Acme CA11: инструкция

Model: CA-11

web

camera

www.acme.eu

4 GB User’s manual 28 Warranty card

6 LT Vartotojo gidas 29 Garantinis lapas

8 LV Lietošanas instrukcija 30 Garantijas lapa

10 EE Kasutusjuhend 31 Garantiileht

12 PL Instrukcja obsługi 32 Karta gwarancyjna

14 DE Bedienungsanleitung 33 Garantieblatt

16 FI Kayttoohje 34 Takuulomake

18 SE Bruksanvisning 35 Garantisedel

20 RO Manual de utilizare 36 Fişa de garanţie

22 BG Ръководство за употреба 37 Гаранционен лист

24 RU Инструкция пользователя 38 Гарантийный талон

26 UA Інструкція 39 Гарантійний лист

3

GB

Introduction

Thank you for using the new generation digital web cam. This web cam

works with USB port to be connected with PC. Its easily carrying, high

quality video and still images make you life more colorful and make your

long distance communications fresh and vivid.

Contents

• Web camera

• Drivers CD

• User’s manual

• Warranty card

Specifications

• Interface: USB

• Hardware resolution: 1.3 Mega pixels

• Max resolution: 1280 x 960 pixels (simulation)

• Frame rate: 30 fps at CIF/VGA, 15 fps at SVGA

• Image storage format: JPEG / BMP

• Microphone: built-in

• 360 degree rotation capability

• Automatic white balance

• Automatic colours compensation

• Color: 24-bit, True Color

• Digital zoom and face tracking function

• Dimensions: 65(W) x 35(H) x 25(D) mm

System requirements

TM

• Windows® 2000 / ME / XP / VISTA / 7

• Mac OS 9.2

• Free USB slot

• CD-ROM drive

4

GB

Drivers Installation

1. Connect the Web Cam USB plug to the USB port of computer.

2. Connect the Ø3.5 mm signal output cable to the audio frequency

input jack of the PC.

3. Your computer will search the Web Cam automatically.

4. Insert the Web Cam installation CD into the CD-ROM of your

computer.

5. Wait a few seconds and software will guide you through the software

setup process automatically. Then follow on-screen instructions.

6. Operating system will ask you to restart your computer. Please follow

the instruction to restart your computer.

7. After restarting, go to “Start” menu and nd “USB PC Camera” in the

program list.

8. When the “USB PC Camera” begin to work, please click “Options” and

select “Preview”. Now, you can begin to use Web Cam.

Notices:

• Don’t use ngers or any other sharp or coarse items to touch the

camera. Soft cotton cloth is highly recommended to clean the optics

parts.

• Don’t use this product when ambience is too hot or cold or dusty.

• Please avoid this product dropping heavily. Heavily dropping will

cause it not to work well.

Waste Electrical and Electronic Equipment (WEEE) Symbol

The use of the WEEE symbol indicates that this product may

not be treated as household waste. By ensuring this product is

disposed of correctly, you will help protect the environment. For

more detailed information about the recycling of this product,

please contact your local authority, your household waste disposal

service provider or the shop where you purchased the product.

5
