Acme NI-51: инструкция

Model: NI-51

2.0

multimedia

speakers

www.acme.eu

4 GB User’s manual 40 Warranty card

7 LT Vartotojo gidas 41 Garantinis lapas

10 LV Lietošanas instrukcija 42 Garantijas lapa

13 EE Kasutusjuhend 43 Garantiileht

16 PL Instrukcja obsługi 44 Karta gwarancyjna

19 DE Bedienungsanleitung 45 Garantieblatt

22 FI Kayttoohje 46 Takuulomake

25 SE Bruksanvisning 47 Garantisedel

28 RO Manual de utilizare 48 Fişa de garanţie

31 BG Ръководство за употреба 49 Гаранционен лист

34 RU Инструкция пользователя 50 Гарантийный талон

37 UA Інструкція 51 Гарантійний лист

3

GB

Introduction

Thank you for purchasing our Multimedia Speaker System. You can use your speakers to listen to

audio output from most computers, MP3 players, TVs, CD players and DVD players. Please read this

manual carefully FIRST in order to get the most out of your equipment.

Contents

• 2.0 stereo speakers

• User’s manual

• Warranty card

Specifications

• Colour: black

• Power: 2 x 0.5W (RMS)

• Frequency response: 150Hz ~ 20 kHz

Power

• Connector: 3.5mm stereo cable

• Power supply: AC 220 V / 50 Hz

Headphone jack

• Signal Noise Ratio: >= 60 dB

Volume

• Sensitivity: 360mV

• Driver unit: 1.7” x 3.5”

• Dimensions: 63(W) x 200(H) x 60(D) mm

4

GB

Installation

1. Be sure that all components are switched o before connecting.

2. Insert the signal cable jack into the sound output port of your PC, MP3 player, or other

equipment.

3. Plug the AC cable into a power socket.

4. Turn the “Volume” setting to minimum and then switch on the speaker system by pressing the

“POWER” button, after which the LED lights will activate.

5. Adjust the volume knob to the desired volume level.

Important safety instructions

1. For the best results, place your speakers on a solid, at surface when in use.

2. Do not touch the metallic parts of your connector cables.

3. When unplugging your speakers from an AC power socket, do not disconnect them by tugging

on the AC power cable; instead, pull carefully on the rubberised section of the plug.

4. In order to avoid potential electric shocks or other such accidents, do not dismantle or take apart

your speakers or their components.

5. Keep the volume turned down to the lowest setting before powering on your speakers. Once

they have power, proceed to raise the volume to a reasonable level.

6. Do not expose your speakers to excessive amounts of heat or cold. Keep them in a well

ventilated area to prevent any possible overheating.

7. Turn o the power to your speakers when they are not in use.

8. Do not spill liquids or uids onto your speakers. Make sure they stay dry at all times.

9. When connecting an audio device to your speakers, make sure that the volume setting on the

audio device is not set too high in order to avoid excessive signal input.

5

GB

Waste Electrical and Electronic Equipment (WEEE) Symbol

The use of the WEEE symbol indicates that this product may not be treated as

household waste. By ensuring this product is disposed of correctly, you will help

protect the environment. For more detailed information about the recycling of this

product, please contact your local authority, your household waste disposal service

provider or the shop where you purchased the product.

6
