Milwaukee AGV 23-230: ENGLISH

TECHNICAL DATA

AG 20-180 AGV 20-180 AG 23-180 AG 20-230 AG 23-230 AGV 23-230

AG 20-230 B AG 23-230 B

230 V 110 V 230 V 110 V

Rated input (W) ...................................................................................

.... 2000 ............2000 ............ 2300 ............. 2000 ........ 2300 .........2100 ......2300 ....... 2100

Output (W) ...........................................................................................

.... 1200 ............1200 ............ 1400 ............. 1200 ........ 1400 .........1250 ......1400 ....... 1250

-1

Max. no-load speed (min

) ................................................................

.... 8500 ............8500 ............ 8500 ............. 6600 ................6600 ........................ 6600

Grinding disk diameter (mm) .............................................................

..... 180 ..............180 .............. 180 ............... 230 ..................230 .......................... 230

Thread of work spindle .......................................................................

.... M 14 ............M 14 ............ M 14 ............. M 14 ................M 14 ........................ M 14

Weight without cable (kg) ...................................................................

......5,1 .............. 5,2 ................5,4 ................5,3 .................. 5,6 ............................5,7

Typical weighted acceleration in the

2

hand-arm area (m/s

) .........................................................................

......4,6 .............< 2,5 ..............4,3 ................3,7 .................. 4,0 .......................... < 2,5

Typical A-weighted sound levels:

Sound pressure level (dB (A)) .......................................................

...... 92 ................93 ................ 96 ................. 93 ....................94 ............................ 94

Sound power level (dB (A)) ...........................................................

..... 105 ..............106 .............. 109 ............... 106 ..................107 .......................... 107

Wear ear protectors! Measured values determined according to

EN 50 144.

SAFETY INSTRUCTIONS

EC-DECLARATION OF CONFORMITY

Please pay attention to the safety instructions in the attached leaflet!

We declare under our sole responsibility that this product is in conformity with

the following standards or standardized documents. EN 50144, EN 55014-1,

Appliances used at many different locations including open air must be

EN 55014-2, EN 61000-3-2, EN 61000-3-3 (AG... B), EN 61000-3-11 (AG...),

connected via a residual current device.

in accordance with the regulations 98/37/EC, 89/336/EEC

Always wear goggles when using the machine. It is recommended to wear

gloves, sturdy non slipping shoes and apron.

Dust and splinters must not be removed while the machine is running.

Always disconnect the plug from the socket before carrying out any work on

Volker Siegle

the machine.

Manager Product Development

Only plug-in when machine is switched off.

MAINS CONNECTION

Keep mains lead clear from working range of the machine. Always lead the

cable away behind you.

Connect only to single-phase a.c. current and only to the system voltage

indicated on the rating plate. It is also possible to connect to sockets without an

After switching off, the machine will not be idle immediately. (After-running of

earthing contact as the design conforms to safety class II.

the work spindle.) Allow the machine to come to a stop before putting down.

Never reach into the danger area of the tool when it is running.

MAINTENANCE

Always use the auxiliary handle.

The ventilation slots of the machine must be kept clear at all times.

Always use the protecting guard when roughing-down and separating.

Use only Milwaukee accessories and Milwaukee spare parts. Should

Only use tools whose permitted speed is at least as high as the highest no-

components need to be replaced which have not been described, please

load speed of the machine.

contact one of our Milwaukee service agents (see our list of guarantee/service

Pay attention to the dimensions of the grinding disc. The mounting hole

addresses).

diameter must fit the mounting flange without play. Do not use reducer pieces

If needed, an exploded view of the tool can be ordered. Please state the ten-

or adapters.

digit No. as well as the machine type printed on the label and order the

Check grinding tools before use. The grinding tool must be properly mounted

drawing at your local service agents or directly at: Milwaukee Electric Tool,

and turn freely. Perform a test run for at least 30 seconds without load. Do not

Max-Eyth-Straße 10, D-71364 Winnenden, Germany

.

use damaged, out of round or vibrating grinding tools.

STARTING CURRENT LIMITED (AG 20/23-230 B)

Immediately switch off the machine in case of considerable vibrations or if

other malfunctions occur. Check the machine in order to find out the cause.

The starting current for the machine is several times greater than rated current.

Always use and store the grinding disks according to the manufacturer's

The starting current limited produces the starting current to such an extent that

instructions.

a fuse (16 A, slow-blow) is not tripped.

When grinding metal, flying sparks are produced. Take care that no persons

SYMBOLS

are endangered. Because of the danger of fire, no combustible materials

should be located in the vicinity (spark flight zone). Do not use dust extraction.

Due care should be taken that no sparks or sanding dust flying from the

Please read the instructions carefully before starting the

workpiece come into contact with you.

machine.

Never use a cutting disc for grinding. Do not subject cutting discs to side

pressure.

Always wear goggles when using the machine.

When separating stone the guide shoe must be used!

The adjusting nut must be tightened before starting to work with the machine.

The workpiece must be fixed if it is not heavy enough to be steady. Never lead

the workpiece to the grinding disk with your hand.

Always disconnect the plug from the socket before

Under extreme conditions (e.g. smooth-grinding metals with the arbour and

carrying out any work on the machine.

vulcanized fibre grinding wheel), significant contamination can build up on the

inside of the angle grinder. For safety reasons, in such conditions the inside

should be cleaned thoroughly of metal deposits and a motor circuit-breaker

Accessory - Not included in standard equipment,

must be connected in series. If the motor circuit-breaker trips the machine

available as an accessory.

must be sent for repair.

Inrush currents cause short-time voltage drops. Under unfavourable power

Do not dispose of electric tools together with household

supply conditions, other equipment may be affected. If the system impedance

waste material! In observance of European Directive

of the power supply is lower than 0,2 Ohm, disturbances are unlikely to occur.

2002/96/EC on waste electrical and electronic equipment

The dust that arises when working with this tool can be detrimental to health

and its implementation in accordance with national law,

and therefore not reach the body. Wear a suitable dust protection mask.

electric tools that have reached the end of their life must

be collected separately and returned to an

For tools intended to be fitted with threaded hole wheel, ensure that the thread

environmentally compatible recycling facility.

in the wheel is long enough to accept the spindle length.

SPECIFIED CONDITIONS OF USE

This angle grinder can be used for separating and grinding many different

materials, e.g. metal or stone. In case of doubt please read the manufacturers'

instruction.

Do not use this product in any other way as stated for normal use.

19

ENGLISH
