Karcher HKF 50 E: Technical specifications

14

English

Technical specifications

HKF 50 E

HKF 50 P

Order No.

3.631-009

3.631-008

Max. flow rate

l/h (l/min)

1200 (20)

1200 (20)

Max. temperature with water with cleaning agents

°C

95

95

Max. temperature with solvents, brines, acids

°C

20

20 Ex

Max. operating pressure

MPa (bar)

10 (100)

10 (100)

Max. operating pressure with solvent operation

MPa (bar)

--

5 (50) Ex

Voltage

V

230

--

Current type

--

1~

--

Frequency

Hz

50

--

Rated power

W

20

--

Type of protection

--

IP 65

--

Compressed air

MPa (bar)

--

0,4-0,7 (4-7)

Compressed air flow rate

I/min

--

450

Functional speed - drive

1/min

29

10-20

Sound pressure level (EN 60704-1)

dB(A)

65

83 (without silencer)

High pressure connection

--

DN 15 - M22x1.5

DN 15 - M22x1.5

Minimum container opening

mm

55

55

Total length

mm

650

715

Max. immersion depth

mm

304

304

Weight kg

7

7

Ambient temperature

°C

+2...+40

+2...+40

Ignition protection class

--

II 1/2 G c T4

II 1/3 D c 120 °C

Dimensional sheet sheet HKF 50
