Technical data

Type CNS 50 S

CNS 75 S

CNS 100 S

CNS 125 S

CNS 150 S

CNS 175 S

CNS 200 S

CNS 250 S

CNS 300 S

CNS 50 U

CNS 75 U

CNS 100 U

CNS 125 U

CNS 150 U

CNS 175 U

CNS 200 U

CNS 250 U

CNS 300 U

Height mm 450

Width mm 370 445 445 590 590 740 740 890 1040

Depth

78

mm

with wall bracket

100

Dimension

A mm 121 195 195 343 343 491 491 639 787

Weight kg 3,0 4,2 4,2 5,6 5,6 7,0 7,0 8,4 9,8

Connection 1/N ~ 230 V 50 Hz

Power kW 0,5 0,75 1,0 1,25 1,5 1,75 2,0 2,5 3,0

Temperature

ºC approx. 6 to 30

adjustment range

Frost protection

ºC approx. 6

Protection class

II

Protection mode IP 24, splash water protected

Approval see unit rating palte

3. Environment and recycling

Recycling of obselete appliances

Appliances with this label must not be

disposed off with the general waste.

They must be collected separately and

disposed off according to local regulations.

Guarantee

For guarantees please refer to the pespective

terms and conditions of supply for your country.

The installation, electrical connection

and rst operation of this appliance

should be carried out by a qualied installer.

The company does not accept liability for

failure of any goods supplied which accor-

dance with the manufacturer‘s instructions.
