HEIDENHAIN ND 1200 Quick Start: инструкция

Quick Reference Guide

Kurzanleitung

Guide de Démarrage rapide

Guida rapida

Guía rápida de referencia

Snabbreferensguide

Beknopte handleiding

Stručná referenční příručka

Guia de referência rápida

Krótka instrukcja

Краткое руководство

Hızlı Başvuru Kılavuzu

クイックリファレンスガイド

快速參考手冊

ND 1200

QUADRA-CHEK

Software Version

2.19.x

9/2013

ND 1200 QUADRA-CHEK

Front panel

Rear side

Side view

ND 1200 QUADRA-CHEK English

Setup

Very important

Please note

For detailed description, see www.heidenhain.de

For your information

Before Power up

Controls and Displays

Mounting

The ND 1200 is secured to the swivel

A LCD screen

slots of the mounting stand or arm

Electrical connection

B

Soft keys: Change to support

mount by a shoulder screw, a cap

Line voltage: 100 V~ to 240 V~

functions

screw mount is shown and associated

(–15 % to +10 %)

C

Measure keys: Initiate

washers.

Line frequency: 47 Hz to 63 Hz

measurements

Line fuse: T1600 mA, 250 V

D

Axis keys: Zero or preset datums

5 x 20 mm

E

Mode keys: Select unit of

measure, datum, coordinate

Power connector wiring

system or help

F

Command keys: Control

measurement

G

Menu key: Displays user menus

H

Arrow cursor keys: Menu

navigation

I

Fast track keys: Programmable

for frequently used functions

K

Numeric keypad: Enter numeric

data

L

Send key: Transmit

L: Line voltage (brown)

measurement data to PC, USB

N: Neutral (blue)

printer or USB drive

Earth ground (yellow/green)

M

LCD on/off key: Turn LCD on or

off, clear data, datums and skew

alignments

Danger of electrical shock!

Connections rear side

• Do not open the enclosure

• Never use 3-wire to 2-wire adapters

1 Power switch

or allow the ground connection to

2 Power connection with fuse

the ND 1200 to be interrupted or

3

Ground (protective ground)

disconnected.

4

Encoder inputs, X, Y, Z, Q axis

for linear and rotary encoders.

Interface specified at the time of

Caution

purchase.

Changes to the power cable may be

5

RS-232-C interface for PC

made only by an electrical technician.

connection. RS-232 cable must

not include crossovers.

6

Optical cable connector for

Caution

comparator screen sensor

Do not make connect encoders or other

equipment to the ND 1200 when the

7

Optical cable connector for

power is on.

Comparator reference light

source

8 Unused

Safety Considerations

General accepted safety precautions

Connections side view

must be followed when operating the

9

Audio out, for 3,5 mm

ND 1200. Failure to observe these

headphone /speaker jack,

precautions could result in damage to

monaural, 8 Ohm

the equipment, or injury to personnel.

10

USB type A interface for printer

It is understood that safety rules within

or data storage

individual companies vary. If a conflict

11

Remote accessory interface

exists between the material contained

RJ-45 for optional foot switch or

in this guide or the and the rules of a

keypad accessory. Two optional

company using this system, the more

remote accessories can be used

stringent rules should take precedence.

simultaneously using an RJ-45

splitter.







 

 




