Hand/arm vibrations

The vibration emission level given in this information

sheet has been measured in accordance with a standard-

ised test given in EN 60745 and may be used to compare

one tool with another. It may be used for a preliminary

assessment of exposure.

The declared vibration emission level represents the

main applications of the tool. However if the tool is used

for different applications, with different accessories or

poorly maintained, the vibration emission may differ.

This may significantly increase the exposure level over

the total working period.

An estimation of the level of exposure to vibration

should also take into account the times when the tool is

switched off or when it is running but not actually doing

the job. This may significantly reduce the exposure level

over the total working period.

Identify additional safety measures to protect the opera-

tor from the effects of vibration such as: maintain the tool

and the accessories, keep the hands warm, organisation

of work patterns.

Emission values for sound and vibration

(Two-figure – specifications as per ISO 4871)

* These values are based on a work cycle consisting of

no-load and full-load operation of the same duration.

For information on the vibration class assigned to the

application tool, please see the enclosed data sheet

3 41 30 213 06 2.

Operating instructions.

Changing the tool FSC1.6Q/FSC2.0Q (see page 5).

Do not use accessories not specifically intended and recom-

mended for this power tool by FEIN.

 The use of non-original

FEIN accessories can lead to overheating of the power

tool and destroy it.

When changing application tools with sharp cutting

edges, use cover 3 21 74 011 00 0 to protect

yourself against hand injuries.

Firmly press in the fastening element to the stop.

Then lock the clamping lever.

Protect your hand and fingers against bruising them

when locking the clamping lever.

 The clamping lever

snaps back vigorously by means of spring force.

Guide the power tool toward the work piece only

when switched on.

Before using, sharpen used and even new cutter blades

with the cleaning block.

The symptom for worn blades is a clearly increased feed

force at lower working progress.

The application tool can be offset in 30° steps and fas-

tened in the most favourable working position.

Guide straight, bent or offset cutter blades at a right angle

to the window flange (see page 10

–

11, Cutter blades

A

–

D).

For U-shaped cutter blades, pay attention that the

traverse of the cutter blade is led parallel to the window

pane of the vehicle (see page 11, Cutter blades E

–

F).

The scraper knife is used for cutting back bond remain-

ders on the window flange or the pane. Before re-bond-

ing the vehicle window, cut back the remaining bead to a

height of approx. 2 mm (see page 11, Cutter blades G).

Repair and customer service.

When working metal under extreme operat-

ing conditions, it is possible for conductive

dust to settle in the interior of the power

tool. The total insulation of the power tool can be

impaired. Blow out the interior of the power tool via the

ventilation slots frequently with dry and oil-free com-

pressed air, and connect a residual current device (RCD)

on the line side.

If the supply cord of this power tool is damaged it must

be replaced by a specially prepared cord available

through the FEIN customer service centre.

If required, you can change the following parts yourself:

Application tool, fastening element (FSC1.6Q/FSC2.0Q)

Warranty and liability.

The warranty for the product is valid in accordance with

the legal regulations in the country where it is marketed.

In addition, FEIN also provides a guarantee in accordance

with the FEIN manufacturer’s warranty declaration.

The delivery scope of your power tool may include only

a part of the accessories described or shown in this

instruction manual.

Declaration of conformity.

FEIN declares itself solely responsible for this product

conforming with the relevant provisions given on the last

page of this Instruction Manual.

Environmental protection, disposal.

Packaging, worn out power tools and accessories should

be sorted for environment-friendly recycling.

Vibration

Classification of FEIN application

tools according to vibration class

Weighted

acceleration*

VC0

< 2.5 m/s

2

VC1

< 5 m/s

2

VC2

< 7 m/s

2

VC3

< 10 m/s

2

VC4

< 15 m/s

2

VC5

> 15 m/s

2

3 m/s

2

K
