Introduction

Description

Acme Extreme Wheel is a professional steering wheel and support force

vibration.

Features

• 24cm wheel size

• 270 degrees rotation for steering wheel

• Compatible with PC, PS2 and PS3

• Support two modes (Digital and Analog) on PS2 and press the button “mode”

for mode switch

• The force vibration is available on all platforms

• Button setting is programmable on all platforms

• Advance 6-sensivity settings

Electromechanical components

Buttons/Axis

• 8 analog buttons (L1, L2, R1, R2, , X, O, □)

• 3 digital buttons (Select , Start and Mode)

• 3 analog Axis (X, Gas Pedal, Brake Pedal)

All buttons are rubber pad and lifecycle of potentiometers on analog axis is

more than 500,000, see button and axis assignment as following.

D-Pad

Description/ Role

One D-Pad (8 directions) and navigation in menus

Electronics requirements

8 directions

LED

Description/ Role

1 LED for setting display

USB/PS2/PS3 Cable

Description/ Role

2.1m length

Motor

Description/ Role

Vibration feature on PC/PS2/PS3

4

GB

Mechanical requirements

Single Motor with a big mass slot in the right side of the wheel rim

Button Assigment:

PC platform PS2/PS3 platform

Buttons layout on PS3/PS2/PC

USB

POSITION PS3 PS2

PC

1 X X 3

2

o o

4

3 Δ Δ 1

4

 

2

5 L1 L1 7

6 R1 R1 8

7 L2 L2 6

8 R2 R2 5

9 Select Select 9

10 Start Start 10

11 Mode & PS home button Mode Mode

12 D_PAD D_PAD D_PAD

Left hand lever L2 L2 2

Right hand lever R2 R2 1

Left Pedal

o o

RY↓

Right Pedal X X RY↑
