RA‑1570 Stereo Integrated Amplifier

Specifications

Continuous Power Output

120 watts/channel

(20-20 kHz, < 0.03%, 8 ohms)

Total Harmonic Distortion

(20Hz-20kHz)

< 0.03%  at rated power,

1/2 power, or 1 watt

Intermodulation Distortion

(60 Hz : 7 kHz, 4:1)

< 0.03%  at rated power,

1/2 power or 1 watt

Frequency Response:

Phono Input

20Hz-20kHz, ±0.5dB

Line Level Inputs

10Hz-100kHz, +1, –3dB

Damping Factor

(20Hz-20kHz, 8 ohms)

 180

Input Sensitivity / Impedance

Phono Input

(MM)

2.25mV / 68k ohms

Line Level Inputs

(RCA)

285mV / 100k ohms

Line Level Inputs

(Balanced)

570mV / 50k ohms

Input Overload

Phono Input

30mV

Line Level Inputs

4V

Preamplifier Output / Impedance

1.5V / 470 ohms

Signal to Noise Ratio

(IHF “A” weighted)

Phono Input

80dB

Line Level Inputs

100dB

Digital Section

Frequency Response

10Hz - 95kHz

(±3.0dB, Max)

Signal to Noise Ratio

(IHF ”A” weighted

)

100 dB

Input Sensitivity/Impedance

0 dBfs / 75 ohms

Preout Level/Impedance

1.2 V/ 470 ohms (at -20 dB)

USB/iPod Digital Signals

WAV, MP3, WMA

(up to 48kHz 16 bit)

Coaxial/Optical Digital Signals

SPDIF LPCM

(up to 192kHz 24 bit)

PC-USB

USB Audio Class 1.0

(up to 24 bit/96kHz)

USB Audio Class 2.0

(up to 24 bit/192kHz)*

*Driver installation required

Power Requirements:

USA:

120 Volts, 60 Hz

EC:

230 Volts, 50 Hz

Power Consumption

400 watts

Standby Power Consumption

< 0.5 watts

Dimensions

(W x H x D)

431 x 144 x 350 mm

(17 x 5

7

/

8

 x 13

3

/

4

 ins)

Front Panel Height

3U (132.6mm, 5

1

/

4

 ins)

Weight

(net)

13kg, 28.7 lbs.

All specifications are accurate at the time of printing.

Rotel reserves the right to make improvements without notice.

Rotel and the Rotel Hi-Fi logo are registered trademarks of The Rotel Co, Ltd.,

Tokyo, Japan.

“Made for iPod,” and “Made for iPhone,” means that an electronic

accessory has been designed to connect specifically to iPod or iPhone,

respectively, and has been certified by the developer to meet Apple

performance standards. Apple is not responsible for the operation of

this device or its compliance with safety and regulatory standards.

Please note that the use of this accessory with iPod, or iPhone may affect

wireless performance.

iPhone, iPod, iPod classic, iPod nano, and iPod touch are trademarks of

Apple Inc., registered in the U.S. and other countries.
