AEG OF 2050 E: 22 23 ENGLISH ENGLISH

TECHNICAL DATA

EC-DECLARATION OF CONFORMITY

SYMBOLS

Rated input ..............................................................................

.......................2050 W

We declare under our sole responsibility that this product is

-1

No-load speed .........................................................................

..........10000-20000 min

in conformity with the following standards or standardized

Please read the instructions carefully before

Cage stroke .............................................................................

...........................66 mm

documents.

starting the machine.

Collet diameter max.................................................................

...................6, 8, 12 mm

EN 60745-1:2009 + A11:2010

Collet diameter max.(UK) ........................................................

........1/4", 3/8", 1/2"

EN 60745-2-17:2010

Router diameter .......................................................................

...........................50 mm

EN 55014-1:2006 + A1:2009 + A2:2011

Weight according EPTA-Procedure 01/2003 ...........................

..........................6,2 kg

EN 55014-2:1997 + A1:2001 + A2:2008

Always disconnect the plug from the socket

EN 61000-3-2:2006 + A1:2009 + A2:2009

before carrying out any work on the machine.

EN 61000-3-3:2008

Noise/vibration information

in accordance with the regulations

Measured values determined according to EN 60 745.

2011/65/EU (RoHs)

Typically, the A-weighted noise levels of the tool are:

2006/42/EC

Sound power level (K = 3 dB(A)) ............................................

...........................96 dB (A)

2004/108/EC

Sound pressure level (K = 3 dB(A)) .......................................

.........................107 dB (A)

Accessory - Not included in standard equipment,

Wear ear protectors!

available as an accessory.

Total vibration values (vector sum in the three axes)

determined according to EN 60745.

2

Vibration emission value a

h

...................................................

.............................7 m/s

Winnenden, 2012-09-06

2

Uncertainty K ........................................................................

..........................1,5 m/s

Do not dispose of electric tools together with

household waste material! In observance of

European Directive 2002/96/EC on waste

WARNING

electrical and electronic equipment and its

Rainer Kumpf

implementation in accordance with national law,

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given

Director Product Development

electric tools that have reached the end of their

in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.

Authorized to compile the technical le

life must be collected separately and returned to

The declared vibration emission level represents the main applications of the tool. However if the tool is used for different

an environmentally compatible recycling facility.

applications, with different accessories or poorly maintained, the vibration emission may differ. This may signicantly increase

MAINS CONNECTION

the exposure level over the total working period.

Connect only to single-phase a.c. current and only to the

Class II construction, tool in which protection

An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or

system voltage indicated on the rating plate. It is also

against electric shock does not rely on basic

when it is running but not actually doing the job. This may signicantly reduce the exposure level over the total working period.

possible to connect to sockets without an earthing contact

insulation only, but in which additional safety

as the design conforms to safety class II.

Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the

precautions, such as double insulation or

accessories, keep the hands warm, organisation of work patterns.

reinforced insulation, are provided.

MAINTENANCE

The ventilation slots of the machine must be kept clear at all

WARNING! Read all safety warnings and all

Only use router cutter with correct shank diameter.

times.

instructions, including those given in the accompanying

The workpieces should be clamped down before cutting.

Use only AEG accessories and AEG spare parts. Should

brochure. Failure to follow the warnings and instructions

may result in electric shock, re and/or serious injury.

Put the router back to original position after usage (loosen

components need to be replaced which have not been

described, please contact one of our AEG service agents

Save all warnings and instructions for future reference.

clamping lever to secure cage).

(see our list of guarantee/service addresses).

Only move the workpiece in counter rotation to cutter (only

SAFETY INSTRUCTIONS

work oppositely oriented)! For security, use devices such as

If needed, an exploded view of the tool can be ordered.

safety- and pressure device, guide slide, rip fence, etc.

Please state the Article No. as well as the machine type

Wear ear protectors. Exposure to noise can cause hearing

printed on the label and order the d rawing at your local

loss.

The dust that arises when working with this tool can be

service agents or directly at: AEG Electric Tools GmbH,

detrimental to health (e.g. when working oak or bECh wood,

Hold power tool by insulated gripping surfaces,

Max-Eyth-Straße 10, D-71364 Winnenden, Germany.

stones, paint, which could contain lead or other harmful

because the cutter may contact its own cord. Cutting a

chemicals) and therefore not reach the body. Use a dust

“live” wire may make exposed metal parts of the power tool

absorption system and wear a suitable dust protection

“live” and shock the operator.

mask. Remove deposited dust thoroughly, e.g. with a

Use clamps or another practical way to secure and

vacuum cleaner.

support the workpiece to a stable platform. Holding the

Under the effect of extreme electromagnetic interferences

work by your hand or against the body leaves it unstable

from the outside, temporary variations in the speed of

and may lead to loss of control

rotation could arise in particular cases.

Appliances used at many different locations including open

air should be connected via a residual current device of

SPECIFIED CONDITIONS OF USE

30 mA or less.

The router can be used for rabbeting, rounding off,

Always wear goggles when using the machine. It is

chamfering, routing of edges, as well as pitting in wood and

recommended to wear gloves, sturdy non slipping shoes

plastic.

and apron.

Do not use this product in any other way as stated for

Always disconnect the plug from the socket before carrying

normal use.

out any work on the machine.

Only plug-in when machine is switched off.

Keep mains lead clear from working range of the machine.

Always lead the cable away behind you.

Never reach into the danger area of the plane when it is

running.

Always use the protective shields on the machine.

Only use tools whose permitted speed is at least as high as

the highest no-load speed of the machine.

Sawdust and splinters must not be removed while the

machine is running.

Only use professionally grinded router cutters.
