INSTRUCTION MANUAL

Manual or OFF with adjustments to EV or power levels.

TTL: Will  re  ashes using TTL metering. The EV level of

Ratio is similar to Canon’s native TTL system. The ratio of

each group can be adjusted up or down (see above).

groups A and B can be set from 8:1 to 1:8. EV levels can

also be adjusted.

M: Flashes can be set in Manual mode and power levels

adjusted.

To change function screens:

Press the Option button on the TCU. The Option Button

O : Selecting O (signi ed by three underscores _ _ _)

will switch between TTL/Mixed and Ratio screens

will turn o the selected group and not  re any remote

 ashes in that group.

TTL/Mixed Functions Screen

The Selection Button allows you to cycle through groups

Ratio Functions Screen

A, B, and C, and Channel selections. Active selections will

The Selection Button allows you to cycle through ratio

 ash on the LCD. The - / + buttons will change the EV

A:B adjustment, EV adjustment and Channel selections.

adjustments or Power Level while groups A, B or C are

Press the Selection button to access ratio adjustments.

selected and will change the transmission channel (1,

Press the + / - button until the desired A:B ratio is

2, 3 or 4) when Channel is selected. This will change the

achieved.

channel the TCU uses to transmit. The TCU will work on

Pressing the Selection button again will move the active

the last channel which was adjusted.

selection to the EV adjustment section. Press the + / -

button until the desired EV level is achieved.

TTL / M / O

Transmission channels can be changed when CH is

While groups A, B or C are selected, pressing the

active. This will change the channel the TCU uses to

Mode button will change from TTL, (M) Manual, or O

transmit.

functions.
