RA‑1570 Stereo Integrated Amplifier

Getting Started

Thank you for purchasing the Rotel RA-1570 Stereo Integrated Amplifier.

When used in a  high-quality music audio system, it will provide years

of musical enjoyment.

The RA-1570 is a full featured, high performance component. All aspects

of the design have been optimized to retain the full dynamic range and

subtle nuances of your music. The RA-1570 has a highly regulated power

supply incorporating a Rotel custom-designed toroidal power transformer

and custom-made slit foil capacitors. This low impedance power supply has

ample power reserves, which enables the RA-1570 to easily reproduce

the most demanding audio signals. This type of design is more expensive

to manufacture, but it is better for the music.

The printed circuit boards (PCB) are designed with Symmetrical Circuit

Traces. This insures that the precise timing of the music is maintained

and faithfully recreated. The RA-1570 circuitry uses metal film resistors

and polystyrene or polypropylene capacitors in important signal paths.

All aspects of this design have been examined to ensure the most faithful

music reproduction.

The main functions of the RA-1570 are easy  to install and use. If you

have experience with other stereo systems, you shouldn’t find anything

perplexing. Simply plug in the associated components and enjoy.

A Few Precautions

WARNING:

To avoid potential damage to your system, turn off ALL

the components in the system when connecting or disconnecting the

loudsp-eakers or any associated components. Do not turn the system

components back on until you are sure all the connections are correct

and secure. Pay particular attention to the speaker wires. There must

be no loose strands that could contact the other speaker wires, or

the chassis of the amplifier.

Please read this manual carefully. In addition to basic installation and

operating instructions, it provides valuable information on various RA-1570

system configurations as well as general information that will help you get

optimum performance from your system. Please contact your authorized

Rotel dealer for answers to any questions you might have. In addition,

all of us at Rotel welcome your questions and comments.

Save the RA-1570 shipping carton and all enclosed packing material for

future use. Shipping or moving the RA-1570 in anything other than the

original packing material may result in severe damage to your amplifier.

Fill out and send in the owner’s registration card packed with the RA-1570.

Also be sure to keep the original sales receipt. It is your best record of

the date of purchase, which you will need in the event warranty  service

is ever required.

Placement

Like all audio components that handle low-level signals, the RA-1570

can be affected by its environment. Avoid placing the RA-1570 on top

of other components. Also avoid routing audio signal cables near power

cords. This will minimize the chance it will pick up hum or interference.

The RA-1570 generates heat as part of its normal operation. The heat

sinks and ventilation openings in the amplifier are designed to dissipate

this heat. The ventilation slots in the top cover must be open. There should

be 10 cm (4 inches) of clearance around the chassis, and reasonable

airflow through the installation location, to prevent the amplifier from

overheating.

Remember the weight of the amplifier when you select an installation

location. Make sure that the shelf or cabinet can support it. We recommend

installing the RA-1570 in furniture designed to house audio components.

Such furniture is designed to reduce or suppress vibration which can

adversely affect sound quality. Ask your authorized Rotel dealer for advice

about component furniture and proper installation of audio components.

The RA-1570 is supplied with an RR-AX92 remote control and must be

placed where the infrared signal from the remote can reach the front

panel Remote Sensor.

Cables

Be sure to keep the power cords, digital signal cables and regular

audio signal cables in your installation away from each other. This will

minimize the chance of the regular audio signal cables picking up noise

or interference from the power cords or digital cables. Using only high

quality, shielded cables will also help to prevent noise or interference from

degrading the sound quality of your system. If you have any questions

see your authorized Rotel dealer for advice about the best cable to use

with your system.

The RR‑AX92 Remote Control

Some functions can be done with either the front panel controls, or the

supplied RR-AX92 remote control. When these operations are described,

the square call out numbers refer to the main unit, while the encircled

letters refer to the remote control.

NOTE:

The remote control can be used to operate the basic functions

of Rotel tuners and CD players. Remote control keys labeled

GHMN

can be used to operate CD or Tuner functions in your system. For the

remote to operate properly, make sure both the remote and the CD

or Tuner are both in same remote code.

Remote Control Batteries

Two UM-4/AAA size batteries (supplied) must be installed before the

remote control can be used. To install the batteries, remove the cover on

the back of the RR-AX92. Install the batteries as shown in the illustration

in the battery well. Test the control for proper operation, then replace

the cover. When the batteries become weak the remote control won’t

operate the RA-1570 consistently. Installing fresh batteries should eliminate

the problem.

AC Power and Control

AC Power Input

i

Because of its relatively high power rating, the RA-1570 can draw

considerable current. Therefore, it should be plugged directly into a

2-pin polarized wall outlet. Do not use an extension cord. A heavy duty

multi-tap power outlet strip may be used if it (and the wall outlet)  is

rated to handle the current demanded by the RA-1570 and all the other

components connected to it.

Your RA-1570 is configured at the factory for the proper AC line voltage

in the country where you purchased it (either 120 volts AC or 230
