Milwaukee V18 PD: 18 19 ENGLISH ENGLISH

TECHNICAL DATA

V18 DD V18 PD

SPECIFIED CONDITIONS OF USE

Drilling capacity in steel ........................................................................

...........................13 mm ..........................13 mm

The battery screwdriver is designed for drilling and

Drilling capacity in wood .......................................................................

...........................38 mm ..........................38 mm

screwdriving for independent use away from mains supply.

Drilling capacity in brick and tile ...........................................................

..............................- ................................16 mm

Do not use this product in any other way as stated for normal

Wood screws (without pre-drilling) .......................................................

...........................12 mm ..........................12 mm

use.

No-load speed ......................................................................................

1st gear .............................................................................................

......................0-500 /min .....................0-500 /min

BATTERIES

2nd gear .............................................................................................

....................0-1600 /min ...................0-1600 /min

Torque

Please take note of the specic information relating to

Low torque*1 .....................................................................................

...........................32 Nm ...........................32 Nm

Milwaukee 18V rechargeable batteries in the instruction

High torque*1 .....................................................................................

...........................71 Nm ...........................71 Nm

manual for the charger.

Static jamming moment, 1st gear/2nd gear *1 .................................

......................47/19 Nm ......................47/19 Nm

New battery packs reach full loading capacity after 4 - 5

Screwing capacity with one fully charged battery (3,0 Ah) : *2

chargings and dischargings. Battery packs which have not

5x40 Soft wood .................................................................................

.............................500 ...............................500

been used for some time should be recharged before use.

Drilling capacity with one fully charged battery (3,0 Ah):

Temperatures in excess of 50°C (122°F) reduce the

ø 3 mm Steel plate 1,6 mm ...............................................................

.............................500 ...............................500

performance of the battery pack. Avoid extended exposure to

ø 6 mm Soft wood 20 mm .................................................................

.............................660 ...............................660

heat or sunshine (risk of overheating).

Battery voltage ......................................................................................

...........................18 V ..............................18 V

Drill opening range ...............................................................................

.....................1,5-13 mm ....................1,5-13 mm

The contacts of chargers and battery packs must be kept

Weight with battery ...............................................................................

..........................2,6 kg ............................2,6 kg

clean.

Typical A-weighted sound levels:

Sound pressure level (K = 3 dB(A)) ....................................................

...........................73 dB (A) ......................89 dB(A)

ADVICE FOR OPERATION

Sound power level (K = 3 dB(A)) ........................................................

...........................84 dB (A) ....................100 dB(A)

Never use the gear switch whilst the machine is operating.

2

2

Typical weighted acceleration in the hand-arm area ...........................

.......................< 2,5 m/s

.........................4,5 m/s

Only use the switch when the machine is at a standstill.

Measured values determined according to EN 60 745.

MAINTENANCE

*1 Measured according to Milwaukee norm N 877318

*2 The values stated are reference values.

Use only Milwaukee accessories and spare parts. Should

Actual values might differ, depending on the material and quality of the screws.

components need to be replaced which have not been

described, please contact one of our Milwaukee service agents

(see our list of guarantee/service addresses).

WARNING

If needed, an exploded view of the tool can be ordered. Please

The vibration emission level given in this information sheet has been measured in accordance with a standardised test given

state the Article No. as well as the machine type printed on the

in EN 60745 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.

label and order the drawing at your local service agents or

The declared vibration emission level represents the main applications of the tool. However if the tool is used for different

directly at: Milwaukee Electric Tool, Max-Eyth-Straße 10,

applications, with different accessories or poorly maintained, the vibration emission may differ. This may signicantly increase

D-71364 Winnenden, Germany.

the exposure level over the total working period.

An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or

SYMBOLS

when it is running but not actually doing the job. This may signicantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the

Please read the instructions

accessories, keep the hands warm, organisation of work patterns.

carefully before starting the

machine.

WARNING! Read all safety warnings and all

Do not dispose of used battery packs in the household refuse

Accessory - Not included in standard equipment,

instructions, including those given in the accompanying

or by burning them. Milwaukee Distributors offer to retrieve old

available as an accessory.

brochure. Failure to follow the warnings and instructions

batteries to protect our environment.

may result in electric shock, re and/or serious injury.

Do not store the battery pack together with metal objects (short

Save all warnings and instructions for future reference.

circuit risk).

Use only System PBS 3000 / V18 chargers for charging

Remove the battery pack before starting any

SAFETY INSTRUCTIONS

System PBS 3000 / V18 battery packs.

work on the machine.

Always wear goggles when using the machine. It is

No metal parts must be allowed to enter the battery section of

recommended to wear gloves, sturdy non slipping shoes and

the charger (short circuit risk).

apron.

Never break open battery packs and chargers and store only in

Do not dispose of electric tools together with

Wear ear protectors. Exposure to noise can cause hearing

dry rooms. Keep dry at all times.

household waste material! In observance of

loss.

Battery acid may leak from damaged batteries under extreme

European Directive 2002/96/EC on waste

Use auxiliary handles supplied with the tool. Loss of control

load or extreme temperatures. In case of contact with battery

electrical and electronic equipment and its

can cause personal injury.

acid wash it off immediately with soap and water. In case of

implementation in accordance with national law,

Hold power tool by insulated gripping surfaces, when

eye contact rinse thoroughly for at least 10 minutes and

electric tools that have reached the end of their

performing an operation where the cutting accessory

immediately seek medical attention.

life must be collected separately and returned to

may contact hidden wiring. Cutting accessory contacting

an environmentally compatible recycling facility.

The dust produced when using this tool may be harmful to

a live“ wire may make exposed metal parts of the power tool

health. Do not inhale the dust. Wear a suitable dust protection

live“ and shock the operator.

mask.

Always wear goggles when using the machine. It is

recommended to wear gloves, sturdy non slipping shoes

EC-DECLARATION OF CONFORMITY

and apron.

We declare under our sole responsibility that this product is in

Always wear goggles when using the machine. It is

conformity with the following standards or standardized

recommended to wear gloves, sturdy non slipping shoes and

documents. EN 60745, EN 55014-1, EN 55014-2, in

apron.

accordance with the regulations 98/37/EC, 2004/108/EC

Sawdust and splinters must not be removed while the machine

is running.

When working in walls ceiling, or oor, take care to avoid

electric cables and gas or waterpipes.

Winnenden, 2009-01-14

Rainer Kumpf

Manager Product Development
