HP Scanjet 8270 Document Flatbed Scanner: Regulatory information and

Regulatory information and: HP Scanjet 8270 Document Flatbed Scanner

Regulatory information and

7

product specifications

This section contains regulatory information and product specifications for the HP

Scanjet 8270 scanner and accessories.

Scanner specifications

Name Description

Scanner type Flatbed

Weight (without

2.79 kg (6.2 lbs)

lid)

Maximum

296 x 494 x 73 mm (11.7 x 19.8 x 2.9 inches)

original size

Scanning element Charged-coupled device

Interface Hi-Speed USB

Optical resolution Scanner: 4800 dpi

ADF: 600 dpi

Selectable

12 dpi to 999,999 dpi at 100 percent scaling

resolution

AC line voltage 100 - 120 V 60 Hz – North America

100 - 240 V 50/60 Hz

Power

For power consumption data, see the

consumption,

regulatory_supplement.htm file on the HP Photosmart Software

Regulatory

CD.

Model

For regulatory identification purposes your product is assigned

Identification

a Regulatory Model Number. The Regulatory Model Number for

Number and

your product is GRLYB-0206. This regulatory number should

regulatory

not be confused with the marketing name (HP ScanJet 8270) or

information

product numbers (L1975A, L1976A). Additional information

about your scanner can be found on the regulatory

supplement.htm file on the HP Photosmart Software CD. The

power supply approved for usage with this scanner is HP Model

Number C9930 - 80004; see the regulatory supplement.htm file

for additional information on the power supply.

28

HP Scanjet 8270 Document Flatbed Scanner

(continued)

Name Description

Your HP scanner is ENERGY STAR® compliant. As an

English

ENERGY STAR® partner, Hewlett-Packard Company has

determined that this product meets the ENERGY STAR®

guidelines for energy efficiency.

Disposal of waste equipment by users in private

households in the European Union

This symbol on the product or on its packaging indicates that

this product must not be disposed of with your other household

waste. Instead, it is your responsibility to dispose of your waste

equipment by handing it over to a designated collection point

for the recycling of waste electrical and electronic equipment.

The separate collection and recycling of your waste equipment

at the time of disposal will help to conserve natural resources

and ensure that it is recycled in a manner that protects human

health and the environment. For more information about where

you can drop off your waste equipment for recycling, please

contact your local city office, your household waste disposal

service or the shop where you purchased the product.

Transparent materials adapter (TMA) specifications

Name Description

Media Types and Capacity Slides: up to 3 slides, 35 mm, mounted on a frame that

is 1.05 x 1.9 mm thick and 49.8 x 50.8 mm square.

Negatives: up to 4 frames of a 35 mm negative strip.

Size 565 x 320 x 64 mm (22.2 x 12.6 x 2.5 inches)

Weight 1.6 kg (3.5 lbs)

Power requirements 16 VDC, 425 mA, 6.8 watts (supplied by scanner)

Automatic document feeder (ADF) specifications

Name Description

Size 584 x 318 x 89 mm (23.0 x 12.5 x 3.5 inches)

Weight (with TMA) 2.7 kg (6.0 lbs)

2

Paper tray capacity

50 pieces of 75 g/m

(20-lb bond)

Maximum paper size 216 x 356 mm (8.5 x 14 inches)

Minimum paper size 89 x 127 mm (3.5 x 5 inches)

User Guide

29

Chapter 7

(continued)

Name Description

2

Maximum paper weight

90 g/m

(24 lbs)

Power requirements 32 VDC, 1200 mA; 16 VDC, 425 mA; 3300 mVDC 3.3

VDC, 300 mA (supplied by scanner)

Environmental specifications for the scanner, ADF, and

TMA

Name Description

Temperature Operating: 10° to 35° C (50° to 95° F)

Storage: -40° to 70° C (-40° to 158° F)

Relative humidity Operating: 15 to 80 percent noncondensing 10° to 35°

C (50° to 95° F)

Storage: up to 90 percent at -40° to 70° C or (-40° to

158° F)

30

HP Scanjet 8270 Document Flatbed Scanner
