TECHNICAL DATA

VP 6

VP 6

Vacuum pump

(110 V)

(220-240 V)

Production code 4108 90 01...

4118 61 01...

... 000001-999999

... 000001-999999

Frequency 60 Hz 50-60 Hz

Connecting lead 400 W 250 W

No-load speed 3400 U/min 3400 U/min

Fuse 2 AT 2 AT

Final vacuum -850 mbar -850 mbar

3

3

Delivery rate 6 m

/h

6 m

/h

100 l/min

100 l/min

Dimensions(LxWxH) 325 x 210 x 280 mm 365 x 230 x 268 mm

Ambient temperature -10°C – +40°C -10°C – +40°C

Compressed air connection IG 3/8 “ IG 3/8 “

Weight according EPTA-Procedure 01/2003 12 kg 12 kg

Motor

DGB

Protection category I (protective earthing), Protection Class IP 54

thermal overload protection

Noise information

Typically, the A-weighted noise levels of the tool are:

Sound pressure level (K=3dB(A))

78 dB (A) 78 dB (A)

Wear ear protectors!

The noise level when working can exceed 80 dB (A).

The relevant national accident prevention regulations are to be ob-

WARNING! Read all safety warnings and all instruc-

served when commissioning, operating and servicing the vacuum.

tions, including those given in the accompanying brochure.

The vacuum must always be used in conjunction with suitable

Failure to follow the warnings and instructions may result in

equipment.

electric shock, re and/or serious injury. Save all warnings and

instructions for future reference.

SPECIFIED CONDITIONS OF USE

SAFETY INSTRUCTIONS

The vacuum should be set up so that the intake and exhaust air of

the motor has good circulation, and so that the vacuum does not

First check whether the mains voltage corresponds to the voltage

wander, e.g. due to vibration. Keep the air vents on the housing

given on the power rating plate of the vacuum.

unblocked and clean at all times. The vacuum must not be operated

The vacuum should be plugged into approved earthed wall sockets

in a closed cabinet unless the cabinet is suciently cooled and ven-

only. It is forbidden to disconnect the protective ground contact.

tilated. Please pay attention to the protection class of the device!

Regularly check the connecting lead and any extension cable for

STARTUP

damage.

Check the hose line for damage, use proper suction hoses, tempera-

Connect the suction hose to the designated connector. Please make

ture resistance of at least 80°C.

sure that the suction hose used can withstand temperatures above

80 °C.

Please note that electrical devices must be repaired, serviced and

examined by electricians only in accordance with the national

Connect the mains cable.

regulations (e.g. in compliance with VBG 4), since improper repairs

Turn on the device at the main switch.

can pose signicant hazards to the user.

Use original replacement parts only.

No responsibility is accepted for damage incurred as a result of

disregarding the operating instructions, using the device for a use

other than the intended use, and as a result of improper repairs and

utilization.

The intended use is governed by the national work safety regulati-

ons (e.g. Appliance/Equipment Safety Law).
