Binatone BS-8045: ENGLISH

7

ENGLISH

Sex

1. Press On/Set button

 (5)

to confirm the User’s age and to enter

the User’s sex input mode.

2. Use the button

(4)

to change the User’s sex (

/

).

Height

1. Press On/Set button

 (5)

to

confirm the User’s number and to

enter the User’s height input mode.

2. Use the button

(4)

to increase/ decrease the User’s height

(from 100 to 250 cm).

Age

1. Press On/Set button

 (5)

to

confirm the User’s height and to

enter the User’s age input mode.

2. Use the buttons

(4)

to increase/ decrease the User’s age (from

10 to 100 years).

Note 1

: if you do not introduce any datum within 15

seconds, the scale will switch off automatically.

Note 2

: while entering personal parameters, at any time you

may press the bottom part of the platform

(1)

 to

nullify the weight readings (in this case, the display

(2)

 will show «

0.0

») to start body weighting or  the

fat/water body content measuring, using the newly

introduced or updated data.

Body fat/water content measurement

1. Switch on the scale by pressing On/Set button

 (5).

The LCD

(2)

will show either initial data set by default, or the readings of the

last weighted User.

2. By pressing the up/ down buttons

(4)

, select your User’s num-

ber with the personal data you introduced.

Note:

 if you press the Direct Access button

(6)

with your

User’s number from1 to 4, you can immediately enter

the data input mode.

3. Before weighing, press by hand the bottom part of the platform

(1)

.

The weight reading indication on the display

(2)

 will high-

light «

0.0

».

4.  Now you can stand up on the platform

(1)

 and weigh your-

self. Keep waiting for a few seconds to allow the appliance to

calculate the result.

5.  Then, under the current weight reading indication, the «

BF

»

title and a percentage of fat content in the body will appear.

6.  After that, the «

BW

» title and a percentage of water content

in the body will appear.

7.  Then the measured recommended calorie intake and “

kcal

”

will be shown in the upper part of the display

(2).

8

8.  The display

(2)

 changes its color dependent on the result (ref.

to the below-mentioned Table of measurement results and

corresponding display readings). Five different colors reflect

the state of your organism.

9. The scale switches off automatically once the measurement is

over.

Note 1:

 if you step on the electrodes

(3)

 wearing shoes or

stocks, the scale will not be able to calculate the

percentage content of water/ fat, and in this case the

display

(2)

 will show “_ _ _”.

Note 2:

  body water and fat readings and recommended

calorie intake will appear 3 times one after another.

Note 3:

 if the body fat content is lower than 4.0% , “

Err-

l

” will appear on the display

(2)

. If the body fat

content  exceeds 60.0%, “

Err-h

” will appear on the

display

(2)

.

Quick data indication in the Direct Access

mode

Four buttons

(6)

 with numbers from 1 to 4 are located in the

bottom part of the platform

(1)

.  By pressing the numbered but-

ton, under which data for the first four Users stored in the memory

are introduced, you can immediately scroll these data.

1. Enter User’s data as shown in the

Personal data input

 sec-

tion. Data under each of four numbers will be stored automati-

cally.

2. Before next weighing, just press the number corresponding to

the User’s number (from 1 to 4). The previously introduced

data will appear on the display

(2).

3. Press by hand the bottom part of the platform

(1)

 to nullify

readings (display

(2)

 will show «

0.0

») to start weighing.

Note:

 if you have already used this scale to weigh yourself

and to measure fat/water content in the body, then,

after a repeated pressing of the Direct Access button

(6)

with your User’s number from

1 to 4, the  fat/

water content readings of the last measurement and

recommended calorie intake will appear one after

another on the display

(2).

Table of the fat/water percentage

measurement results

Having received the weighing results and measured the body

fat/water content, check the state of your organism against the

values indicated in the Table below:
