EXFO Photonic Solutions Div. FVA-600: инструкция

User Guide

Guide d’utilisation

用户指南

Guía del usuario

Guia do utilizador

Руководство пользователя

FVA-600

Variable Attenuator

ii

Copyright © 2010 EXFO Inc. All rights reserved. No part of this publication may be

reproduced, stored in a retrieval system or transmitted in any form, be it

electronically, mechanically, or by any other means such as photocopying,

recording or otherwise, without the prior written permission of EXFO Inc. (EXFO).

Information provided by EXFO is believed to be accurate and reliable. However, no

responsibility is assumed by EXFO for its use nor for any infringements of patents or

other rights of third parties that may result from its use. No license is granted by

implication or otherwise under any patent rights of EXFO.

EXFO’s Commerce And Government Entities (CAGE) code under the North Atlantic

Treaty Organization (NATO) is 0L8C3.

The information contained in this publication is subject to change without notice.

Trademarks

EXFO’s trademarks have been identified as such. However, the presence or

absence of such identification does not affect the legal status of any trademark.

Units of Measurement

Units of measurement in this publication conform to SI standards and practices.

Patents

EXFO’s Universal Interface is protected by US patent 6,612,750.

Version number: 1.0.0

Contents

Certification Information .................................................................................. v

1 Introducing the FVA-600 Variable Attenuator ......................... 1

Main Features ................................................................................................... 1

Power Sources .................................................................................................. 2

Typical Applications .......................................................................................... 2

Conventions ...................................................................................................... 3

2 Safety Information ................................................................... 4

General Information ......................................................................................... 4

Electrical Safety Information ............................................................................. 4

3 Getting Started with Your FVA-600 Variable Attenuator ........ 5

Turning the Unit On and Off ............................................................................. 5

Display Description ........................................................................................... 5

Keypad Description ........................................................................................... 6

Secondary Functions Keypad ............................................................................ 6

Activating Automatic Shutdown (Auto-Off) ...................................................... 6

Activating the Backlight .................................................................................... 7

Installing the EXFO Universal Interface (EUI) ..................................................... 7

Cleaning and Connecting Optical Fibers ........................................................... 8

4 Operating the FVA-600 Variable Attenuator ............................ 9

Selecting Wavelengths ...................................................................................... 9

Setting the Attenuation .................................................................................... 9

Selecting an Operation Mode ........................................................................... 9

Setting Attenuation Step Size ......................................................................... 12

Setting Power Step Size .................................................................................. 12

Editing Wavelength ........................................................................................ 12

Zeroing the unit .............................................................................................. 13

Using the USB Port ......................................................................................... 13

5 Maintenance ............................................................................ 14

Cleaning EUI Connectors ................................................................................ 15

Recharging the Battery Pack ........................................................................... 16

Replacing the Battery ...................................................................................... 17

Checking the LCD Display ............................................................................... 17

Reverting to the Default Settings ....................................................................17

Recycling and Disposal (Applies to European Union Only) .............................. 18

6 Troubleshooting ...................................................................... 19

Solutions to Common Problems ..................................................................... 19

Contacting the Technical Support Group ........................................................ 20

Transportation ................................................................................................ 21

7 Warranty .................................................................................. 22

General Information ....................................................................................... 22

Liability ........................................................................................................... 22

Exclusions ....................................................................................................... 22

Certification .................................................................................................... 23

Service and Repairs ......................................................................................... 24

EXFO Service Centers Worldwide .................................................................... 25

FVA-600 iii

Contents iv

A Technical Specifications .......................................................... 26

B Typical Test Configurations .................................................... 27

BERT and Protocol Analysis ............................................................................. 27

Overload and Sensitivity ................................................................................. 27

OSNR Loading ................................................................................................. 28

ROADM ........................................................................................................... 28

Certification Information

F.C.C. Information

Electronic test equipment is exempt from Part 15 compliance (FCC) in the United

States. However, compliance verification tests are systematically performed on

most EXFO equipment.

 Information

Electronic test equipment is subject to the EMC Directive in the European Union.

The EN61326 standard prescribes both emission and immunity requirements for

laboratory, measurement, and control equipment. This unit has undergone

extensive testing according to the European Union Directive and Standards.

FVA-600 v

Certification Information vi

DECLARATION OF CONFORMIT

Application of Council Directives: 2006/95/EC - The Low Voltage Directive

2004/108/EC - The EMC Directive

2006/66/EC - The Battery Directive

93/68/EEC - CE Marking

and their amendments

Manufacturer’s Name: EXFO Inc.

Manufacturer’s Address: 400 Godin Avenue

Quebec, Quebec

Canada, G1M 2K2

Equipment Type/Environment: Test & Measurement / Industrial

Trade Name/Model No.: Variable Attenuator / FVA-600

Standard(s) to which Conformity is Declared:

EN 61010-1:2001 Edition 2.0 Safety Requirements for Electrical Equipment for Measurement,

Control, and Laboratory Use – Part 1: General Requirements.

EN 61326-1:2006 Electrical Equipment for Measurement, Control and Laboratory

Use - EMC Requirements

EN 55022: 2006 + A1: 2007 Information technology equipment — Radio disturbance

characteristics — Limits and methods of measurement

I, the undersigned, hereby declare that the equipment specified above conforms to the above Directives and Standards.

Manufacturer

Signature:

Full Name: Stephen Bull, E. Eng

Position: Vice-President Research and

Development

Address: 400 Godin Avenue, Quebec (Quebec),

Canada, G1M 2K2

Date: February 18, 2010

1 Introducing the FVA-600

Variable Attenuator

The FVA-600 is a variable optical attenuator used for bit error rate and system

testing, optical margin analysis, calibration verification and component testing. It is

configured for singlemode fibers. Calibrated wavelengths are 1310 nm and 1550 nm.

Main Features

The FVA-600 includes the following:

³ Large attenuation range

³ High accuracy

³ Fast settling time

³ Auto-off feature to lenghten battery life

³ Backlight to help you work regardless of external conditions

³ Unit status and operation mode stored upon shutdown

³ Remote operation using a USB link

LCD display

Shoulder

strap eyelet

Keypad

DC connector

USB connector

Safety label

and serial number

(under the stand)

Quick reference label

Battery compartment

FVA-600 1

Introducing the FVA-600 Variable Attenuator 2

In

Out

Power Sources

The unit operates with the following power sources:

³ AC adapter (connected to standard power outlet - indoor use only)

Compatible car outlet adapter available upon request.

³ Li-Ion rechargeable battery (automatically takes over if you unplug the

AC adapter)

IMPORTANT

If the battery level becomes too low, the unit turns itself off.

Typical Applications

You can use the FVA-600 Variable Attenuator for several applications, such as:

³ High power suiting any application, including CATV and Telco

³ BER testing ready with high optical resolution

³ FTTx ready with standard 1310,1490,1550 and 1625 nm wavelengths

³ Remote control ready via USB for integration in automated test setups

Conventions

Before using the product described in this manual, you should understand the

following conventions:

WARNING

Indicates a potentially hazardous situation which, if not avoided,

could result in death or serious injury. Do not proceed unless you

understand and meet the required conditions.

CAUTION

Indicates a potentially hazardous situation which, if not avoided,

may result in minor or moderate injury. Do not proceed unless you

understand and meet the required conditions.

CAUTION

Indicates a potentially hazardous situation which, if not avoided,

may result in component damage. Do not proceed unless you

understand and meet the required conditions.

IMPORTANT

Refers to information about this product you should not overlook.

FVA-600 3
