Hotpoint-Ariston BWMD 742: Description of the washing machine

6

GB

Detergent dispenser drawer:

 used to dispense

detergents and washing additives (

see “Detergents and

laundry”

).

ON/OFF

button

:

 press this briefly to switch the ma-

chine on or off. The START/PAUSE indicator light, which

flashes slowly in a green colour shows that the machine is

switched on. To switch off the washing machine during the

wash cycle, press and hold the button for approximately 2

seconds; if the button is pressed briefly or accidentally the

machine will not switch off. If the machine is switched off

during a wash cycle, this wash cycle will be cancelled.

WASH CYCLE SELECTOR

buttons

:

 used to set the

desired wash cycle

(see “Table of wash cycles”).

MEMORY

button

:

 press and hold the button to store a

cycle with your own set of preferences in the memory of

the machine. To recall a previously stored cycle, press the

MEMORY button.

FUNCTION

buttons

:

press the button to select the

desired function. The corresponding indicator light on the

display will switch on.

SPIN

button

  :

 press to reduce or completely exclude

the spin cycle - the value is indicated on the display.

TEMPERATURE

button

:

 press to decrease the tem-

perature: the value will be shown on the display.

CONTROL PANEL LOCK

button

:

to

activate

the control panel lock, press and hold the button for

approximately 2 seconds. When the symbol

 is

illuminated, the control panel is locked. This means it

is possible to prevent wash cycles from being modified

accidentally, especially where there are children in the

home. To

deactivate

the control panel lock, press and

hold the button for approximately 2 seconds.

DELAYED START

button

:

 press to set a delayed start

time for the selected wash cycle. The delay time will be

shown on the display.

START/PAUSE

button with indicator light: when the gre-

en indicator light flashes slowly, press the button to start a

wash cycle. Once the cycle has begun the indicator light

will remain lit in a fixed manner. To pause the wash cycle,

press the button again; the indicator light will flash in an

orange colour. If the symbol

 is not illuminated, the door

may be opened. To start the wash cycle from the point at

which it was interrupted, press the button again.

Standby mode

This washing machine, in compliance with new energy sa-

ving regulations, is fitted with an automatic standby system

which is enabled after about 30 minutes if no activity is

detected. Press the ON-OFF button briefly and wait for the

machine to start up again.

Consumption in off-mode: 0,5 W

Consumption in Left-on: 0,5 W

Description of the washing  machine

SPIN SPEED

Button

START/PAUSE

button with indicator

light

Control panel

TEMPERATURE

Button

WASH

CYCLE

SELECTOR

Buttons

Detergent dispenser drawer

FUNCTION

buttons

ON/OFF

button

DISPLAY

DELAYED

START

Button

MEMORY

Button

CONTROL PANEL

LOCK

button

GB

7

Display

The display is useful when programming the machine and provides a great deal of information.

The two upper strings

A

and

B

provide details of the wash cycle selected, the wash cycle phase in progress and all informa-

tion relating to the progress status of the wash cycle.

String

C

shows the time remaining until the end of the wash cycle in progress and, if a DELAYED START has been set, the

time remaining until the start of the selected wash cycle.

String

D

shows the maximum spin speed value (this depends on the selected wash cycle); if the wash cycle does not include

a spin cycle, the string remains unused.

String

E

shows the maximum temperature value which may be selected (this depends on the wash cycle used); if the tempe-

rature of the wash cycle cannot be modified, the string remains unused.

Indicator lights

F

correspond to the functions and light up when the selected function is compatible with the set wash cycle.

Door locked symbol

If the symbol is lit, this indicates that the washing machine door is blocked to prevent it from being opened accidentally. To

prevent any damage from occurring, wait for the symbol to switch itself off before opening the appliance door.

N.B.:

 if the DELAYED START function has been activated, the door cannot be opened; pauses the machine by pressing the

START/PAUSE button if you wish to open it.

!

 The first time the machine is switched on, you will be asked to select the language and the display will automatically show

the language selection menu.

To select the desired language press the

X

and

Y

buttons; to confirm the selection press the

Z

button.

To change the language switch off the machine and press buttons

X

,

Y

,

Z

simultaneously

 until an alarm is heard: the

language-selection menu will be displayed again.

A

B

C

D

E

Z

X

Y

START/PAUSE

button with indicator

light

F
