Using the setting key turn the adjusting

nut clockwise to increase the torque.

Turning anti-clockwise reduces the

torque.

■

Replace the cap (2).

Positioning the angle head.

Before commencing work remove the bat-

tery.

■

Push the cover (1) forward with the aid

of a screwdriver.

■

Undo both the front housing screws by

turning through approx. 2 full turns.

■

Adjust the position of the angle head by

turning. The angle head can be turned

through ± 180°.

■

Tighten the screws and push the

cover (1) over.

Meaning of LED display (4).

Green LED display (a) lights up:

The screwdriving procedure has been

properly carried out. The pre-set torque

has been reached.

The delay for turning on again is then only

active for 0.9 secs.

Red LED display (b) lights up and a singing

tone is heard:

The screwdriving procedure has not be

carried out properly. The pre-set torque

has not been reached. The screwdriving

procedure must be carried out once again.

The machine can be used immediately for

further screwdriving.

Red LED display (b) flashes (1/s):

The battery (9) has become dis-

charged (empty) and must be changed.

The power tool is blocked and not ready

for operation again until it has been

“dead” for approx. 20 secs.

Red LED display (b) flashes (2/s):

The power tool is overheated, the over-

heating protection has been activated.

Once the power tool has cooled down,

it will be ready to be used again.

If the overheating protection activates

several times at short intervals, have the

power tool overhauled by the customer

service.

Red and green LED displays flash:

The reverse rotation is switched on.

After the reverse rotation has been car-

ried out, or if the power tool is not used

for approx. 10 sec., it automatically

switches back to forward rotation.

Operating instructions

The machine is designed with a gentle

starting-up motion. This increases the life

of the motor and gears.

If the motor switches off after a proper

screwdriving procedure, it cannot be

switched on again until after 0.9 secs.

Tightening firmly seated screws uninten-

tionally is thereby avoided.
