Milwaukee MS 304 DB: English English

TECHNICAL DATA MITRESAW

MS 305 DB MS 304 DB

230 / 240 V 110

V 230 V / 240 V 110

V

Rated input ........................................................................ 1800 W .....................1800 W ..................... 1800 W ......................1800 W

Amps ........................................................................................8 A ........................15 A............................. 8 A ......................15,5 A

-1

-1

-1

-

No-load speed .................................................................... 3200 min

...............3200 min

................ 3900 min

................3900 min

Saw blade dia. x hole dia ...............................................305 x 30 mm .............305 x 30 mm .............305 x 30 mm ............. 305 x 30 mm

Saw blade thickness ..............................................................2,4 mm .....................2,4 mm ..................... 2,4 mm ......................2,4 mm

Max. cutting width

Mitre 0°/ Bevel 0° .................................................... 102 / 342 mm ...........102 / 342 mm ...........102 / 342 mm ............102 / 342 mm

Mitre 45°/ Bevel 0° .................................................. 102 / 241 mm ...........102 / 241 mm ........... 102 / 241 mm ............102 / 241 mm

Mitre 0°/ Bevel 45°

............................................. 57 / 342 mm .............57 / 342 mm .............57 / 342 mm ..............57 / 342 mm

Mitre 0°/ Bevel 45°

............................................. 45 / 342 mm .............45 / 342 mm .............45 / 342 mm ..............45 / 342 mm

Mitre 45°/ Bevel 45° ........................................... 57 / 241 mm .............57 / 241 mm .............57 / 241 mm ..............57 / 241 mm

Mitre 45°/ Bevel 45°

........................................... 45 / 235 mm .............45 / 235 mm .............45 / 235 mm ..............45 / 235 mm

Max. height

Mitre 0°/ Bevel 0° ...................................................... 166 / 53 mm .............166 / 53 mm ............. 166 / 53 mm ..............166 / 53 mm

Mitre 45°/ Bevel 0° .................................................... 166 / 10 mm .............166 / 10 mm .............166 / 10 mm ..............166 / 10 mm

Min. workpiece dimensions .................................... 130 x 35 x 2 mm ....... 130 x 35 x 2 mm ........130 x 35 x 2 mm ........ 130 x 35 x 2 mm

Weight according EPTA-Procedure 01/2003 ........................ 30,2 kg .....................30,2 kg ...................... 29,9 kg ......................29,9 kg

GB

GB

Noise/Vibration Information

Measured values determined according to EN 61029. Typically, the A-weighted noise levels of the tool are:

Sound pressure level (K=3dB(A)) .......................................... 95 dB (A) ..................95 dB (A) ............... 93,5 dB (A) ................93,5 dB (A)

Sound power level (K=3dB(A)) ............................................ 108 dB (A) ................108 dB (A) ................105 dB (A) .................105 dB (A)

Wear ear protectors!

Total vibration values (vector sum in the three axes) determined according to EN 61029.

Vibration emission value a

h

2

2

2

2

Sawing of wood ................................................................ < 2,5 m/s

................< 2,5 m/s

.................... 3,3 m/s

.....................3,3 m/s

2

2

2

2

Uncertainty K= ..................................................................... 1,5 m/s

....................1,5 m/s

.................... 1,5 m/s

.....................1,5 m/s

WARNING

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given in EN 61029 and

may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.

The declared vibration emission level represents the main applications of the tool. However if the tool is used for dierent applications, with

dierent accessories or poorly maintained, the vibration emission may dier. This may signicantly increase the exposure level over the total

working period.

An estimation of the level of exposure to vibration should also take into account the times when the tool is switched o or when it is running

but not actually doing the job. This may signicantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the eects of vibration such as: maintain the tool and the accessories, keep

the hands warm, organisation of work patterns.

Always disconnect the plug from the socket before carrying out any

WARNING! Read all safety warnings and all instruc-

work on the machine.

tions, including those given in the accompanying brochure.

Only plug-in when machine is switched o.

Failure to follow the warnings and instructions may result in electric

shock, re and/or serious injury.

Keep mains lead clear from working range of the machine. Always

lead the cable away behind you.

Save all warnings and instructions for future reference.

Before use check machine, cable, and plug for any damages or

material fatigue. Repairs should only be carried out by authorised

SAFETY INSTRUCTIONS

Service Agents.

Wear ear protectors. Exposure to noise can cause hearing loss.

The handle lock must always be engaged when transporting the

Always wear goggles when using the machine. It is recommended to

mitre saw.

wear gloves, sturdy non slipping shoes and apron.

Ensure that the machine is always stable and secure (e.g. xed to a

The dust produced when using this tool may be harmful to health.

bench)

Do not inhale the dust. Use a dust absorption system and wear a

Keep the oor area free of loose material e.g. chips and cut-os.

suitable dust protection mask. Remove deposited dust thoroughly,

Before using the tool please read the instructions. If possible have the

e.g. with a vacuum cleaner.

tool demonstrated.

Appliances used at many dierent locations including open air should

Always use the protective shields on the machine.

be connected via a residual current device (FI, RCD, PRCD) of 30mA

or less.

Only use the saw with guards in good working order and properly

maintained, and in position.

English
