Hotpoint-Ariston AQ9D 492 X: Care and maintenance

EN

10

Care and maintenance

1

2

Cutting off the water and electricity

supplies

•  Turn off the water tap after every wash cycle. This will

limit wear on the hydraulic system in the machine and

help to prevent leaks.

•  Unplug the appliance when cleaning it and during all

maintenance work.

Cleaning the machine

The outer parts and rubber components of the appliance

can be cleaned using a soft cloth soaked in lukewarm

soapy water. Do not use solvents or abrasives.

Cleaning the detergent dispenser

drawer

To remove the drawer, press

lever (1) and pull the drawer

outwards (2)

(see figure).

Wash it under running water;

this procedure should be

repeated frequently.

Caring for your appliance drum

•  Always leave the door ajar to prevent unpleasant odours

from forming.

Cleaning the pump

The washing machine is fitted with a self-cleaning pump

which does not require any maintenance. Sometimes,

small items (such as coins or buttons) may fall into the

protective pre-chamber at the base of the pump.

!

 Make sure the wash cycle has finished and unplug the

appliance.

To access the pre-chamber:

1. take off the cover panel on the front of the machine by

first pressing it in the centre and then pushing downwards

on both sides until you can remove it

(see figures);

2. position a container so that

it will collect the water which

flows out (approximately 1.5 l)

(

see

figure

)

;

3. unscrew the lid by rotating

it in an anti-clockwise

direction (

see

figure

)

;

4. clean the inside thoroughly;

5. screw the lid back on;

6. reposition the panel, making sure the hooks are securely

in place before you push it onto the appliance.

Checking the water inlet hose

Check the inlet hose at least once a year. If there are any

cracks, it should be replaced immediately: during the wash

cycles, water pressure is very strong and a cracked hose

could easily split open.
