GBC H420 Laminator: инструкция

GBC QuickStart

H320 & H420

Laminator

G

Instruction Manual

F

Manuel d’utilisation

D

Bedienungsanleitung

I

Manuale d’istruzioni

O

Gebruiksaanwijzing

E

Manual de instrucciones

P

Manual de Instruções

T

Kullanım Kılavuzu

K

Οδηγίες

c

Brugsvejledning

FI

o

Käyttöopas

NO

o

Bruksanvisning

S

Bruksanvisning

Q

Instrukcja obsługi

o

CZ

Návod k obsluze

H

Használati útmutató

RUS

o

Руководствo по

зкcплyатации

English 4

Français 6

Deutsch 8

Italiano 10

Nederlands 12

Español 14

Português 16

Türkçe 18

Ελληνικά 20

Dansk 22

Suomi 24

Norsk 26

Svenska 28

Polski 30

Česky 32

Magyar 34

Pyccкий 36

4 5 6

1 32

Technical specifications

GBC QuickStart H320

GBC QuickStart H420

Electrical

230-240V/50hZ/6Amps/1200W

230-240V/50hZ/6Amps/1200W

Machine Dimensions

495 x 140 x 117.5mm

495 x 140 x 117.5mm

Machine Weight

3.1kg

3.9kg

Maximum Pouch Width

317mm

317mm

Maximum Pouch Thickness

2x125Mic (250 Total)

2x175Mic (350 Total)

Maximum Thru-put Thickness

1.0mm

1.0mm

Warm-Up Time (hot lamination)

Approximately 1 minute

Approximately 1 minute

Ready Time (cold lamination)

Instant

Instant

Speed

483mm per min

610mm per min

Safety instructions

Important safeguards

m

m

YOUR SAFETY AS WELL AS THE SAFETY OF OTHERS IS IMPORTANT

warnIng: for Your proTecTIon do noT connecT

®

TO ACCO

BRANDS. IN THIS INSTRUCTION MANUAL AND ON THE

m

The pouch LaMInaTor To eLecTrIcaL power unTIL

PRODUCT ARE IMPORTANT SAFETY MESSAGES. READ THESE

You read TheSe InSTrucTIonS coMpLeTeLY. Keep

MESSAGES CAREFULLY.

TheSe InSTrucTIonS In a conVenIenT LocaTIon for

fuTure reference. To guard agaInST InJurY, The

The SafeTY aLerT SYMBoL precedeS each SafeTY

foLLowIng BaSIc SafeTY precauTIonS MuST Be

m

MeSSage In ThIS InSTrucTIon ManuaL.

oBSerVed In The SeT-up and uSe of ThIS producT.

ThIS SYMBoL IndIcaTeS a poTenTIaL perSonaL

SafeTY haZard ThaT couLd hurT You or oTherS,

aS weLL aS cauSe producT daMage or properTY

Electrical safeguards

daMage.

• The unit must be connected to a supply voltage corresponding to the

ThIS warnIng IS found on The producT.

electrical rating shown on the unit.

• Unplug the unit before moving it, or when it is not in use for an

m

WARNING

extended period of time.

c

Electrical shock hazard.

• Do not operate with a damaged supply cord or plug. Do not alter the

Do not open. No user

attachment plug. The plug is congured for the appropriate electrical

servicable parts inside.

supply.

Refer servicing to qualified

• Do not overload electrical outlets beyond their capacity. Fire or

service personnel.

electrical shock could result.

This safety message means that you could be seriously hurt or killed if

• The unit is intended for indoor use only.

you open the product and expose yourself to hazardous voltage.

• Do not spill liquid of any kind on this product.

• Close supervision is required when this product is used near children.

Service

Do not attempt to service or repair the pouch laminator yourself. Unplug

General safeguards

®

the unit and contact an authorized GBC

service representative for any

required repairs.

• Use the unit only for its intended purpose of laminating documents.

• Do not place anything in the throat opening of the laminator other than

pouches/documents.

• Place unit on a secure, stable work area to prevent the unit from

falling and possibly causing personal injury and damage to the unit.

• Follow all warnings and instructions

• The socket outlet shall be installed near the equipment and shall be

easily accessible.

• Do not attempt single side lamination, this will destroy the laminator.

• Do not block the vent slots, this will cause the laminator to overheat.

4

G

Introduction

Jam Free feature

®

Thank you for purchasing this GBC

Pouch Laminator. The laminator

This machine is equipped with GBC SureFlow anti-jam performance

heats up to operating temperature quickly and retains its heat so you

which will prevent laminating pouches from jamming when used in

can laminate your documents without waiting. The laminator also

accordance with this instruction manual and when using GBC branded

provides cold lamination for cold lamination pouches. The laminator

pouches.

provides audible and visual indication that it is ready to laminate. The

• If you experience a pouch jam, place one hand on the machine and

laminator goes into a standby mode after 30 minutes of inactivity.

gently pull the pouch out the front of the machine with your other

Please take a little time to study these instructions to ensure you get the

hand (g. 6).

best out of your machine. Your new laminator may emit a slight odour

• Do not reuse the same pouch.

during the initial operation. It is normal and will diminish after a few

• Load a new pouch and review the Operation section of this manual.

hours of operation.

Cleaning

Transportation tabs

Caution: Unplug this product before cleaning the exterior. Wipe

Before use, the transportation tabs must be removed (g. 1).

m

exterior only with a damp cloth and do not use detergents or

1

Carefully peel away the tape.

solvents. Your laminator came with a cleaning card that is to

2

Pull the tabs inward to free them.

be used after each laminating session, prior to shutting off the

machine. Adhesive may exit the pouch and stick to the rollers

3

Remove the tabs.

while laminating or if a jam occurs. The cleaning card removes

this residue, keeping your machine in proper working order and

extending its life.

Operation

1

Run the cleaning sheet through the machine two or three times.

1

Connect power cord to appropriate power source.

2

Turn off the machine when nished laminating and cleaning.

2

For cold lamination, push the power button to turn on the machine.

The indicator will glow (g. 2). Skip step 3.

3

For hot lamination, select the button for the appropriate pouch

gauge thickness. The button will blink until it is ready. (g. 2).

4

Position the document to be laminated into a GBC laminating pouch,

so that the document is aligned to the folded sealed edge and the

right and left borders are equal (g. 3).

5

When the ready light turns on (g. 4) and the machine beeps, insert

the pouch and its contents straight into the machine, leading with

the folded sealed edge (g. 5).

6

The laminated item will automatically exit the rear of the machine.

7

You can select a different pouch thickness. If you select a lower

setting, the laminator must cool down to that setting before

laminating. The ready light will glow when the laminator is ready.

8

If you have nished laminating, push the power button to turn off the

machine (g. 2).

Guarantee

Operation of this machine is guaranteed for two years from date of

persons not authorised by ACCO Brands Europe will invalidate the

purchase, subject to normal use. Within the guarantee period, ACCO

guarantee. It is our aim to ensure that our products perform to the

Brands Europe will at its own discretion either repair or replace the

specications stated. This guarantee does not affect the legal rights

defective machine free of charge. Defects due to misuse or use for

which consumers have under applicable national legislation governing

inappropriate purposes are not covered under the guarantee. Proof

the sale of goods.

of date of purchase will be required. Repairs or alterations made by

Register this product online at www.accoeurope.com

5
