Before first start-up it is definitely nec-
household waste; please send it
essary to read the operating instruc-
for recycling.
tions and safety indications Nr. 5.951-
Old appliances contain valuable
949.0!
materials that can be recycled;
– In case of transport damage inform ven-
these should be sent for recy-
dor immediately
cling. Batteries, oil, and similar
– Check the contents of the pack before
substances must not enter the
unpacking. For scope of delivery see il-
environment. Please dispose of
lustration 1.
your old appliances using ap-
Contents
propriate collection systems.
Environmental protection . . EN . . .1
Please do not release engine oil, fuel oil,
diesel and petrol into the environment Pro-
Symbols in the operating in-
structions . . . . . . . . . . . . . . EN . . .1
tect the ground and dispose of used oil in
Overview . . . . . . . . . . . . . . EN . . .2
an environmentally-clean manner.
Symbols on the machine . . EN . . .2
Notes about the ingredients (REACH)
Proper use . . . . . . . . . . . . . EN . . .3
You will find current information about the
Safety instructions . . . . . . . EN . . .3
ingredients at:
Safety Devices . . . . . . . . . . EN . . .3
www.kaercher.com/REACH
Start up. . . . . . . . . . . . . . . . EN . . .4
Symbols in the operating
Operation . . . . . . . . . . . . . . EN . . .6
instructions
Storage. . . . . . . . . . . . . . . . EN . . .9
Transport . . . . . . . . . . . . . . EN . . .9
Danger
Maintenance and care . . . . EN . . .9
Immediate danger that can cause severe
Troubleshooting . . . . . . . . . EN . .10
injury or even death.
Warranty. . . . . . . . . . . . . . . EN . .13
몇 Warning
Accessories and Spare Parts EN . .13
Possible hazardous situation that could
EC Declaration of Conformity EN . .14
lead to severe injury or even death.
Technical specifications . . . EN . .15
Caution
Recurring tests . . . . . . . . . . EN . .17
Possible hazardous situation that could
lead to mild injury to persons or damage to
property.
24 EN
