Инструкция к GBC HeatSeal Inspire Laminator
GBC Inspire
Laminator
G
Instruction Manual
F
Manuel d’utilisation
D
Bedienungsanleitung
I
Manuale d’istruzioni
O
Gebruiksaanwijzing
E
Manual de instrucciones
P
Manual de Instruções
T
Kullanım Kılavuzu
K
Οδηγίες
c
Brugsvejledning
o
FI
Käyttöopas
o
NO
Bruksanvisning
S
Bruksanvisning
Q
Instrukcja obsługi
o
CZ
Návod k obsluze
H
Használati útmutató
RUS
o
Руководствo по
зкcплyатации
U
A
1
2
3
4
Technical specifications
GBC Inspire Laminator
Electrical
A4: 230 VAC/50 Hz/0.46 A/110W
A3: 230 VAC/50 Hz/0.56 A/130W
Machine Dimensions
A4: 355 x 90 x 76 mm
A3: 457 x 90 x 76 mm
Machine Weight
A4: 1.0 kg
A3: 1.2 kg
Maximum Pouch Width
A4: 241.3 mm
A3: 303 mm
Maximum Pouch Thickness
2 x 75 micron (total 150)
Maximum Thru-put Thickness
0.6 mm
Warm-Up Time
Approximately 7 minutes
Speed
254 mm per minute
Safety instructions
m
Important safeguards
m
YOUR SAFETY AS WELL AS THE SAFETY OF OTHERS IS IMPORTANT
wArning: for Your proTecTion, do noT connecT
®
TO ACCO
BRANDS. IN THIS INSTRUCTION MANUAL AND ON THE
m
The pouch lAMinATor To elecTricAl power unTil
PRODUCT ARE IMPORTANT SAFETY MESSAGES. READ THESE
You reAd These insTrucTions coMpleTelY. Keep
MESSAGES CAREFULLY.
These insTrucTions in A convenienT locATion for
fuTure reference. To guArd AgAinsT inJurY, The
The sAfeTY AlerT sYMBol precedes eAch sAfeTY
following BAsic sAfeTY precAuTions MusT Be
m
MessAge in This insTrucTion MAnuAl.
oBserved in The seT-up And use of This producT.
This sYMBol indicATes A poTenTiAl personAl
wArning: To Avoid elecTricAl shocK or oTher
sAfeTY hAZArd ThAT could hurT You or oThers,
m
inJurY, The following sAfeTY precAuTions MusT
As well As cAuse producT dAMAge or properTY
Be oBserved.
dAMAge.
The following wArning is found on The producT in
Electrical safeguards
severAl lAnguAges.
• The unit must be connected to a supply voltage corresponding to the
m
WARNING
electrical rating shown on the unit.
c
Electrical shock hazard.
• Unplug the unit before moving it, or when it is not in use for an
Do not open. No user
extended period of time.
servicable parts inside.
• Do not operate with a damaged supply cord or plug. Do not alter the
Refer servicing to qualified
attachment plug. The plug is configured for the appropriate electrical
service personnel.
supply.
• Do not overload electrical outlets beyond their capacity.
This safety message means that you could be seriously hurt or killed if
you open the product and expose yourself to hazardous voltage.
• Fire or electrical shock could result.
• The unit is intended for indoor use only.
• Never push objects through the housing slots. Do not spill liquid of any
Service
kind on this product.
Do not attempt to service or repair the pouch laminator yourself. If unit
• Close supervision is required when this product is used near children.
becomes jammed or inoperable, immediately unplug and dispose of
properly.
General safeguards
• Use the unit only for its intended purpose of laminating documents.
• Do not place anything in the throat opening of the laminator other than
pouches/documents.
• Place unit on a secure, stable work area to prevent the unit from
falling and possibly causing personal injury and damage to the unit.
• Follow all warnings and instructions.
• The socket outlet shall be installed near the equipment and shall
be easily accessible. Do not attempt single side lamination, this will
destroy the laminator.
• Do not block the vent slots, this will cause the laminator to overheat.
4
G
Introduction
Cleaning
®
Thank you for purchasing this GBC
Pouch Laminator. The laminator
WARNING: UNPLUG THIS PRODUCT BEFORE CLEANING
heats up to operating temperature and retains its heat so you can
m
THE EXTERIOR. WIPE EXTERIOR ONLY WITH A DAMP
laminate your documents without waiting. The laminator provides a
CLOTH AND DO NOT USE DETERGENTS OR SOLVENTS.
visual indication that it is ready to laminate. Turn off power and unplug
Your laminator came with a cleaning card that is to be used after each
unit when it will not be used for extended periods of time.
laminating session, prior to shutting off the machine. Adhesive may exit
For best lamination results and performance, use only GBC 2 x 75
the pouch and stick to the rollers while laminating or if a jam occurs.
micron (total 150 micron) pouches.
The cleaning card removes this residue, keeping your machine in proper
working order and extending its life.
Please take a little time to study these instructions to ensure you get the
best results out of your machine. Your new laminator may emit a slight
1
Run the cleaning sheet through the machine two or three times.
odour during the initial operation. It is normal and will diminish after a
2
Turn off the machine when finished laminating and cleaning.
few hours of operation.
Laminating tips
Operation
• DO NOT LAMINATE AN EMPTY POUCH.
1
Connect power cord to appropriate power source.
• Never insert the loose end of the pouch first into the machine. This
2
Turn the unit On with the switch located on the back of the unit.
could cause the machine to jam. Always insert the sealed edge first.
3
Position the document to be laminated into a GBC laminating pouch,
• Before laminating important or unique documents, always run a test
so that the document is aligned to the folded sealed edge and the
pouch through the laminator using a similar type document.
right and left borders are equal (fig. 2).
• Do not attempt to do single sided lamination. This will destroy the
4
When the ready light turns on (A, fig. 1), insert the pouch and its
laminator.
contents straight into the machine, leading with the sealed edge
• As soon as hot lamination is completed, remove the lamination from
(fig. 3).
the rear of the machine and place on a cool flat surface for cooling to
5
The laminated item will exit from the rear of the machine. Once the
prevent the pouch from curling.
item is no longer moving, pull it free of the rear of the machine.
• Do not block the vent slots, this will cause the laminator to overheat.
6
Once you have finished laminating, push the power switch on the
• Do not cut pouches prior to lamination.
back of the machine to turn the unit Off.
Guarantee
Operation of this machine is guaranteed for two years from date of
persons not authorised by ACCO Brands Europe will invalidate the
purchase, subject to normal use. Within the guarantee period, ACCO
guarantee. It is our aim to ensure that our products perform to the
Brands Europe will at its own discretion either repair or replace the
specifications stated. This guarantee does not affect the legal rights
defective machine free of charge. Defects due to misuse or use for
which consumers have under applicable national legislation governing
inappropriate purposes are not covered under the guarantee. Proof
the sale of goods.
of date of purchase will be required. Repairs or alterations made by
Register this product online at www.accoeurope.com
