HP Scanjet 8270 Document Flatbed Scanner: How to scan from the

How to scan from the: HP Scanjet 8270 Document Flatbed Scanner

How to scan from the

3

English

transparent materials adapter

(TMA)

Use the transparent materials adapter (TMA) to scan 35 mm slides or negatives.

Tips for scanning transparent items

● To scan items larger than those that the TMA accepts, place the transparency on

the scanner glass, place a white sheet of paper on top of the transparency, and

then scan as usual.

● When scanning a 35 mm slide or negative, the scanner software automatically

enlarges the image to approximately 10 cm x 15 cm (4 x 6 inches). If you want

the final image to be larger or smaller, use the Resize tool in the scanner

software to set the scaling to the final size that you select. The scanner will scan

the item to the size that you select and adjust the scan resolution as appropriate.

● To scan positives, such as 35 mm slides, or negatives using the TMA, press the

Scan Picture button (

) on the front of the scanner, or click the Scan Film

button in HP Solution Center.

Scan slides

To scan 35 mm slides, use the slide holder that is part of the built-in TMA.

1. Open the scanner lid and remove the TMA cover.

2. Remove the negative holder, if present, from the slide holder.

User Guide

13

Chapter 3

3. Place up to three slides into the slide holder. Insert the slides with the front of the

slides facing you.

4. After loading the last slide, insert the slide light-shield until it touches the slides.

Note Inserting the slide light-shield prevents stray light on the scanned

image.

5. Close the scanner lid.

6.

Click the Scan Picture button (

).

The HP Scanning dialog box is displayed.

7. Select Picture.

8. Select Scan positives, including 35 mm slides, using the TMA.

If you want to preview the scanned image, select the Show Preview check box

on the screen, or begin the scan from HP Solution Center.

9. Click Scan.

10. Follow the instructions on the screen to finish scanning.

14

HP Scanjet 8270 Document Flatbed Scanner

The scan is sent to the destination selected in the HP Scanning dialog box.

11. When finished, remove the slides. Replace the slide light-shield, the negative

holder, and the TMA cover.

English

Scan negatives

To scan 35 mm negatives, use the negative holder that is part of the built-in TMA.

1. Open the scanner lid and remove the TMA cover.

2. Remove the negative light-shield from the negative holder. The negative holder is

stored in the slide holder.

3. Slide a negative strip into the negative holder so that the shiny side faces the

scanner glass when the scanner lid is closed.

Note Negatives are easily damaged. Touch them only on their edges.

User Guide

15

Chapter 3

4. If you are scanning a negative strip that has fewer than four frames, insert the

negative light-shield into the negative holder until it touches the negative strip.

Note Inserting the negative light-shield prevents stray light on the

scanned image.

5.

Click the Scan Picture button (

).

The HP Scanning dialog box is displayed.

6. Select Picture.

7. Select Scan negatives using the Transparent Materials Adapter (TMA).

If you want to preview the scanned image, select the Show Preview check box

on the screen, or begin the scan from HP Solution Center.

8. Click Scan.

9. Follow the instructions on the screen to finish scanning.

The scan is sent to the destination selected in the HP Scanning dialog box.

10. When finished, remove the negative strip. Replace the negative holder, the

negative light-shield, and the TMA cover.

16

HP Scanjet 8270 Document Flatbed Scanner
