Festool ASA 6000: 8 Dust extraction

12

ASA

GB

7.3

Connecting the dust extractor

ASA CT/SRM



Insert the reducing sleeve on the extractor hose

into the connection on the dust extractor.



We recommend using rotating adapter D50

DAS-AS to connect the extractor hose to the

dust extractor.

ASA TURBO



Connect the suction hose on the ASA to the sta-

tionary extraction system.

7.4

Connecting the mains cable



Insert the black plug on the ASA into a socket

connected to the mains power supply (230 V~/

16A).

7.5

Operation

On completion of the following steps, the ASA is

ready for operation:

1. Connect to EAA (see EAA operating manual)

– Mains and control cable to EAA

– Compressed air line to service unit

2. Connect the ASA

– Plug from on-site power supply

– Compressed air line to on-site com-

pressed-air system

– Control cable to dust extractor

8 Dust extraction

If national safety regulations stipulate that dust ex-

tractors must have a suction power monitoring

function (volumetric flow monitoring), only one ex-

tractor opening

 on the EAA can be opened.

The slide prevents the use of both openings. If the

slide is removed, e.g. when extracting non-hazard-

ous dust, the system can operate and extract from

two machines at the same time (see EAA operating

manual).

9 Service  and  maintenance

Damaged safety devices and components must be

repaired or replaced in a recognised specialist

workshop, unless otherwise indicated in the oper-

ating manual.

10 Disposal

Do not throw the tool in your household waste!!

Dispose of machines, accessories and packaging at

an environmentally responsible recycling centre.

Observe the valid national regulations.

EU only:

European Directive 2002/96/EC stipulates

that used electric tools must be collected separate-

ly and disposed of at an environmentally responsi-

ble recycling centre.

11 Accessories

Use only original Festool accessories and Festool

consumable material intended for this machine be-

cause these components are designed specifically

for the machine. Using accessories and consum-

able material from other suppliers will most likely

affect the quality of your working results and limit

any warranty claims. Machine wear or your own

personal workload may increase depending on the

application. Protect yourself and your machine, and

preserve your warranty claims by always using

original Festool accessories and Festool consum-

able material!

The order numbers of the accessories and tools can

be found in the Festool catalogue or on the Internet

under "www.festool.com".

12 Warranty

We offer a warranty for material and production de-

fects for all our tools in accordance with the locally

applicable legal provisions, but for a minimum of 12

months. Within the EU member states, the warran-

ty period is 24 months (verification through invoice

or delivery note). Damage caused by the operator,

natural wear, overloading, incorrect handling or

through the use of the equipment not specified in

the operating manual, or damage which was known

WARNING

Dust hazard



Dust can be hazardous to health. Always work

with a dust extractor.



Always read applicable national regulations be-

fore extracting hazardous dust.

WARNING

Risk of accidents



Disconnect the EAA/ASA from the power and

compressed air supply before performing any

maintenance and repair work.



All maintenance and repair work on the electri-

cal or electronic system must always be carried

out by a qualified electrician.
