Indesit DISP 5377: Installation

Installation

Keep this instruction manual in a safe place for future

Connecting the water inlet hose

EN

reference. If the appliance is sold, given away or moved,

• To a suitable cold water connection point: before

please ensure the manual is kept with the machine, so that

attaching the hose, run the water until it is perfectly clear

the new owner may benefit from the advice contained within

so that any impurities that may be present in the water

it.

do not clog the appliance; after performing this

operation, screw the inlet hose tightly onto a tap with a

Please read this instruction manual carefully: it

¾ gas threaded connection.

contains important information regarding the safe

installation, use and maintenance of the appliance.

• To a suitable hot water connection point: your

dishwasher may be supplied with hot water from the

If the appliance must be moved at any time, keep it in

mains supply (if you have a central heating system with

an upright position; if absolutely necessary, it may be tilted

radiators) provided that it does not exceed a temperature

onto its back.

of 60°C.

This appliance is intended to be used in household

Screw the hose to the tap as described for connection

and similar applications such as:

to a cold water supply.

- staff kitchen areas in shops, offices and other working

If the inlet hose is not long enough, contact a specialist

environments;

store or an authorised technician (

see Assistance

).

- farm houses;

- by clients in hotels, motels and other residential type

The water pressure must be within the values indicated

environments;

in the Technical data table (

see adjacent information

).

- bed and breakfast type environments.

The hose should not be bent or compressed.

Positioning and levelling

1. Remove the appliance from all packaging and check

Connecting the water outlet hose

that it has not been damaged during transportation.

Connect the outlet hose (without bending it) to a drain duct

If it has been damaged, contact the retailer and do not

with a minimum diameter of 4 cm.

proceed any further with the installation process.

2. Check the dishwasher by placing it so that its sides or

back panel are in contact with the adjacent cabinets or

even with the wall. This appliance can also be recessed

under a single worktop

* (

see the Assembly instruction

sheet

).

3. Position the dishwasher on a level and sturdy floor. If the

floor is uneven, the front feet of the appliance may be

adjusted until it reaches a horizontal position. If the

appliance is levelled correctly, it will be more stable and

The outlet hose must be at a height ranging from 40 to 80

much less likely to move or cause vibrations and noise

cm from the floor / surface where the dishwasher rests (A).

while it is operating.

Before connecting the water outlet hose to the sink drain,

remove the plastic plug (B).

4. Adjust the height of the rear foot from the front of the appliance*

on the central lower part of the dishwasher, turning a hexagonal

Anti-flooding protection

spanner (red color) with an opening of 8 mm in a clockwise

To ensure floods do not occur, the dishwasher:

direction to increase the height or in an anticlockwise direction to

- is provided with a special system which blocks the water

decrease the height.

supply in the event of anomalies or leaks from inside the

appliance.

Connecting the water and electricity

supplies

Some models are also equipped with the supplementary

safety device

New Acqua Stop

*, which guarantees anti-

Connection to the water and electricity supplies should

flooding protection even in the event of a supply hose

only be performed by a qualified technician.

rupture.

The dishwasher should not stand on top of the water

hoses or the electricity supply cable.

WARNING: HAZARDOUS VOLTAGE!

The appliance must be connected to the water supply

Under no circumstance should the water inlet hose be cut

network using new hoses.

as it contains live electrical parts.

Do not use old hoses.

The water inlet and outlet hoses and the electricity supply

cable may be positioned towards the right or the left in

* Only available in selected models.

order to achieve the best possible installation.

14
