HEIDENHAIN PWM 20: 1 About these instructions

Operating Instructions

en

PWM 20

18

1 About these instructions

These instructions provide all the information and safety

precautions needed for the proper mounting and installation

of the product, as well as for operation of the unit as far as it

is used without the ATS software.

1.1 Information on the model Product designation ID number

PWM 20

731626-01

The above-stated ID number is the number on

the ID label. The ID number on the packaging

label may differ from the number on the ID label

because the device can be delivered in different

packaging units.

ID label

The ID label is provided on the back of the product.

Example:

1 2 3

1

Product designation

2

ID number

3

Index

Validity of the documentation

A document number is provided at the bottom

left on the last page of the documentation. The

documentation is valid if the document number

matches the document number indicated at

www.heidenhain.de

.

You therefore need to compare the product

designation, the ID number and the index given

on the ID label with the corresponding details

provided at

www.heidenhain.de

1.2 Notes on reading the documentation

The table below lists the components of the documentation

in the order of priority for reading.

WARNING

Failure to comply with the documentation may result in

fatal accidents, personal injury or damage to equipment.

Please read the documentation carefully from

beginning to end and keep it for future reference.

Documentation Description

Addendum

An addendum supplements or su-

persedes the corresponding con-

tents of the Operating Instructions

and, if applicable, of the Installation

Instructions. If this document is in-

cluded in delivery, read it first befo-

re you proceed. All other contents

of the documentation retain their

validity.

Operating Instruc-

tions

The Operating Instructions con-

tain all the information and safety

precautions needed for the proper

mounting, installation and operation

of the product according to its in-

tended use. It is included in delivery

and has the second highest priority

for reading.

Operating instruc-

tions for ATS soft-

ware

The documentation on operating

the product with the ATS software

can be downloaded from the down-

load area at

www.heidenhain.de

.

Documentation of

connected measu-

ring devices and

other peripherals

These documents are not included

in delivery. They are included with

the respective measuring devices

and peripherals

1.3 Storage and distribution of the documentation

These instructions must be kept in the immediate vicinity of

the workplace and must be available to all personnel at all

times. The operating company must inform the personnel

where these instructions are kept. If the instructions have

become illegible, the operating company must obtain a new

copy from the manufacturer.

If the product is handed over or sold to a third party, the

following documents must be given to the new owner:

Addendum, if supplied

Operating Instructions

1.4 Target group for the instructions

The Operating Instructions must be read and observed by

every person who performs any of the following tasks:

Mounting

Installation

Operation

Maintenance

Removal, environmental protection and disposal
