Indesit DISP 5377: Loading the racks

Loading the racks

Before loading the racks, remove all food residues from

Tilt A Tilt B Tilt C

EN

the crockery and empty liquids from glasses and cups.

Arrange the crockery so that it is held in place firmly and

does not tip over.

After loading the appliance, check that the sprayer arms can

rotate freely.

-Lift the tip-up compartment, slide it gently and position it in the

Lower rack

desired tilt angle.

The lower rack can hold pans, lids, plates, salad bowls, cutlery,

etc. as seen in the

Loading examples.

Adjusting the height of the upper rack

Plates and large covers should be placed at the sides of the

In order to make it easier to arrange the crockery, the upper rack

rack, ensuring that they do not block the rotation of the upper

may be moved to a higher or lower level.

sprayer arm.

The height of the upper rack should ideally be adjusted

Some dishwasher models are fitted with

WHEN THE RACK IS EMPTY.

tip-up sections

*, which can be used in a

vertical position when arranging plates

Never lift or lower the rack on one side only.

or in a horizontal position when arranging

Open the left and right guide rail stops

pans and salad bowls.

and pull out the rack; position it higher or

lower as required, slide it along the guide

Cutlery basket

rails until the front wheels are in place and

The type of cutlery basket may vary according to the dishwasher

close the stops (

see figure

).

model: The cutlery basket should be positioned at the front of the

lower rack, by sliding it between the fixed inserts, or on the

If the rack is fitted with “Dual Space”

upper rack when the half load option has been selected (in models

handles

* (

see figure

), pull out the upper

featuring this option).

rack until it reaches its stop point, grip the

handles at the sides of the rack and move

- It has a collapsible sliding

it upwards or downwards, then slowly let it

system which means the cutlery

fall back into place.

can be arranged in the best

Loading examples for the upper rack

possible way.

Knives and other utensils with sharp edges must be placed

in the cutlery basket with the points facing downwards, or they

must be positioned horizontally in the tip-up compartments on

the upper rack.

Cutlery basket positioning examples

Loading examples for the lower rack

Upper rack

Load this rack with delicate and lightweight crockery: glasses,

Items which should not be washed in the

tea and coffee cups, saucers, small salad bowls, saucepans

and small saucepans which are not too soiled, using the

Loading

dishwasher

examples

as a guide.

• Wooden items, objects with wooden or horn handles or glued-

• Mugs and cups, long sharp knives and serving utensils: place

on parts.

these on the tip-up compartments

**.

• Items made from aluminium, copper, brass, pewter or tin.

• Items made from plastic material which is not heat-resistant.

• Antique or hand-painted porcelain.

Tip-up compartments with adjustable tilt*

• Antique silver. Silver which is not antique may, however, be

- The tilt feature can be used to increase the space in the upper

washed in the dishwasher using a delicate wash cycle,

rack, to position wine glasses with different stem lengths safely

provided that it does not come into contact with other metals.

and to improve drying performance.

We recommend the use of crockery which is dishwasher

*Only available in selected models.

safe.

** The number and position may vary.

17
